Patriot Lighting E24101BK Manual

Patriot Lighting E24101BK Manual

2-light led outdoor security light
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

PACKAGE CONTENTS
HARDWARE CONTENTS Note: Hardware not shown actual size.
AA
Drywall Screw
X3
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the product.
WARNING
•
Turn off electricity at main fuse box (or circuit breaker box) before beginning installation by removing fuse (or switching
off circuit breaker).
•
Be careful not to damage or cut the wire insulation (covering) during fixture installation. Do not permit wires to contact
any surface having a sharp edge. To do so may damage or cut the wire insulation, which could cause serious injury
or death from electric shock.
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-800-887-6326
Monday – Friday 9:00 a.m. – 5:00 p.m. CST
B
BB
2-Light LED Outdoor Security Light
Anchor
X3
SKU Number: 356-9640
Model Number: E24101BK
A
C
240927

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E24101BK and is the answer not in the manual?

Questions and answers

Related Manuals for Patriot Lighting E24101BK

Summary of Contents for Patriot Lighting E24101BK

  • Page 1 SKU Number: 356-9640 2-Light LED Outdoor Security Light Model Number: E24101BK Questions, problems, missing parts? Before returning to your retailer, call our customer service at 1-800-887-6326 Monday – Friday 9:00 a.m. – 5:00 p.m. CST PACKAGE CONTENTS HARDWARE CONTENTS Note: Hardware not shown actual size.

  • Page 2: Important To Know

    SAFETY INFORMATION (continued) CAUTION • All electrical connections must be in agreement with local codes, ordinances or the national electric code (NEC). Contact your municipal building department to learn about your local codes, permits and/or inspections. • Risk of fire – most dwellings built before 1985 have supply wire rated for 140°F/60ºC. Consult a qualified electrician to ensure correct branch circuit conductor.

  • Page 3: Installation Steps

    ASSEMBLY INSTRUCTIONS (continued) Installation Steps Set Hole 1. Slide off the mounting bracket (B) from 2. Install the mounting bracket (B) to the wall or mounting back of the light fixture (A). surface using anchors (BB) and drywall screws (AA). When mounting to a wall, the "UP"...

  • Page 4: Adjusting The Light Head

    ASSEMBLY INSTRUCTIONS (continued) FUNCTION AND OPERATION ASSEMBLY INSTRUCTIONS (continued) Adjusting the Light Head: Fig.4 Adjust the light head up or down, left or right for desired area. Keep the light heads at least 1˝ (25mm) away from the sensor (See Fig. 4). Choose a mode by sliding the switch on the fixture (See Fig.6).

  • Page 5: Customization Options

    ASSEMBLY INSTRUCTIONS (continued) FUNCTION AND OPERATION (continued) ASSEMBLY INSTRUCTIONS (continued) Customization Options: Fig.10 Shut-off Delay Motion Motion ● The shut-off delay is the length of time the light will stay at brightness after motion is detected. ● You can set the shut-off delay by sliding the Time switch so it points to the desired time setting (30s/60s/120s).
  • Page 6 If unable to fix any of the above issues, please consult a certified electrician. FIVE-YEAR LIMITED WARRANTY: If, during normal use, this PATRIOT LIGHTING lighting fixture breaks or fails due to a defect in material workmanship within five (5) years from the date of original purchase, simply bring this lighting fixture with the original sales receipt back to your nearest MENARDS retail store.
