Sunjoy L-GG032PST-C 8'X5' Kent Hard-top Grill Gazebo
Owner's Manual
IMPORTANT
Thank you very much for choosing Sunjoy Group.
Please take time to read these instructions thoroughly and follow each step carefully for safe
and easy operation. Keep this manual for future reference.
We would like to hear from you with any comments or suggestions. You can call us toll-free at
1-866-578-6569
from 8:00 a.m. EST to 8:00 p.m. PST. You can also send the email to
customer.care@sunjoygroup.com
or visit
www.sunjoyonline.com
to get tech. assistance or to
place your replacement part order form.
Production Number:xxxxxxxx
Advertisement
Table of Contents
Related Manuals for Sunjoy L-GG032PST-C
Summary of Contents for Sunjoy L-GG032PST-C
- Page 1 Sunjoy L-GG032PST-C 8’X5’ Kent Hard-top Grill Gazebo Owner’s Manual IMPORTANT Thank you very much for choosing Sunjoy Group. Please take time to read these instructions thoroughly and follow each step carefully for safe and easy operation. Keep this manual for future reference.
- Page 2 Cautions: 1. Keep all children and pets away from assembly area. Children and pets should be supervised when they are in the area of gazebo construction. 2. The area for assembly should not be less than 6 feet from any obstruction such as fence, garage, house, overhanging branches, laundry line or electrical wires.
-
Page 3: Parts List
Parts List Roof Vent 2pcs Base 4pcs Base Cover 4pcs Support Bar 1 2pcs Support Bar 2 2pcs Top Bar Top Horizontal 2pcs Beam1 Top Horizontal 2pcs Beam2 Top Horizontal 4pcs Beam3 Hook Big Roof Cover 1 2pcs Big Roof Cover 2 2pcs Big Roof Cover 3 2pcs... -
Page 4: Hardware Pack
Press Slice 2 8pcs Top Screen 2pcs Bottom Screen 2pcs Press Panel 6pcs Hardware Pack 1 M6x20 Hex Bolt 44PCS M6 Flat Washer 44PCS M6 Hex Wrench 2 PCS Insert Support Bars ( D1, D2 ) into Roof Vent ( A ) ,then connect Top Horizontal Beam2 ( F2 ) by Bolt Fig.1:... - Page 5 Connect Top Horizontal Beam3 (F3) and Roof Vent (A) by Bolt (AA) and Washer (BB). Fig.4: Connect Top Horizontal Beam 3 (F3) and Support Bars (D1, D2) by Bolt (AA) and Washer (BB). Fig.5: Connect Top Horizontal Beam 1 (F1) and Support Bars (D1, D2) by Bolt (AA) and Washer (BB). Fig.6: Hardware Pack 2 M6 Flat Washer...
- Page 6 Tighten Big Roof Cover (H1, H2 and H3) with Press Panel (Q) by Bolt (CC) and Washer (BB). Fig.7: Fig.8: Place Small Roof Cover (I1, I2 and I3) to be well, and then tighten them with Press Panel (Q) by Bolt (CC) and Washer (BB).
- Page 7 Attach Base Cover (C) on Post (K1, K2), then tighten Base (B) with Post (K1, K2) by Bolt (CC) and Fig.10: Washer (BB) Raise up the assembled Large Roof, then insert the Post (k1, k2) into the Roof and tighten them by Fig.11: Bolt (AA) and Washer (BB).
- Page 8 Attach one end of slanting support (L) to Post (K1, K2) and the other end to Support Bar (D1, Fig.13: D2) by Bolt (AA) and Washer (BB). Tighten Bottom Screen (P) to Posts (K1) and (K2) by Bolt (EE) and Washer (BB). Fig.14: Place Countertop (M1) on Bottom Screen...
-
Page 9: Care And Maintenance
Care & Maintenance: Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective coatings are scratched. This is not a defect and thus not covered by the warranty. To minimize this condition, we recommend care when assembling &...
