- Page 1 Domed Top Grill Gazebo Assembly Instruction Item# L-GG035PST SKU # 810138516...
- Page 2 IMPORTANT: Please read and follow all safety statements, warnings, assembly instructions, use & care directions before attempting to assemble. 1. When installing and assembling your gazebo, it is recommended that 2 or more adults are involved. 2. Do not use the unit during an electrical storm, as there is a remote chance of getting struck by lightening.
- Page 3 Parts List Arch post 1 Arch post 2 Bottom crossbeam Long screen Short screen Shelf Side beam Top connector Hook Small canopy Large canopy Hardware Pack1 M6X15 Bolt 24 PCS M6 Flat washer 24 PCS M6 Wrench 2 PC...
- Page 4 Fig.4: Attach long screen Fig.3: Attach shelf (F) Fig.1: Put the bottom Fig.2: Attach short screen (D) to post 1 (A) and post to post 1 (A) and post 2 crossbeam (C) on the (E) to post 1 (A) and post 2 2 (B) by bolt (AA) and flat (B) by bolt (AA) floor, insert post 2 (B)
- Page 5 Fig.5: Insert side beam Fig.6: Attach side beam Fig.7: large Fig. ８ : Spread out (G) to top connector (H), (G) to post 1 (A) and post 2 canopy (K) onto big large canopy (K). then attach hook (I) to top (B) by bolt (CC), flat top, do not spread out,...
- Page 6 CUSTOMER SERVICE Sunjoy Industries warrants to the original purchaser that this item is free from defects in workmanship and materials of your item provided the item was factory-sealed at the time of purchase and is maintained with care and used only for personal, residential purposes. The item is warranted to be free from defects in material or workmanship for a period of 6 months.
