Related Manuals for ARDESTO WMS-6109S
Summary of Contents for ARDESTO WMS-6109S
- Page 1 ИНСТРУКЦИЯ Ardesto WMS-6109S...
- Page 15 Б М АВОВНА ІКС Е КОНОМ С ИНТЕТИКА РЕЖИМ С Д ПОРТИВНИЙ ИТЯЧИЙ 7,0 кг ОДЯГ ОДЯГ WMS-7109W С Ш ПІДНЯ ВИДКЕ БІЛИЗНА ПРАННЯ ХВ П ОЛОСКАННЯ В ОВНА В ІДЖИМ С /П Т Ш В В В ТАРТ АУЗА ЕМП.
- Page 46 Х М ЛОПОК ИКС Э КОНОМ С ИНТЕТИКА РЕЖИМ С Д ПОРТИВНАЯ ЕТСКАЯ 7,0 кг ОДЕЖДА ОДЕЖДА WMS-7109W Н Б ИЖНЕЕ ЫСТРО БЕЛЬЕ МИН. П ОЛОСКАНИЕ Ш ЕРСТЬ О ТЖИМ С /П Т С О В В ТАРТ АУЗА ЕМП. КОРОСТЬ...
- Page 67 Content Warning Safety Notifications Part Name Installation Instruction Methods of Door Lock and Remove The Usage Method of the Detergent Box Function Introduction of Operating Panel The Introduction of Function and Program The Introduction of Washing Programs Maintenance Varieties of Functions Notice before Washing Non-fault Conditions Troubleshooting Guide...
- Page 73 Requires for positions Horizontal adjustment: The slant angle should be less than 1 degree. Drain pipe Power outlet The distance between any side of washer and Wash tub power outlet should be within 1.5 meters. Don't use too many electrical appliances in one outlet.
- Page 76 Adjust alignment pins Adjust the adjustable feet to make sure the washing machine in balance, which can be placed on the ground steadily.After settling, screw the locknut to guarantee. Do not place the washing machine in the platform ,which is higher than the ground, in order to prevent the machine from falling down because of other accidents.
- Page 77 The recommendations on detergent use at the various temperatures When washing heavily soiled whites, we recommend using cotton programs of 60℃ or above and a normal washing powder(heavy duty) that contains bleaching agents that at medium/high temperatures provide excellent results. For washes between 40℃...
- Page 79 & H RESS SEC. HILD UNCTION М OTTON ІX Е YNTHETIC PORTS 7,0 kg WMS-7109W UICK NDERWEAR INSE + TART/ AUSE EMP. PEED ELAY UVET LEAN Image shown here is indicative only. Actual product you receive may differ.
- Page 81 Introduction Wool program This function is set for woolen and fibrous clothes. Please confirm the washing icon in clothes before washing them. 1.Preparation for washing Open the door, put clothes in and closes the door. Pull out the detergent box, add detergent and close the box. Connect the inlet pipes and make sure the tap turned on.
- Page 82 Baby Care program Introduction This function can use high temperature to sterilize and remove the mites. 1.preparation for washing Open the door, put clothes in and closes the door. Pull out the detergent box, add detergent and close the box. Connect the inlet pipes and make sure the tap turned on.
- Page 83 Mix Program Introduction This function can be used to wash mix clothes like cotton, synthetic and soon (please do not mix wash the clothes that easily rub off). 1.Prepare for washing Open the door, put the clothes then close the door Taking the detergent box and add detergent then close it.
- Page 85 Synthetic Program Introduction To wash the synthetic clothes 1.Preparation for washing Open the door, put the clothes then close the door. Taking the detergent box and add detergent then close it. Connect the water inlet pipe well and make sure the faucet is running. 2.Push “Power”...
- Page 86 Rinse and Spin Program Introduction The machine will not wash, only rinse and spin. 1.Prepare washing Open the door and put the cloths then close the door 2. Push “Power” button and connect to the power 3. Turn the program button to choose“Rinse+ Spin” program The washing program will be selected automatically.
- Page 87 Duvet Program Introduction The cloths have the machine-washable mark, like bedding, bed sheets, curtains, etc 1.Prepare for washing Open the door, put the clothes then close the door Taking the detergent box and add detergent then close it. Connect the water inlet pipe well and make sure the faucet is running. 2.Push “Power”...
- Page 88 EDF 1062 DA++ Maximum Program Revolution(rpm) Time(min) Cloth type Temperature(℃) Rinse(times) load cold water(20℃, general cotton fabrics 800(0,400,600,1000) Cotton rated 40℃,60℃,90℃) 20℃(cold water, ≤2kg general cotton fabrics 1000(0,400,600,800) 40℃,60℃) used for sport suit ≤4kg Sports 20℃(cold water,40℃) 800(0,400,600) noted with "hand-wash" cotton fabrics/cellulose ≤3kg 40℃(cold water,20℃)
-
Page 91: Maintenance
Maintenance When washing machine is frozen 1.Cover stopcock and the universal coupling with hot towel. 2.ake off the inlet pipe, and put it into 50 degree water. 3.Pour into the drum about 2-3L of 50 degree water. 4.Connect inlet pipe, turn on the stopcock and start the washing machine, please check whether inlet and outlet is normal. - Page 92 1. Child Lock function: You can lock and unlock the child lock function by pushing “Pre Delay” 3 seconds when the machine is running. Once the child lock function set, all the other buttons will be locked except the power button. When the washing process ending or push “Power”...
- Page 93 Abnormal power off for 2 minutes, you can open the door. During the process of running, the required condition for opening door(water level below door gasket, water temperature below 45℃,spin speed is 0),push "Start/Pause" button, wait till door lock mark disappear, then open the door. When closing the door, press the middle place of the door handle.
- Page 97 EDF 1062 DA++...
- Page 102 СМОТРИТЕ ТАКЖЕ Вытяжные Стиральные машины Полотенцесушители Бойлеры вентиляторы Фильтры от накипи для Раковины Шланги Ванны бытовой техники (умывальники) Аксессуары для Монтаж стиральных Душевые кабины Унитазы стиральных и сушильных машин машинок Отводы канализационные...
