- Page 1 Assembly Instructions Item# L-GG067PST...
- Page 2 IMPORTANT: Please read and follow all safety statements, warnings, assembly instructions, use & care directions before attempting to assemble. 1. When installing and assembling your gazebo, it is recommended that 2 or more adults are involved. It takes one or two hours to assemble the gazebo. 2.
- Page 3 Parts List Post (1) Post (2) Small top connector Big top connector Decorative Cap Hook Small beam Big beam Long screen Short screen Glass panel Hook rack Base cover Base Small canopy Big canopy Hardware Pack 1 M6*15 Bolt 12 PCS M6 Big flat washer 44 PCS M6*15 Bolt...
- Page 4 Fig.1: Insert the post (A1A2) into the base cover (L) to from the bottom. And then attach base (M) to post by bolt (AA) and washer (BB). Fig.2: Attach decorative cap (D) to long and short screen (H/I) and fix long/short screen (H/I) and decorative cap (D) together by bolt (CC) and washer (BB).
- Page 5 Fig.9: Inert the connector of glass panel (J) into the U-shaped piece of post (A1A2) and then attach the glass panel tightly by bolt (AA) and washer (BB). Hardware Pack 2 Φ6X180MM Stake 8 PCS Fig.10: Put small canopy (N) onto small top, and attach four corners of the canopy to small beam (F). Fig.11: Spread out the big canopy and attach four corners of the canopy to big beam (G).
- Page 6 This can be prevented if measure is taken to keep the product from oxidizing. DON’T RETURN THE ITEM TO STORES, need tech. assistance or replacement parts, please call Sunjoy Industries at 1(866) 578-6569 from 8:30 am to 5:30 pm eastern standard time or e-mail to customer.care@sunjoygroup.com...
