- Page 1 OS60 & 50’s Seasons Outdoor Collection Installation Manual OS67, OS65DT, OS65, OS57, OS55DT, OS55...
-
Page 2: Table Of Contents
Table of Contents Introduction Specifications What’s Included Tools & Items Wire Recommendation About Speaker Wire Installing the Wire Wire Routing Tracing the Template & Drilling the Hole Installing the Speaker Connecting the Wire Testing & Adjustments Troubleshooting Technical Assistance Warranty Return Process... -
Page 3: Introduction
OS60 & 50 Series Seasons Outdoor Collection Introduction Thank you for purchasing the Seasons Outdoor OS 60 & 50 Speaker. At Origin Acoustics, we take pride in providing you with a high quality product. All of Origin Acoustics’ speakers are designed to have excellent sound quality, longevity, and a simple installation process. -
Page 4: Specifications
OS60 & 50 Series Seasons Outdoor Collection Specifications MODEL OS67 OS65DT PART OCS6700B, OCS6700W OCS6500DTB, OCS6500DTW Woofer 4 x 8” Glass Fiber, 2 Passive Radiator 4 x 8” IMG, 2 Passive Radiator Tweeter 1” Aluminum 1” Dual Aluminum Frequency Response... - Page 5 OS60 & 50 Series Seasons Outdoor Collection MODEL OS57 OS55DT PART OCS5700B, OCS5700W OCS5500DTB, OCS5500DTW Woofer 5 1/ 4 ” Glass Fiber 5 1/ 4 ” IMG Tweeter 3/ 4 ” Aluminum Dual 3/ 4 ” Aluminum Frequency Response 52Hz-20kHz 63Hz-20kHz Power RMS 50 Watts...
-
Page 6: What's Included
OS60 & 50 Series Seasons Outdoor Collection What’s Included Installation Manual Speaker Bracket & Screws Template Input Connector Tools & Items • Drywall Saw • Measuring Tape • Stud Finder • Speaker Wire • Drill • Fish Tape • Pencil •... -
Page 7: About Speaker Wire
OS60 & 50 Series Seasons Outdoor Collection About Speaker Wire You will need a wire that has at least two conductors; one that can be identified as the positive and the other as the negative. All two conductor wires have some means of identifying which conductor is which, but at times this identification may be subtle. -
Page 8: Installing The Wire
OS60 & 50 Series Seasons Outdoor Collection 1. Installing the Wire When choosing the point where the wire exits the house, remember that it’s best if less wire is exposed to the 0.25 - 0.5” outside elements. Try to find a point (6 - 12mm) in the wall as close to the speaker as possible when drilling a hole for the... -
Page 9: Tracing The Template & Drilling The Hole
OS60 & 50 Series Seasons Outdoor Collection Attic or Basement Under the Carpet When available, you can route the wire One option is to lift up the carpet and through an attic or crawlspace. rout “tape wire” under the carpet. For New Construction If these speakers are being installed in a new home during construction, the installation process will be a bit different (although much simpler). -
Page 10: Installing The Speaker
OS60 & 50 Series Seasons Outdoor Collection 3. Installing the Speaker When you’re finished, hang the speaker on the wall. The speaker is designed to have the tweeter at the top if it’s mounted vertically, or to the outside if mounted horizontally. -
Page 11: Testing & Adjustments
OS60 & 50 Series Seasons Outdoor Collection will be drastically impacted.) Insert the connector into the matching receptacle on the speaker. If it’s difficult to insert the connector because the mounting bracket is in the way, the bracket can be rotated to the side. Simply turn the knobs on the top and bottom counter clockwise to loosen the bracket so it can be moved to the side. -
Page 12: Troubleshooting
OS60 & 50 Series Seasons Outdoor Collection Troubleshooting If possible, it’s often good to try to isolate the problem first. For example, if you’re playing a DVD on a television and there’s no sound, try connecting an MP3 player to the system to see if that works. If it does work, then the problem is with the tele- vision, DVD player, or the cables connecting them. -
Page 13: Technical Assistance
If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return at- tempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process. -
Page 14: Warranty
If the product is determined to be defective, it will be repaired or replaced at Origin Acoustics’ discretion. If the product must be replaced yet it is no longer manufactured, it will be replaced with a model of equal to or greater value that is the most similar to the original. -
Page 15: Return Process
Before making any return attempts, it is required that you first contact Origin Acoustics. Return product to Origin Acoustics or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this isn’t possible, the customer is responsible for insuring the shipment for the full value of the product. - Page 16 OS60 & 50 Series Seasons Outdoor Collection NOTES...
- Page 17 OS60 & 50 Series Seasons Outdoor Collection NOTES...
- Page 18 6975 S Decatur BLVD, Las Vegas, NV 89118 • www.originacoustics.com • 844-674-4461 ©2019 Origin Acoustics. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin Acoustics.
- Page 19 Seasons Outdoor Collection ™ Rock Speakers OSR85 OSR65 OSR8SUB Installation Manual OSR85, OSR65, OSR8SUB...
- Page 20 Seasons Outdoor Collection™ Table of Contents Introduction --------------------------------------------- Models & Specifications ------------------------------ Items Included ------------------------------------------ System Design ------------------------------------------ Tools & Items -------------------------------------------- Speaker Wire -------------------------------------------- Wire Recommendation ------------------------------- Installation ----------------------------------------------- Speaker Placement Connecting the Wires Testing & Adjustments -------------------------------- Maintenance and Care ------------------------------- Troubleshooting ---------------------------------------- Technical Assistance ----------------------------------- Warranty --------------------------------------------------...
-
Page 21: Introduction
At Origin Acoustics, we take pride in providing you with a high quality product. All of Origin Acoustics’ speakers are designed to have excellent sound quality, longevity, and a simple installation process. -
Page 22: Items Included
Seasons Outdoor Collection™ Specifications OSR85 OSR65 Part: OSR8500 Part: OSR6500 Woofer: 8” Injection Polypropylene Woofer: 6” Injection Polypropylene with Rubber Surround with Rubber Surround Tweeter: 1” Titanium Tweeter: 1” Titanium Power RMS: 50 Watts Power RMS: 50 Watts Power Peak: 100 Watts Power Peak: 100 Watts Frequency Response: 40Hz –... -
Page 23: System Design
Seasons Outdoor Collection™ System Design 70V / 8 Ω System 70-volt systems are advantageous when the design calls for multiple speakers from the same amplifier and/or long-distance wire runs. The 70V/8 ohm Rock Collection speakers feature multiple taps off the transformer adjusted by a rotary switch on the bottom side of the speaker. -
Page 24: Tools & Items
Seasons Outdoor Collection™ Tools & Items • Trench Spade/Shovel • Measuring Tape • Speaker Wire/Direct Burial wire • Wire Stripper • Wire Nuts (Included) About Speaker Wire You will need a wire that has at least two conductors; one that can be identified as the positive and the other as the negative. -
Page 25: Installation
Seasons Outdoor Collection™ Installation 1) Speaker Placement Determine the location of your ROCK speakers. Designate the general area where the speakers would be most ideal. The speakers should face the general listening area and be placed at or close to the same distance from that point for good stereo sound. Place the speakers in the location where they will camouflage with your surroundings. - Page 26 Seasons Outdoor Collection™ 5. Run the wire through the trench from your amplifier to the speaker locations. Do not connect the wires to the amplifier at this time. 6. Connect the speaker wires you ran from your amplifier to the wires that came attached to the speakers.
-
Page 27: Testing & Adjustments
Seasons Outdoor Collection™ Testing & Adjustments Turn your amplifier on and test the system with music of your choice. Sound Distribution • Connecting all Rock speakers in Stereo connection gives an even sound distribution of both Left and Right channel at any location. •... -
Page 28: Troubleshooting
Seasons Outdoor Collection™ Troubleshooting If you have a problem, try isolating it first. For example, if you’re playing a DVD and there is no sound, try replacing the DVD with an MP3 player to see if you get sound. If it does work, then the problem is with the television, DVD player, or the cables connecting them. -
Page 29: Technical Assistance
If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return at- tempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process. -
Page 30: Warranty
If the product is determined to be defective, it will be repaired or replaced at Origin Acoustics’ discretion. If the product must be replaced yet it is no longer manufactured, it will be replaced with a model of equal to or greater value that is the most similar to the original. -
Page 31: Return Process
Before making any return attempts, it is required that you first contact Origin Acoustics. Return product to Origin Acoustics or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this isn’t possible, the customer is responsible for insuring the shipment for the full value of the product. - Page 32 6975 S Decatur Blvd, Las Vegas, NV 89118 • www.originacoustics.com • 844-674-4461 ©2019 Origin Acoustics. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin Acoustics.
