- Page 1 SMART Board® 8070i interactive flat panel User’s guide For models SBID 8070i, SBID 8070i-SMP and SBID 8070ie-SMP...
- Page 2 © 2011–2014 SMART Technologies ULC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior written consent of SMART Technologies ULC. Information in this manual is subject to change without notice and does not represent a commitment on the part of SMART.
- Page 3 Do not open or disassemble the SMART product. You risk electrical shock from the high voltage inside the casing. Opening the casing also voids your warranty. Do not stand (or allow children to stand) on a chair to touch the surface of your SMART product. Rather, mount the product at the appropriate height.
- Page 4 Avoid setting up and using the SMART product in an area with excessive levels of dust, humidity and smoke. Make sure an electrical socket is near your SMART product and remains easily accessible during use.
- Page 5 Contact qualified personnel if you’re uncertain of the type of power system available where you’re installing your SMART product. You must connect the USB cable that came with your SMART Board® interactive flat panel to a computer that has a USB compliant interface and that bears the USB logo. In addition, the USB source computer must be compliant with CSA/UL/EN 60950 and bear the CE mark and CSA and/or UL Mark(s) for CSA/UL 60950.
-
Page 7: Table Of Contents
Chapter 5: Using your interactive flat panel Turning on and turning off your interactive flat panel Using the infrared remote control Getting started with your SMART Board interactive flat panel Playing audio files on your interactive flat panel Using the USB receptacle... - Page 8 Resolving touch control and digital ink issues Resolving audio issues Resolving remote control issues Resolving issues using the SMART Connection Wizard Resolving issues using SMART Board Diagnostics Appendix A: Adjusting video settings with the on-screen display menu Changing settings in the OSD menu...
-
Page 9: Chapter 1: About Your Interactive Flat Panel
Left side view Menu control panel USB receptacle Side terminal panel Back view Bottom terminal panel Inside terminal panel Audio terminal panel Appliance Other components for the SMART Board 8070i-SMP interactive flat panel SMART GoWire™ auto-launch cable CAT 5 USB extender smarttech.com/kb/155317... -
Page 10: Feature Highlights
SMART Ink Note appears and you can write inside the note. When you open an application that has its own ink tools, you can turn off SMART Ink, and then use the application's ink tools to write in the content. -
Page 11: Interactive Flat Panel Components
The object awareness feature enables you to pick up a pen, and then write, select or erase without replacing the pen. Durable surface The SMART Board 8070i interactive flat panel features a hardened glass screen. Interactive flat panel components Front view The front of your interactive flat panel includes the LCD screen, the cameras and reflective tape channel, the pen holders with the pens, the eraser holder with an eraser and the color select module. -
Page 12: Pen And Eraser Holders
C H A P T E R 1 About your interactive flat panel C A U T I O N Do not damage or remove the reflective tape. Keep the reflective tape dry. I M P O R T A N T Do not attach items such as adhesive notes to the screen because they will interfere with the cameras. -
Page 13: Front Control Panel
C H A P T E R 1 About your interactive flat panel Front control panel The front control panel contains the volume control, mute, input and power buttons, as well as the status light and infrared remote control sensor. I M P O R T A N T Do not cover or block this area or you could have reduced use of the infrared remote... -
Page 14: Left Side View
C H A P T E R 1 About your interactive flat panel Left side view The left side of your interactive flat panel has the menu control panel and the side terminal panel. Menu control panel The menu control panel enables you to access the on-screen display menu to adjust display and audio settings. -
Page 15: Back View
Back view The back of the interactive flat panel includes the bottom terminal panel, the inside terminal panel,the audio connection terminal panel and the appliance (for SMART Board 8070ie-SMP interactive flat panels only). I M P O R T A N T Connect all required cables before you wall-mount your interactive flat panel. -
Page 16: Bottom Terminal Panel
Blu-ray™ players and VCRs. C A U T I O N The AC power outlet is designated for a component of the SMART Board 8070ie-SMP interactive flat panel. Use this power outlet only as designated by documentation for that system. Using this power outlet for other items could damage the interactive flat panel. -
Page 17: Inside Terminal Panel
Appliance Your SMART Board 8070ie-SMP interactive flat panel appliance is attached to the back of the interactive flat panel. The appliance comes with SMART Product Drivers and the SMART Meeting Pro™ application installed (see About the SMART Meeting Pro application on page 48). -
Page 18: Other Components For The Smart Board 8070I-Smp Interactive Flat Panel
SMART GoWire™ auto-launch cable Enables you to use SMART Product Drivers and SMART Meeting Pro software without installing them on your computer. For more information, see Using a SMART GoWire cable on page 50. CAT 5 USB extender Extends a USB connection between your computer and the interactive flat panel. For more information, see the documentation included with the CAT 5 USB extender. -
Page 19: Chapter 2: Installing Your Interactive Flat Panel
Environmental requirements Before installing your interactive flat panel, review the following environmental requirements. For more detailed information, see SMART Board 8070i and 8070i-SMP interactive flat panel specifications (smarttech.com/kb/155318) or SMART Board 8070ie-SMP interactive flat panel with appliance specifications (smarttech.com/kb/170078). -
Page 20: Wall-Mounting Your Interactive Flat Panel
C H A P T E R 2 Installing your interactive flat panel Environmental requirement Parameter Power consumption at 77ºF Typically up–530 W (brightness at 70% and volume at 40), (25ºC) maximum 580 W (brightness and volume at maximums) Operating temperature 41°F to 95°F (5°C to 35°C) Storage temperature -4°F to 140°F (-20°C to 60°C) - Page 21 Save all product packaging so that it is available if you need to transport your interactive flat panel. If your original packaging is not available, you can purchase new product packaging from your authorized SMART reseller (smarttech.com/where). Important mounting considerations for trained installers...
- Page 22 C H A P T E R 2 Installing your interactive flat panel Choosing a mounting location Consider the following when you select a location for the interactive flat panel: The wall must be strong enough to support the interactive flat panel and the mounting equipment. The interactive flat panel weighs 262 lb.
-
Page 23: Chapter 3: Connecting Computers And Peripheral Devices
Chapter 3 Connecting computers and peripheral devices Installing the speakers Connecting a room control system Connecting computers to your interactive flat panel Interactive flat panel touch control and video input connections Connecting to power and your room computer Room computer connection diagram Installing a guest laptop connection Guest laptop connection diagram Disabling the USB receptacle on the side terminal panel... -
Page 24: Installing The Speakers
C H A P T E R 3 Connecting computers and peripheral devices Installing the speakers Your interactive flat panel comes with two 15 W speakers. To install the speakers 1. Attach the speakers to the speaker mounting holes on the side of the interactive flat panel with the included screws. -
Page 25: Connecting A Room Control System
I M P O R T A N T Do not use a null modem cable. Use only a standard RS-232 cable. For more information about setting up and programming an RS-232 connection, see Remotely managing your SMART Board 8070i interactive flat panel (smarttech.com/kb/160469). smarttech.com/kb/155317... -
Page 26: Connecting Computers To Your Interactive Flat Panel
N O T E This document describes the default USB and video connections. To customize the USB and video mapping, see Configuring the video and touch input for your SMART Board 8070i interactive flat panel (smarttech.com/kb/170065). Interactive flat panel touch control and video input connections The following table shows which touch control USB connection corresponds with which video input for each computer connection. -
Page 27: Connecting To Power And Your Room Computer
N O T E A wire management bundle (part number WMB-SBID) for the guest laptop connection is available from your authorized SMART reseller. This 16' (5 m) bundle includes a USB cable and a RGB/HV to VGA video cable. Connecting to power and your room computer Your room computer is the default computer for your interactive flat panel. -
Page 28: Installing A Guest Laptop Connection
Connecting computers to your interactive flat panel on page 18. W A R N I N G Ensure that any cables extending across the floor to your SMART product are properly bundled and marked to avoid a trip hazard. smarttech.com/kb/155317... -
Page 29: Guest Laptop Connection Diagram
C H A P T E R 3 Connecting computers and peripheral devices N O T E You do not require a laptop to install this cabling. Guest laptop connection diagram To setup the guest laptop connection location 1. Connect a USB cable to the USB 2 receptacle on the inside terminal panel, and then run the cable to the laptop connection location, such as beside the interactive flat panel or on a conference table. -
Page 30: Disabling The Usb Receptacle On The Side Terminal Panel
C H A P T E R 3 Connecting computers and peripheral devices To connect and use a guest laptop using this installed connection, see Connecting a guest laptop on page 49. Disabling the USB receptacle on the side terminal panel You can connect a USB drive or other USB device to the USB receptacle on the side terminal panel of your interactive flat panel, and then access the device from the room computer. -
Page 31: Connecting Peripheral Devices To Your Interactive Flat Panel
Connect peripheral devices to the bottom terminal panel. C A U T I O N The AC power outlet is designated for a component of the SMART Board 8070ie-SMP interactive flat panel with appliance. Use this power outlet only as instructed by that product’s documentation. - Page 32 C H A P T E R 3 Connecting computers and peripheral devices To connect a peripheral device 1. Turn off the interactive flat panel and the peripheral device. 2. Connect the peripheral device’s input cables to the appropriate connectors on the bottom terminal panel.
-
Page 33: Chapter 4: Installing Smart Software
For more information, see Updating SMART Product Drivers on page 55. You need to install SMART software on the computer that’s connected to your interactive flat panel in order to use the interactive flat panel. You can install either SMART Meeting Pro software or SMART Notebook software. -
Page 34: Installing Smart Meeting Pro Software
I M P O R T A N T Connect to the Internet before you install SMART software so that you can obtain a software product key (smarttech.com/registration) and download software updates. To install SMART Notebook software 1. - Page 35 (Windows operating systems) or the Dock (Mac OS X operating system software), and then select Check for Updates and Activation. The SMART Product Update window appears. 4. Follow the on- - screen instructions to update your SMART Notebook software to the latest version. smarttech.com/kb/155317...
-
Page 37: Chapter 5: Using Your Interactive Flat Panel
Turning on and turning off your interactive flat panel Using the infrared remote control Installing batteries in the remote control Infrared remote control sensor Infrared remote control buttons Getting started with your SMART Board interactive flat panel About SMART Ink SMART Ink Notes SMART Ink Document Viewer SMART Ink Toolbar About your SMART software SMART Product Drivers... -
Page 38: Turning On And Turning Off Your Interactive Flat Panel
C H A P T E R 5 Using your interactive flat panel Turning on and turning off your interactive flat panel To turn on your interactive flat panel 1. Turn on your computer. 2. Press the Power button on the front control panel. You can also press the POWER ON button on the remote control. -
Page 39: Using The Infrared Remote Control
C H A P T E R 5 Using your interactive flat panel Using the infrared remote control The infrared remote control enables you to turn on and turn off your interactive flat panel, change the input source, change the volume and more. You can also use the remote control to open the on- screen menu and then change the interactive flat panel’s settings. -
Page 40: Infrared Remote Control Sensor
C H A P T E R 5 Using your interactive flat panel To install batteries in the remote control 1. Press the tab on the underside of the remote control, and then slide it to open the cover. 2. Remove the batteries if they are present. 3. -
Page 41: Infrared Remote Control Buttons
C H A P T E R 5 Using your interactive flat panel Infrared remote control buttons POWER ON STANDBY The remote control enables you to access on-screen menus and change display and input settings. DISPLAY PORT RGB/HV DVD/HD VIDEO S-VIDEO HDMI Use the remote control’s POWER ON button turn on your... - Page 42 C H A P T E R 5 Using your interactive flat panel Number Function Description MENU Turns on and turns off the menu mode AUTO SET UP Enters auto setup menu EXIT Returns to previous menu Up/Down Moves the highlighted area up or down to select items within the on-screen display menu Increases or decreases the adjustment level within the on - screen display menu...
-
Page 43: Getting Started With Your Smart Board Interactive Flat Panel
You can convert your digital ink notes to text. You can also move, erase and capture your notes as an image and save it to your SMART software. When you open an application that has its own ink tools, you can turn off SMART Ink, and then use the application's ink tools to write. -
Page 44: About Your Smart Software
The ink becomes part of your .notebook file. For more information, see the SMART Meeting Pro support page (smarttech.com/SupportMeetingPro3Windows). Writing or drawing in digital ink Using the pen supplied with your interactive flat panel, you can write or draw digital ink over SMART software and other programs. To write or draw digital ink 1. -
Page 45: Entering Text On The Interactive Flat Panel
Changing pen settings You can change your pen settings, including line size and fill effects. To change pen settings 1. Press the SMART Board icon in the notification area (Windows operating systems) or the Dock (Mac OS X operating system software). Press the SMART Meeting Pro icon in the notification area. -
Page 46: Using Locked Ink Mode
9. Press Save Tool Settings to save your settings. 10. Optionally, repeat steps 4 through 9 to customize other pens. 11. Press OK to close SMART Settings. Using Locked Ink mode Locked Ink mode enables you to write or draw digital ink using large objects, including eraser-sized objects. -
Page 47: Changing Eraser Settings
To change eraser settings 1. Press the SMART Board icon in the notification area (Windows operating systems) or the Dock (Mac OS operating system software), and then select SMART Settings. Press the SMART Meeting Pro icon in the notification area, and then select SMART Settings. - Page 48 C H A P T E R 5 Using your interactive flat panel N O T E S This gesture performs a standard mouse click. This gesture starts programs if your operating system is set to start applications on a single click.
- Page 49 C H A P T E R 5 Using your interactive flat panel Using two fingers on the same hand, press and hold the object with your left finger, and then press the screen once with your right finger. Press the Right-Click button on the pen tray, and then press the object. To move an object 1.
- Page 50 C H A P T E R 5 Using your interactive flat panel To resize an object 1. Using one finger on each hand, press the screen at opposite ends of the object. 2. Drag your fingers in opposite directions to enlarge the object. Drag your fingers toward each other to reduce the object.
-
Page 51: Browsing
C H A P T E R 5 Using your interactive flat panel To rotate an object 1. Using one finger on each hand, press the screen at opposite ends of the object. 2. Rotate your fingers in the direction you want to rotate the object. 3. - Page 52 C H A P T E R 5 Using your interactive flat panel Quickly flick your finger right across the screen. To display the previous page Press the screen, and then quickly press again directly to the left of that point. Quickly flick your finger left across the screen.
- Page 53 C H A P T E R 5 Using your interactive flat panel To zoom in or out 1. Using one finger on each hand, press the screen at opposite ends of the object. 2. Drag your fingers in opposite directions to zoom in. Drag your fingers toward each other to zoom out.
-
Page 54: Playing Audio Files On Your Interactive Flat Panel
C H A P T E R 5 Using your interactive flat panel To pan horizontally or vertically 1. Using two fingers on the same hand, press and hold the screen. 2. Keeping your fingers on the screen, move up, down, left or right. 3. -
Page 55: Using The Usb Receptacle
C H A P T E R 5 Using your interactive flat panel Using the USB receptacle You can connect a USB drive or device to the USB receptacle on the side terminal panel on your interactive flat panel, and then access it from the room computer connected to VGA and USB 1. N O T E To disable the USB A receptacle on the side terminal panel, see Disabling the USB receptacle on the side terminal panel on page 22. -
Page 56: Using The Smart Meeting Pro Application
Using the SMART Meeting Pro application About the SMART Meeting Pro application The appliance that comes with your SMART Board 8070ie-SMP interactive flat panel is installed with software, including the SMART Meeting Pro application. The SMART Meeting Pro application enables you to work with various types of digital content, from application files and documents to images and websites. -
Page 57: Chapter 6: Using Guest Laptops With Your Interactive Flat Panel
SMART GoWire cable. If you purchased an SBID8070i-SMP or SBID8070ie-SMP model, you can use the supplied SMART GoWire cable to connect your laptop to the interactive flat panel. For more information, see Using a SMART GoWire cable on the next page. -
Page 58: Using A Smart Gowire Cable
However, if you want to connect a laptop that doesn’t have SMART software installed, you can connect a SMART GoWire cable from the laptop to the USB cable for your interactive flat panel. The SMART GoWire cable enables you to have touch control of your laptop and use SMART Meeting Pro software without installing the software on your laptop. -
Page 59: Connecting A Side Laptop
To disconnect a SMART GoWire cable 1. Save your SMART Meeting Pro software file to your laptop, if required. You can save the file as a .ppt, .pdf or .notebook file. I M P O R T A N T You can open a .notebook file on a computer that has SMART Meeting Pro software or... - Page 60 C H A P T E R 6 Using guest laptops with your interactive flat panel To connect a side laptop 1. Connect an HDMI cable from the side laptop’s HDMI input to your interactive flat panel’s side terminal panel. 2.
-
Page 61: Chapter 7: Maintaining Your Interactive Flat Panel
Updating SMART software Once you have SMART software installed on your computer, you can check for software updates with SMART Product Update by selecting Help > Check for Updates in the software or by browsing to smarttech.com/downloads. smarttech.com/kb/155317... -
Page 62: Updating Your Interactive Flat Panel Firmware
Only a system administrator should update interactive flat panel firmware. Your interactive flat panel uses firmware on its processor. After you update SMART software, a new firmware executable file could save on your computer. When you connect a computer with this file to your interactive flat panel, your interactive flat panel detects this executable file, and then prompts you to run the file to update the firmware. -
Page 63: Updating Smart Product Drivers
3. Follow the on-screen instructions using your computer’s mouse and keyboard. Don’t touch the interactive flat panel screen. 4. Select the check box for the SMART interactive product you want to update, and then click Next. A progress bar appears. -
Page 64: Calibrating Your Interactive Flat Panel
Digital cameras in the corners of the interactive flat panel track the position of the pens, eraser and your finger on the interactive surface, and then send the information to the SMART software, which interprets this information as mouse clicks, digital ink or ink removal in the appropriate location. -
Page 65: Orienting Your Interactive Flat Panel
To prevent damage to your interactive flat panel’s anti-glare coating, replace your pen nib if it becomes worn. Eight replacement pen nibs are included with your pens, and you can purchase additional replacements from your authorized SMART reseller (smarttech.com/where). To replace a pen nib 1. -
Page 66: Cleaning The Screen
C H A P T E R 7 Maintaining your interactive flat panel Cleaning the screen Follow these instructions to clean the interactive flat panel screen without damaging its anti-reflective coating or other product components. C A U T I O N Do not use permanent or dry-erase markers on the screen. -
Page 67: Maintaining Ventilation
1. Remove the humidity source from the interactive flat panel, if possible. 2. Adjust the room temperature to normal operating ranges. 3. Turn on the interactive flat panel for 2–3 hours. If the screen condensation doesn’t evaporate, contact SMART Support (smarttech.com/contactsupport). smarttech.com/kb/155317... -
Page 68: Checking The Interactive Flat Panel Installation
C H A P T E R 7 Maintaining your interactive flat panel Checking the interactive flat panel installation Inspect your interactive flat panel installation frequently to ensure that it remains securely installed. Check the mounting location for signs of damage or weakness that can occur over time. Check for loose screws, gaps, distortions or other issues that could occur with the mounting apparatus. -
Page 69: Transporting Your Interactive Flat Panel
This packaging was designed with optimal shock and vibration protection. If your original packaging isn’t available, you can purchase the same packaging directly from your authorized SMART reseller (smarttech.com/where). C A U T I O N Transport your interactive flat panel only in original or replaced packaging. -
Page 71: Chapter 8: Troubleshooting For Your Interactive Flat Panel
Resolving issues using SMART Board Diagnostics Checking the camera view This chapter provides you with the information necessary to solve simple issues that can occur with your interactive flat panel. If issues persist, or aren’t covered in this chapter, contact SMART Support (smarttech.com/contactsupport). Resolving image issues Complete the following steps if your interactive flat panel doesn’t display an image correctly or... - Page 72 The interactive flat panel detects Install SMART software on your computer green green a computer, but (see page 25) or install a SMART GoWire SMART Product Drivers isn’t cable (see page 50). installed or isn’t running. (For more information, see page 68). Solid...
-
Page 73: Resolving Poor Image Quality
C H A P T E R 8 Troubleshooting for your interactive flat panel Resolving poor image quality Symptom Causes Solution The interactive flat panel’s native resolution is The image is too The computer’s video 1920 × 1080 at 60 Hz. large, too small or resolution settings don’t If your computer can’t support this resolution, doesn’t... - Page 74 C H A P T E R 8 Troubleshooting for your interactive flat panel Symptom Causes Solution Turn off or adjust the overscan/underscan feature The screen The computer’s video card in the video card driver software until the image resolution is is underscanning the fits the screen resolution.
- Page 75 C H A P T E R 8 Troubleshooting for your interactive flat panel Symptom Causes Solution The image is The video connection is Secure the video cable to both your computer and unstable or loose. your interactive flat panel. unfocused.
-
Page 76: Resolving Touch Control And Digital Ink Issues
Use the following troubleshooting table if you can see your computer desktop on your interactive flat panel, but you do not have touch control over the desktop. For more information, see SMART Ink user’s guide for Mac OS X operating system software (smarttech.com/kb/170192) or SMART Ink user’s guide for Windows operating system (smarttech.com/kb/170191). - Page 77 When you touch the screen the You aren’t touching the For more information, see Touching and pointer appears in the wrong screen at right angles. drawing on your SMART Board location. interactive whiteboard is Inaccurate (smarttech.com/kb/131299). Your interactive flat Orient your interactive flat panel. Press...
- Page 78 C H A P T E R 8 Troubleshooting for your interactive flat panel Symptom Causes Solution Your finger or pen is Use consistent pressure while drawing skipping as you draw. digital ink. This is most common on the upstroke. Bright lights are Close blinds or shades or dim all interfering with the...
-
Page 79: Resolving Audio Issues
C H A P T E R 8 Troubleshooting for your interactive flat panel Resolving audio issues I M P O R T A N T Ensure you can see your computer’s desktop and have touch control and digital ink before using this table. -
Page 80: Resolving Remote Control Issues
The remote control batteries Replace the batteries. (For more needs to be replaced. information, see page 31.) The remote control is damaged. Contact your authorized SMART reseller (smarttech.com/where) to inquire about a replacement remote control. Something is plugged into the... -
Page 81: Resolving Issues Using The Smart Connection Wizard
Troubleshooting for your interactive flat panel Resolving issues using the SMART Connection Wizard You can resolve a variety of issues using the SMART Connection Wizard found in SMART Settings. To start the SMART Connection Wizard 1. Press the Help button on the color select module. -
Page 82: Resolving Issues Using Smart Board Diagnostics
If you touch the interactive flat panel’s surface and nothing happens, or if there is no digital ink or the ink appears in some locations and not in others, use SMART Board Diagnostics to help identify and resolve these issues. -
Page 83: Appendix A: Adjusting Video Settings With The On-Screen Display Menu
Appendix A Adjusting video settings with the on-screen display menu Changing settings in the OSD menu Main menu settings Picture settings Adjustment settings Audio settings Schedule settings PIP (Picture in Picture) settings OSD settings Multi-display settings Display protection settings Advanced option settings You can access the on-screen display (OSD) menu using either the remote control (see Infrared remote control buttons on page 33) or the menu control panel on the left side of the interactive flat panel (see Left side view on page 6). -
Page 84: Main Menu Settings
A P P E N D I X A Adjusting video settings with the on-screen display menu 4. Press the up and down arrows to select the setting you want to change. 5. Press SET. 6. Press the left arrow to decrease or the right arrow to increase the value. Press the up arrow or down arrow to select a value. -
Page 85: Adjustment Settings
A P P E N D I X A Adjusting video settings with the on-screen display menu Menu item Function MOVIE SETTING Sets NOISE REDUCTION, FILM MODE and ADAPTIVE CONTRAST. PICTURE MODE Sets picture mode to HIGHBRIGHT, STANDARD, sRGB, CINEMA, AMBIENT1 or AMBIENT2. -
Page 86: Schedule Settings
A P P E N D I X A Adjusting video settings with the on-screen display menu Menu item Function BASS Adjusts the low frequency sound. PIP AUDIO Selects the sound source when in Picture in Picture mode. LINE OUT Selects FIXED or VARIABLE audio line out. -
Page 87: Osd Settings
A P P E N D I X A Adjusting video settings with the on-screen display menu Menu item Function TEXT TICKER Allows text insertion in main screen with the ability to adjust. SUB INPUT Selects sub-picture input signal. PIP RESET Restores the PIP settings to their default values. -
Page 88: Display Protection Settings
A P P E N D I X A Adjusting video settings with the on-screen display menu Menu item Function Allows an image to be expanded and displayed on multiple monitors (up TILING to 100) through a distribution amplifier. N O T E Use a high resolution when tiling an image to multiple monitors. - Page 89 A P P E N D I X A Adjusting video settings with the on-screen display menu Menu item Function HEAT STATUS Displays the FAN, BRIGHTNESS and TEMPERATURE settings. FAN CONTROL Sets the cooling fan to protect the interactive flat panel from overheating.
-
Page 90: Advanced Option Settings
A P P E N D I X A Adjusting video settings with the on-screen display menu Advanced option settings Menu item Function INPUT DETECT Selects the method of input detection the interactive flat panel uses when more than two input devices are connected. Sets input change speed. -
Page 91: Appendix B: Hardware Environmental Compliance
Appendix B Hardware environmental compliance SMART Technologies supports global efforts to ensure that electronic equipment is manufactured, sold and disposed of in a safe and environmentally friendly manner. Waste Electrical and Electronic Equipment regulations (WEEE directive) Electrical and electronic equipment and batteries contain substances that can be harmful to the environment and to human health. -
Page 92: Packaging
Hardware environmental compliance Packaging Many countries have regulations restricting the use of certain heavy metals in product packaging. The packaging used by SMART Technologies to ship products complies with applicable packaging laws. China’s Electronic Information Products regulations China regulates products that are classified as EIP (Electronic Information Products). -
Page 93: Index
46 previous page 44 resizing 42 calibration 56 rotating 43 Chinese regulations 84 zooming in and out 45 cleaning GoWire See SMART GoWire cable camera windows 58 reflective tape 58 screen 58 condensation 59 HDMI connections 8 connection guest laptop 49... - Page 94 51 left-clicking 39 Schedule settings 78 side terminal panel 6 Mac OS X USB audio output 46 SMART Board interactive flat panels 35 menu control panel 6 SMART GoWire cable 50 Multi-display settings 79 SMART Ink 35...
- Page 95 I N D E X updating interactive flat panel firmware 54 SMART Product Drivers 55 SMART software 53 USB receptacle disable 22 video connections 18 WEEE directive 83 wired remote control receptacles 9 zoom 45 smarttech.com/kb/155317...
