PACKAGE CONTENTS
HARDWARE CONTENTS Note: Hardware not shown actual size.
AA
Cross Bar
X1
BB
Mounting Screw
X2
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-800-887-6326
Monday – Friday 9:00 a.m. – 5:00 p.m. CST
A
CC
Wire Connector
X3
DD
Headless Screw
X2
OUTDOOR SENSOR LIGHT
EE
Ball Nut
X2
FF
Lock Nut
X4
Sku Number: 356-4287
Model Number: E4140
GG
Rubber Pad
X2
Page 1 of 6
Advertisement
Table of Contents
Related Manuals for Patriot Lighting E4140
Summary of Contents for Patriot Lighting E4140
- Page 1 Sku Number: 356-4287 OUTDOOR SENSOR LIGHT Model Number: E4140 Questions, problems, missing parts? Before returning to your retailer, call our customer service at 1-800-887-6326 Monday – Friday 9:00 a.m. – 5:00 p.m. CST PACKAGE CONTENTS HARDWARE CONTENTS Note: Hardware not shown actual size.
- Page 2 SAFETY INFORMATION Please read and understand this entire manual before atte mpting to assemble, operate or install the product. WARNING • Turn off electricity at main fuse box (or circuit breaker box) before beginning installation by removing fuse (or switching off circuit breaker).
- Page 3 ASSEMBLY INSTRUCTIONS (continued) 1. Thread two headless screws (DD) 4. Attach the fixture to the cross through the cross bar (AA), and then bar (AA) by inserting headless DD A secure them with four lock nuts (FF) screws (DD) into holes on back (two on each side of the cross bar(AA)).
- Page 4 ASSEMBLY INSTRUCTIONS (continued) ASSEMBLY INSTRUCTIONS (continued) ASSEMBLY INSTRUCTIONS (continued) Step 1: Rotate the sensor lens counterclockwise to show “TIME” Knob up the adjustable knobs and slide switch. “LOW LEVEL” Knob (See Fig.1) “SENS” Knob Flathead Screwdriver Step 2: Use the small flathead screwdriver to adjust time, (not included) low level brightness and sensitivity.
- Page 5 FUNCTION AND OPERATION (continued) CUSTOMIZATION OPTIONS Fig. 5 (View from back of sensor head) Shut-off Delay The Shut-off delay is the length of time the light will stay at high- level brightness after motion has ceased to be detected. This Shut-off delay can be set when operation is in “OFF”, or “AUTO”...
- Page 6 If unable to fix any of the above issues, please consult a certified electrician. FIVE-YEAR LIMITED WARRANTY: If, during normal use, this PATRIOT LIGHTING lighting fixture breaks or fails due to a defect in material workmanship within five (5) years from the date of original purchase, simply bring this lighting fixture with the original sales receipt back to your nearest MENARDS retail store.
