BT7521
FLAT SCREEN WALL MOUNT
INSTALLATION GUIDE & PARTS LIST
REG. DESIGN NO: 3020005
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Additional Mounting Options.............................................................................................................10
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
INSTALLATION TOOLS REQUIRED
13mm (1/2")
Spanner or socket
B-TECH AUDIO VIDEO MOUNTS
This Pack Contains 1 Mount
PLEASE KEEP THIS FOR FUTURE REFERENCE
CONTENTS
10mm (7/16") masonry bit
Drill
or 6mm (1/4") wood bit
www.btechavmounts.com
FEATURES
● Designed for screens up to 32" (81cm) / 25kg (55lbs)
● Fits screens with VESA mounting patterns:
75mm x 75mm, 100mm x 100mm and 200mm x 100mm
● Low profile design mounts screen only 15mm (0.6")
from wall
● Simple 'hook-on' installation with all mounting
hardware included
Pencil
Stud finder
Level
(optional)
(optional)
Advertisement
Related Manuals for BTECH mountlogic BT7521
Summary of Contents for BTECH mountlogic BT7521
-
Page 1: Table Of Contents
BT7521 FLAT SCREEN WALL MOUNT INSTALLATION GUIDE & PARTS LIST This Pack Contains 1 Mount PLEASE KEEP THIS FOR FUTURE REFERENCE FEATURES ● Designed for screens up to 32” (81cm) / 25kg (55lbs) ● Fits screens with VESA mounting patterns: 75mm x 75mm, 100mm x 100mm and 200mm x 100mm ●... -
Page 2: Installation Safety Notes
INSTALLATION SAFETY INSTRUCTIONS CAUTION: This wall mount is intended for use only with the maximum weights indicated. Use with flat screen heavier than the maximum indicated may result in instability causing possible injury. Do not attempt to install this product until all instructions and warnings have been read and properly understood. - Page 3 Společnost B-Tech International Ltd. doporučuje provést instalaci tohoto produktu prostřednictvím odborného instalátora AV či jinak způsobilé osoby. Společnost B-Tech International Ltd, její distributoři a prodejci nenesou odpovědnost za škody nebo zranění způsobená nevhodnou instalací. Tento výrobek je nutno umístit do vhodné konstrukce a používat jen po uvedenou maximální...
-
Page 4: Parts List
BT7521 PARTS LIST IMPORTANT This mount must be disassembled prior to installation. Suitable for loads up to 25kg (55lbs) - Page 5 PART NAME FLAT SCREEN INTERFACE KIT WALL PLATE (FOR ATTACHING MOUNT TO BACK OF FLAT SCREEN) INTERFACE PLATE M4 X 8mm PIN HEX SECURITY SCREW 2.5mm PIN HEX SECURITY KEY (FOR PARTS 3 & A) INTERFACE KIT M4 X 12mm PIN HEX SECURITY SCREW FIXING KIT WALL FIXING KIT...
-
Page 6: Installation Instructions
THIS MOUNT MUST BE DISASSEMBLED PRIOR TO INSTALLATION INSTALLATION INSTRUCTIONS Fix wall plate to the wall using one of the following methods. i. Brick / concrete walls. 10mm (7/16") masonry bit... - Page 7 ii. Wood / wood stud walls. STUD FINDER (Optional) 6mm (1/4") wood bit...
- Page 8 Attach interface plate to back of the screen. FLAT SCREEN i. Hook screen onto wall plate. FLAT SCREEN WALL...
- Page 9 ii. Secure the screen. FLAT WALL SCREEN OPTIONAL ACCESSORIES B-Tech AV Component Shelves & Cable Management. BT7087 BT7087 BT7070 BT7077 BT7070 BT7078...
-
Page 10: Additional Mounting Options
ADDITIONAL MOUNTING OPTIONS BT7850 BT7052 This product is compatible with the System 2 range of professional install products from B-Tech Pole Installations ii. Vertical Pole i. Horizontal Pole SAMPLE INSTALLATIONS BT7822 BT7822 BT7052 BT7521 BT7260 BT7521 BT7521 BT7850 BT7325 BT4011 BT7052 BT7322 BT4000... -
Page 11: Product Dimensions
BT7521 PRODUCT DIMENSIONS INTERFACE PLATE 100mm 3.9" 114mm 4.5" 100mm 75mm 3.9" 3" 15mm 0.6" 75mm 3" 100mm 3.9" 200mm 7.9" WALL PLATE 24mm 0.9" 14mm 0.3" 0.5" 79mm 3.1" 71mm 214mm 2.8" 8.4" 108mm 4.3" 50mm 2" 20° 24mm 0.9"... -
Page 12: B-Tech Contact Details
www.btechavmounts.com B-TECH AUDIO VIDEO MOUNTS HEAD OFFICE Bennett House, Long March, Daventry, Northants NN11 4NR, UK Email: info@btechavmounts.co.uk EUROPE NORTH AMERICA SINGAPORE ASIA PACIFIC Brixtonlaan 32, Zaventem 1930, 203 Eggert Road, Ruby Industrial Complex, 1503 Prosperity Millennia Plaza, Brussels, Belgium Buffalo, NY 14215, USA Singapore 347740 Quarry Bay, Hong Kong...
