SUMAKE
1/2" Air Impact Wrench W/ 2" Anvil
Twin Hammer, Composite Housing
Specification:
Free Speed
Std. Bolt Size
Max. Torque
Working Torque
Overall Length
Air Consumption
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
ST-C5444S-2
8,500 r/min
53/64" (M21)
1100 ft-lb (1491 Nm)
800 ft-lb (1080 Nm)
6.89" (175 mm)
17 CFM (480 L/min)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
3.6 lbs (1.65 kg)
Noise and Vibration:
Vibration
EN ISO 28927-2
Sound Pressure Level
under no load : 96.7 dB(A)
under load: 101.6 dB(A)
under load
:
8.29 m/s²
under no load: 107.7 dB(A)
under load: 112.6 dB(A)
Uncertainty
²
K= 1.5 m/s
Noise
EN ISO 15744
Please always
protector at
Sound power level
environment
noise level >
80 dB(A) due
Uncertainty
K= 3dB
ST-C5444S-2-S-1805B-JUF
Remark
wear ear
to risk of
impaired
hearing!
Advertisement
Table of Contents
Related Manuals for Sumake ST-C5444S-2
Summary of Contents for Sumake ST-C5444S-2
- Page 1 Air Hose (I.D.) 3/8” (10 mm) impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! ² K= 1.5 m/s K= 3dB Net Weight 3.6 lbs (1.65 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-C5444S-2-S-1805B-JUF...
- Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： 1/2" AIR IMPACT WRENCH W/ 2" ANVIL (TWIN HAMMER), -COMPOSITE HOUSING- Model/ Serial No.：ST-C5444S-2 to which this declaration applies, complies with these normative documents: ...
- Page 3 Application: The impact wrench is designed to deliver high torque output with minimal exertion by the user, for the purpose of tightening or loosening nuts and bolts. Operation Method: Press the trigger for running and release to stop. Please be aware that the tool will stop rotation within few seconds. For safety reason, place the tool on the level plate or on hanger after use.
- Page 4 C5444-15A Air Inlet (PT19) C5444-39 Hammer Pin C5444-15B Air Inlet (NPT18) C5444-40 1/2" Dr. Anvil [ST-C5444S] C5444S-16 Packing C5444-40A 1/2" Dr. Anvil 2" Extended [ST-C5444S-2] C5444S-18 Reverse Lever C5444-41 O-Ring C5444-19 Spring C5444-42 1/2" Anvil Collar C5444-20 Steel Ball C5444-43...
- Page 5 IMPACT WRENCH Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 3. If the operator experiences symptoms such as persistent or recurring discomfort, pain, throbbing, aching, tingling, numbness, burning sensations or stiffness, these warning signs should not be ignored. The operator should tell the employer and consult a qualified health professional. Safety precautions for accessory hazards 1.
- Page 8 General preparation and connection: When using brand-new air hose or air pipe. Blow and clean the inside of air hose or pipe before installation. Keep inside of air hose or air pipe clean to prevent airdrop problem caused by the lots of drain and dust accumulated and possibly make the inside diameter smaller in the long use.
