  • Page 1 User Manual Digital Multimeter model no.: MSR-U1000...

  • Page 2: Safety Information

    This Operating Manual covers information on safety and cautions. Please read the relevant information carefully and observe all the Warnings and Notes strictly. Warning Unpacking Inspection Open the package case and take out the Meter. Check the following items carefully to see any missing or damaged part: Item Description...
  • Page 3 Rules For Safe Operation Warning To avoid possible electric shock or personal injury, and to avoid possible damage to the Meter or to the equipment under test, adhere to the following rules:  Before using the Meter inspect the case. Do not use the Meter if it is damaged or the case (or part of the case) is removed.

  • Page 4: The Meter Structure (See Figure 1)

     Turn the Meter off when it is not in use and take out the battery when not using for a long time.  Constantly check the battery as it may leak when it has been using for some time, replace the battery as soon as leaking appears. A leaking battery will damage the Meter.

  • Page 5: Functional Buttons

    Functional Buttons Below table indicated for information about the functional button operations. Button Operation Performed. Press and hold for 2 serconds to turn the display backlight on or off. Press to enter or exit data hold mode. Hold Press to select the alternate function. BLUE Button RANGE Press...

  • Page 6: Measurement Operation

    Symbol Meaning A: Amperes (amps). The unit of current. mA: Milliamp. 1 x 10 or 0.001 amperes µA : Microamp. 1x 10 or 0.000001 amperes F: Farad. The unit of capacitance. µF : Microfarad. 1 x 10 or 0.000001 farads. nF : Nanofarad.
  • Page 7 Note  In each range, the Meter has an input impedance of 10M except mV range which input impedance is 3000M . This loading effect can cause measurement errors in high impedance circuits. If the circuit impedance is less than or equal to 10k , the error is negligible (0.1% or less).
  • Page 8 Note  If the value of current to be measured is unknown, use the maximum measurement position, and reduce the range step by step until a satisfactory reading is obtained.  For safety sake, each measurement time for >5A current should be less than 10 seconds and the interval time between 2 measurements should be greater than 15 minutes.
  • Page 9 D. Testing for Continuity (See figure 5) figure 5 Warning To avoid damages to the Meter or to the devices under test, disconnect circuit power and discharge all the high-voltage capacitors before testing for continuity. To avoid harm to yourself, do not input higher than DC 60V or AC 30V voltages. To test for continuity, connect the Meter as below: 1.
  • Page 10 E. Testing Diodes (See figure 6) figure 6  Connect the test leads to the proper terminals as said above to avoid error display. The LCD will display OL indicating diode being tested is open or polarity is reversed. The unit of diode is Volt (V), displaying the forward voltage drop readings.
  • Page 11 F. Capacitance Measurement (See figure 7) figure 7 (around 10nF) n the tested capacitor is more than 100uF - 10 -...
  • Page 12 G. Frequency Measurement (see figure 8) figure 8  When frequency measurement has been completed, disconnect the connection between the testing leads and the circuit under test, and remove the testing leads away from the input terminals of the Meter. - 11 -...
  • Page 13 H. Transistor hFE Measurement (See figure 9) figure 9 1. Set the rotary switch to hFE. 2. Insert the multi-purpose socket into the input terminal as shown on figure 9. 3. Insert the transistor to be tested into the corresponding multi-purpose socket jacks. 4.
  • Page 14 Operation of Function buttons Hold button To avoid possibility of electric shock, do not use Hold mode to determine if circuits are without power. The Hold mode will not capture unstable or noisy readings. The Hold mode is applicable to all measurement functions. ...

  • Page 15: General Specifications

    Sleep Mode General Specifications  Maximum Voltage between any Terminals and Grounding: Refer to the different ranges input protection voltage.. Fused Protection for AmA Input Terminal:1A H 240V 6x25mm.  Fused Protection for 10A Input Terminal:10A H 240V 6x25mm.  ...
  • Page 16 Accurcy Specifications - 15 -...
  • Page 17 - 16 -...
  • Page 18 0.01Hz - 17 -...

  • Page 19: Maintenance

    Maintenance This section provides basic maintenance information including battery and fuse replacement instruction. Warning Do not attempt to repair or service your Meter unless you are qualified to do so and have the relevant calibration, performance test, and service information. To avoid electrical shock or damage to the Meter, do not get water inside the case.
  • Page 20 10A range: F2, 10A H 240V, 6x25 mm. (CE) 6. Rejoin the case bottom and case top, and reinstall the screw. 7. Rejoin the tilt stand, battery compartment and case bottom, and reinstall the screw. Questions or Concerns? support@etekcity.com visit etekcity.com for more products - 19 -...
