1 - INTRODUCING THE PRODUCT

1.1 - Product and model description

The EASY2 is a digital selector pad for controlling automatic doors,
for use instead of or in addition to an SMNPAE manual selector
switch. The EASY2 allows users to change the door's status and
perform control, setup or diagnostics on operating parameters by
means of an RS485 connection.
When switched on, the EASY2 sets by default for control of the
automatic door's status.
8,2 cm
CODE DESCRIPTION
900EASY2 Digital selector pad with 128 x 64 pixel display for automatic doors
9,2 cm
To access the set-up and diagnostics menu, the user has to enter
a password (set in the factory as 0000).
The same password can be enabled for automatic door status
change operations: bidirectional, open, int radar, ext radar,
manual, partial and lock. After entering the password, the user
has 10 seconds to make additional changes, after which he will be
prompted to enter the password again.
6 cm
2,8 cm
8 cm
EN
2,5 cm
11
