HOW TO DO AN AUTOTAKE?

HOME MENU
(extract)
CONTROL
The Autotake function performs a TAKE automatically each time an input is selected.
HOW TO RECORD & DISPLAY A QUICK FRAME?
HOME MENU
(extract)
LOGOS/FRAME
RECORD FRAMES
QUICK FRAME: full and individual frame that can be displayed on top of every layer.
It is possible to store up to 8 frames in the device non volatile memory.
- Select RECORD FRAMES in the frames menu.
- A white rectangle will appear on your Program display, indicating the frame which will be caught and saved. (The Frame can be
captured in Preview too.)
- To select the Quick frame, please go into the SCREEN menu, select QUICK FRAME menu and then choose a Frame slot. The
selected frame will be your QUICK FRAME.
Now to display it, simply press the front panel button
- To remove the QUICK FRAME, press the
TIP: a long press on the BLACK

HOW TO DISABLE THE HDCP ENCRYPTION?

HOME MENU
(extract)
INPUTS
HOME MENU
(extract)
OUTPUT #1
HDCP DETECTION
OUTPUT #2
The HDCP Encryption can be disabled on HDMI/DVI inputs or/and Program Output #1 / Program Output #2. This can be useful
when you have a computer which is detecting the HDCP compliance of your switcher and protecting the content by encrypting the
signal from this computer. This feature will disable the HDCP compliance on this specific HDMI/DVI input only.
If you want to use HDCP content from your sources, be sure to use only HDCP compliant screens or projector. If it's not the case,
the output image could be disabled.
Screen will go to black without displaying the HDCP input image, or partially layer out on HDCP content.
The output status can provide you all information about the output in real time. This feature is particularly useful when HDCP is
used with long cable to be sure the communication is well handled.

HOW TO USE THE AUTO-LOCK FUNCTION?

HOME MENU
(extract)
CONTROL
FUNCTIONS
AUTO-LOCK allows to select an input only if a signal is valid.

WARRANTY AND SERVICE

This Analog Way product has a 3 year warranty on parts and labor, back to factory. This warranty does not include faults resulting
from user negligence, special modifications, electrical surges, abuse (drop/crush), and/or other unusual damage. In the unlikely
event of a malfunction, please contact your local Analog Way office for service.

GOING FURTHER WITH THE SAPHYR

For complete details and operations procedures, please refer to the Saphyr User's Manual and our website for further information:
www.analogway.com
Technical support:
Europe, Middle East & Africa
Tel.: +33 (0)1 81 89 08 76
techsupport@analogway.com
FUNCTIONS AUTOTAKE
FRAME #1 TO #8
QUICK
QUICK FRAME
button will clear all layers on Preview. Press
INPUT # HDMI OR DVI SETTINGS
DISABLED
AUTOMATIC
AUTO-LOCK
The Americas
Tel.: +1 212 269 1902
techsupportusa@analogway.com
ENABLED OR DISABLED
The [Empty] term appears next to all unused slots
FRAME. It becomes solid RED.
button on the front panel. It becomes solid green.
TAKE to view your Program display turn to black.
HDCP ENABLE
ENABLED OR DISABLED
Asia Pacific
Tel.: +65 6292 5800
techsupport@analogwayasia.com
ENABLED OR DISABLED
