SCANCLIMBER Snake Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Adjustable hinged
platform system
Snake
INSTRUCTION MANUAL
SCANCLIMBER OY
• Turkkirata 26 • FI-33960 PIRKKALA • FINLAND
• Tel. +358 10 680 7000 • Fax +358 10 680 7033 •
V110B_10.13
www.SCANCLIMBER.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Snake and is the answer not in the manual?

Questions and answers

Related Manuals for SCANCLIMBER Snake

Summary of Contents for SCANCLIMBER Snake

  • Page 1 Adjustable hinged platform system Snake INSTRUCTION MANUAL SCANCLIMBER OY • Turkkirata 26 • FI-33960 PIRKKALA • FINLAND • Tel. +358 10 680 7000 • Fax +358 10 680 7033 • V110B_10.13 www.SCANCLIMBER.com...
  • Page 2 CONTENTS SC Snake Pos 0 V110B_10.13 Instruction manual...

  • Page 3: Table Of Contents

    1.2. Snake platform equipment ..............9 1.2.1 Snake root platform, code: PG154856 ..........10 1.2.2 Snake platform section 0,6 m, code: PG154858 ......11 1.2.3 Snake platform section 1,5 m, code: PG154857 ......12 1.2.4 T-adapter platform for SC5000/SC6000/SC8000, code: PG154861 . 13 1.2.5 L-adapter platform for SC5000/SC6000/SC8000 , code: PG104799 .
  • Page 4 3.3.2 Anchoring instructions - mast on Mini chassis ......69 3.3.3 Anchoring forces SC5000 + Snake ..........72 3.3.3.1 Anchoring forces in storm SC5000 + Snake ........ 73 3.3.4 Anchoring forces SC6000 + Snake ..........74 3.3.4.1 Anchoring forces in storm SC6000 + Snake ........ 75 3.3.5 Anchoring forces SC8000 + Snake ..........
  • Page 5 1.2. Snake platform equipment ..............9 1.2.1 Snake root platform, code: PG154856 ..........10 1.2.2 Snake platform section 0,6 m, code: PG154858 ......11 1.2.3 Snake platform section 1,5 m, code: PG154857 ......12 1.2.4 T-adapter platform for SC5000/SC6000/SC8000, code: PG154861 . 13 1.2.5 L-adapter platform for SC5000/SC6000/SC8000 , code: PG104799 .
  • Page 6 SNAKE GENERAL INFORMATION SC Snake Pos 1 V110B_10.13 Instruction manual...

  • Page 7: General Information

    1. GENERAL INFORMATION 1. General description The SCANCLIMBER Snake platform is a versatile able in two lengths: 1,5 m and 0,6 m. The Snake addition to the SCANCLIMBER product range. It platform sections can be adjusted in different is a hinged platform system which can be used...
  • Page 8 Low-weight components do not require special transport or craneage • Robust design, materials and manufacture allows freedom of use in hostile environ- ments • Rapid erection and dismantling reduce over- all production downtime massively SC Snake Pos 1 V110B_10.13 Instruction manual...

  • Page 9: Snake Platform Equipment

    Snake platform section 0,6 m w/o railings Adjustable railing 600-1020 mm Linch pin T-adapter platform, set T-adapter platform w/o railings Adjustable railing 1020-1820 mm Drawing 1.2. SC5000 on wheel chassis with 4,1 m platform and Snake platforms V110B_10.13 SC Snake Pos 1 Instruction manual...

  • Page 10: Snake Root Platform, Code

    SNAKE GENERAL INFORMATION 1.2.1 Snake root platform, code: PG154856 Weight: 113 kg Description Part No. Snake root platform PG141355 Corner railing set SC5000/6000/8000 PG133992 Snake end railing set SC5000/6000/8000 PG133890 SC Snake Pos 1 V110B_10.13 Instruction manual...

  • Page 11: Snake Platform Section 0,6 M, Code

    SNAKE GENERAL INFORMATION 1.2.2 Snake platform section 0,6 m, code: PG154858 Weight: 106 kg Description Part No. Snake platform section 0,6m PG148981 Adjustable railing 330-1030 mm PG151694 Linch pin 12x75 D60 10008994 V110B_10.13 SC Snake Pos 1 Instruction manual...

  • Page 12: Snake Platform Section 1,5 M, Code

    SNAKE GENERAL INFORMATION 1.2.3 Snake platform section 1,5 m, code: PG154857 Weight: 134 kg Description Part No. Snake platform section 1,5m PG148963 Adjustable railing1020-1820 mm PG114499 Linch pin 12x75 D60 10008994 SC Snake Pos 1 V110B_10.13 Instruction manual...

  • Page 13: T-Adapter Platform For Sc5000/Sc6000/Sc8000, Code

    SNAKE GENERAL INFORMATION 1.2.4 T-adapter platform for SC5000/SC6000/SC8000, code: PG154861 Weight: 221 kg No Description Part No. T-adapter platform SC5000/6000/8000 PG151369 Adjustable railing1020-1820 mm PG114499 V110B_10.13 SC Snake Pos 1 Instruction manual...

  • Page 14: L-Adapter Platform For Sc5000/Sc6000/Sc8000 , Code

    SNAKE GENERAL INFORMATION 1.2.5 L-adapter platform for SC5000/SC6000/SC8000 , code: PG104799 2130 Weight: 59 kg ☞ NOTE! Max. 2,1m Snake platform can be mounted onto L-adapter (1x1,5m + 1x0,6m Snake platform sections) SC Snake Pos 1 V110B_10.13 Instruction manual...

  • Page 15: Warranty Terms

    SNAKE GENERAL INFORMATION 1.3 Warranty terms The seller warrants that a new SCANCLIMBER mast climbing work plat form is supplied free from defects in material and work manship. The warranty is valid for six (6) months from the date of delivery.
  • Page 16 SNAKE GENERAL INFORMATION SC Snake Pos 1 V110B_10.13 Instruction manual...
  • Page 17 2. Safety regulations and loading tables .........19 2.1 Notes ....................19 2.2 Safety rules ..................19 2.3 Loading tables SC5000 + Snake ............23 2.3.1 Loading tables, SC5000 + Snake ............. 24 2.4 Loading tables SC6000 + Snake ............33 2.3.1 Loading tables, SC6000 + Snake .............
  • Page 18 SNAKE SAFETY INSTRUCTIONS V110B_10.13 SC Snake Pos 2 Instruction manual...

  • Page 19: Safety Regulations And Loading Tables

    Snake platform. If a storm arises, stop working immediately drive the platform down, switch off the elec­ It is forbidden to adjust the Snake platform tricity and disconnect the power supply ca­ section when they are loaded.
  • Page 20 When leaving the worksite, unplug the pow­ er cable. V110B_10.13 SC Snake Pos 2 Instruction manual...
  • Page 21 ☞ NOTE! Be careful when driving up or down. Watch the area around the platform. Be careful when adjust- ing the Snake platform horizontally. Do not hit the platform in the other objects. ☞ NOTE! There must not be any ob- stacles on the way of the platform.
  • Page 22 NOTE! Raising the platform above the last anchor is not allowed last anchor ☞ NOTE! Do not use the platform as freestanding. The mast has to be anchored. ☞ NOTE! Use only Scanclimber Maxi- anchors. V110B_10.13 SC Snake Pos 2 Instruction manual...

  • Page 23: Loading Tables Sc5000 + Snake

    Snake with 2x1500mm sections • Loading table 5, Snake with 2x1500mm sections • Loading table 6, L­adapter , Snake with 1x600mm + 1x1500mm sections • Loading table 7, L­adapter , Snake with 1x600mm + 1x1500mm sections • Loading table 8, L­adapter , Snake with 1x600mm + 1x1500mm sections...

  • Page 24: Loading Tables, Sc5000 + Snake

    SNAKE SAFETY INSTRUCTIONS 2.3.1 Loading tables, SC5000 + Snake • TABLE 1 allowed layouts for SC5000 PG111640 and SC5000 PG127033 platforms • end mounting • Snake with 4x1500mm sections Loading total max. 1200kg consist of: • 3 persons 320kg •...
  • Page 25 Loading total max. 1400kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1080kg • on each Snake platform set max. 2 persons 240kg Loading total max. 1300kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 980kg •...
  • Page 26 Loading total max. 1000kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 680kg • on each Snake platform set max. 2 persons 240kg Loading total max. 900kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 580kg •...
  • Page 27 Loading total max. 1800kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1480kg • on each Snake platform set max. 3 persons 320kg Loading total max. 1800kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1480kg •...
  • Page 28 Loading total max. 1200kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 880kg • on each Snake platform set max. 3 persons 320kg Loading total max. 1200kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 880kg •...
  • Page 29 TABLE 6 • allowed layouts forSC5000 PG111640 and SC5000 PG127033 platforms • L­adapter mounting main platform • Snake with 1x600mm + 1x1500mm sections L­adapter root platform platform section 0,6m platform section 1,5m Loading total max. 1800kg consist of: • 3 persons 320kg •...
  • Page 30 TABLE 7 • allowed layouts for SC5000 PG111640 and SC5000 PG127033 platforms main platform • L­adapter mounting • Snake with 1x600mm + 1x1500mm sections L­adapter root platform platform section 0,6m platform section 1,5m Loading total max. 1500kg consist of: •...
  • Page 31 TABLE 8 • allowed layouts for SC5000 PG111640 and SC5000 PG127033 platforms main platform • L­adapter mounting • Snake with 1x600mm + 1x1500mm sections L­adapter root platform platform section 0,6m platform section 1,5m Loading total max. 1100kg consist of: •...
  • Page 32 TABLE 9 • allowed layouts for SC5000 PG111640 and SC5000 PG127033 platforms • T­adapter mounting • Snake with 3x1500mm + 2x1500mm sec­ tions T­adapter root platform platform section 1,5 m platform section 1,5 m Loading total max. 320kg consist of: •...

  • Page 33: Loading Tables Sc6000 + Snake

    Snake with 2x1500mm sections • Loading table 5, Snake with 2x1500mm sections • Loading table 6, L­adapter , Snake with 1x600mm + 1x1500mm sections • Loading table 7, L­adapter , Snake with 1x600mm + 1x1500mm sections • Loading table 8, L­adapter , Snake with 1x600mm + 1x1500mm sections...

  • Page 34: Loading Tables, Sc6000 + Snake

    SNAKE SAFETY INSTRUCTIONS 2.3.1 Loading tables, SC6000 + Snake • TABLE 1 allowed layouts for SC6000 platform • end mounting • Snake with 4x1500mm sections Loading total max. 1700kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1380kg •...
  • Page 35 Loading total max. 1900kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1580kg • on each Snake platform set max. 2 persons 240kg Loading total max. 1800kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1480kg •...
  • Page 36 Loading total max. 1400kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1080kg • on each Snake platform set max. 2 persons 240kg Loading total max. 1300kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 980kg •...
  • Page 37 Loading total max. 2300kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1980kg • on each Snake platform set max. 3 persons 320kg Loading total max. 2300kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1980kg •...
  • Page 38 Loading total max. 1700kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1380kg • on each Snake platform set max. 3 persons 320kg Loading total max. 1600kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1280kg •...
  • Page 39 SNAKE SAFETY INSTRUCTIONS TABLE 6 • allowed layouts for SC6000 platform • L­adapter mounting main platform • Snake with 1x600mm + 1x1500mm sections L­adapter root platform platform section 0,6m platform section 1,5m Loading total max. 2300kg consist of: • 3 persons 320kg •...
  • Page 40 SNAKE SAFETY INSTRUCTIONS TABLE 7 • allowed layouts for SC6000 platform • L­adapter mounting main platform • Snake with 1x600mm + 1x1500mm sections L­adapter root platform platform section 0,6m platform section 1,5m Loading total max. 2000kg consist of: • 3 persons 320kg •...
  • Page 41 SNAKE SAFETY INSTRUCTIONS TABLE 8 • allowed layouts for SC6000 platform main platform • L­adapter mounting • Snake with 1x600mm + 1x1500mm sections L­adapter root platform platform section 0,6m platform section 1,5m Loading total max. 1600kg consist of: • 3 persons 320kg •...
  • Page 42 SNAKE SAFETY INSTRUCTIONS TABLE 9 • allowed layouts for SC6000 platform • T­adapter mounting • Snake with 3x1500mm + 2x1500mm sections T­adapter root platform platform section 1,5 m platform section 1,5 m Loading total max. 600kg consist of: • 3 persons 320kg •...

  • Page 43: Loading Tables Sc8000 + Snake

    L­adapter , Snake with 1x600mm + 1x1500mm sections • Loading table 9, T­adapter , Snake with 3x1500mm and 1x1500mm sections • Loading table 10, T­adapter , Snake with 4x1500mm and 3x1500mm sections • Loading table 11, T­adapter , Snake with 4x4x1500mm sections V110B_10.13 SC Snake Pos 2...

  • Page 44: Loading Tables, Sc8000 + Snake

    SNAKE SAFETY INSTRUCTIONS 2.5.1 Loading tables, SC8000 + Snake • TABLE 1 allowed layout for SC8000 platform • end mounting • Snake with 4x1500mm sections Loading total max. 2300kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1980kg •...
  • Page 45 Loading total max. 2600kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 2280kg • on each Snake platform set max. 2 persons 240kg Loading total max. 2400kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 2080kg •...
  • Page 46 Loading total max. 2200kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1880kg • on each Snake platform set max. 2 persons 240kg Loading total max. 2000kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1680kg •...
  • Page 47 Loading total max. 3000kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 2680kg • on each Snake platform set max. 3 persons 320kg Loading total max. 3000kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 2680kg •...
  • Page 48 Loading total max. 2400kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 2080kg • on each Snake platform set max. 3 persons 320kg Loading total max. 2300kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 1980kg •...
  • Page 49 SNAKE SAFETY INSTRUCTIONS TABLE 6 main platform • allowed layouts for SC8000 platform • L­adapter mounting • Snake with 1x600mm + 1x1500mm sections L­adapter root platform platform section 0,6m platform section 1,5m Loading total max. 2900kg consist of: • 3 persons 320kg •...
  • Page 50 SNAKE SAFETY INSTRUCTIONS TABLE 7 main platform • allowed layouts for SC8000 platform • L­adapter mounting • Snake with 1x600mm + 1x1500mm sections L­adapter root platform platform section 0,6m platform section 1,5m Loading total max. 2700kg consist of: • 3 persons 320kg •...
  • Page 51 TABLE 8 main platform • allowed layouts for SC8000 platform • L­adapter mounting • L­adapter Snake with 1x600mm + 1x1500mm sections root platform platform section 0,6m platform section 1,5m Loading total max. 2200kg consist of: • 3 persons 320kg •...
  • Page 52 SNAKE SAFETY INSTRUCTIONS TABLE 9 • allowed layouts for SC8000 platform • T­adapter mounting T­adapter • Snake with 3x1500mm + 2x1500mm sections root platform platform section 1,5 m platform section 1,5 m Loading total max. 1000kg consist of: • 3 persons 320kg •...
  • Page 53 680kg • on two upper arc shaped Snake platform set max. 2 persons 240kg ☞ NOTE ! Lower Snake sets are only for counter weights. No persons al- lowed there. V110B_10.13 SC Snake Pos 2 Instruction manual...
  • Page 54 1,5 m platform section 1,5 m Loading total max. 400kg consist of: • 3 persons 320kg • uniformly distributed loading on hatched area 80kg • max. 2 persons 240kg on each Snake set(wing arc) V110B_10.13 SC Snake Pos 2 Instruction manual...

  • Page 55: Instruction And Warning Decals

    Anchorage instruction, mast on Wheel hassis Ta227 Caution Anchorage instruction, mast on Mini chassis T197 Snake platform loading T504 Read instruction manual T_Snake 1 Warning Warning label 1 T_Snake 2 Warning Warning label 2 V110B_10.13 SC Snake Pos 2 Instruction manual...
  • Page 56 - Do not work if your physical condition is not well or you have a fear of heights - Prevent unauthorized use of platform - Carry out the daily inspections - Report on all faults Ta103 Snake V110B_10.13 SC Snake Pos 2 Instruction manual...
  • Page 57 FORCES F1 AND F2 FROM THE INSTRUCTION MANUAL NOTE! CHECK THE STRENGTH OF THE WALL ANCHORING ALL OUTRIGGERS FULLY EXTENDED AND OPPOSITE TO THE MAST ALSO TURNED OUT USE ALWAYS MIDDLE JACK Ta225_SNAKE V110B_10.13 SC Snake Pos 2 Instruction manual...
  • Page 58 MAX. ALLOWED WIND SPEED 15,5 m/s WHEN OPERATING SECTION A - A NOTE! CHECK THE ANCHORING FORCES F1 AND F2 FROM THE INSTRUCTION MANUAL NOTE! CHECK THE STRENGTH OF THE WALL ANCHORING Ta227_SNAKE V110B_10.13 SC Snake Pos 2 Instruction manual...
  • Page 59 SNAKE SAFETY INSTRUCTIONS V110B_10.13 SC Snake Pos 2 Instruction manual...
  • Page 60 SNAKE SAFETY INSTRUCTIONS WARNING ! T_Snake 1 V110B_10.13 SC Snake Pos 2 Instruction manual...
  • Page 61 SNAKE SAFETY INSTRUCTIONS WARNING ! last anchor RAISING THE PLATFORM ABOVE THE LAST ANCHOR IS NOT ALLOWED DO NOT USE THE PLATFORM AS A FREESTANDING THE MAST HAS TO BE ANCHORED T_Snake 2 V110B_10.13 SC Snake Pos 2 Instruction manual...
  • Page 62 SNAKE SAFETY INSTRUCTIONS V110B_10.13 SC Snake Pos 2 Instruction manual...
  • Page 63 3.3.2 Anchoring instructions - mast on Mini chassis ......69 3.3.3 Anchoring forces SC5000 + Snake ..........72 3.3.3.1 Anchoring forces in storm SC5000 + Snake ........ 73 3.3.4 Anchoring forces SC6000 + Snake ..........74 3.3.4.1 Anchoring forces in storm SC6000 + Snake ........ 75 3.3.5 Anchoring forces SC8000 + Snake ..........
  • Page 64 SNAKE ERECTION V110B_10.13 SC Snake Pos 3 Instruction manual...

  • Page 65: Erection

    What kind of work is going to be done and for what purpose the MCWP will be used. Exact locations of the machines and outriggers. The needed loading capacity of Snake plat- form, height and size of the working area. Distance from the wall and suitable anchors.

  • Page 66: Tools

    Wedge anchors for wall anchor fastenings • Iron bar • Shovel • Level eye • Socket wrench 24mm • Ratchet drill 3.2.3 Tightening torques Mast section bolts 350 Nm Platform section bolts 240 Nm Mast rollers 200 Nm V110B_10.13 SC Snake Pos 3 Instruction manual...

  • Page 67: Wall Anchoring

    Anchoring forces appearing on one an- choring set ( anchoring dis tance 18 m) is shown on the following drawings. See the figures of A/B and F1/F2 on the fol- lowing tables. Drawing 3.3. Anchoring forces. V110B_10.13 SC Snake Pos 3 Instruction manual...

  • Page 68: Anchoring Instructions - Mast On Wheel Chassis

    SNAKE ERECTION 3.3.1 Anchoring instructions - mast on Wheel chassis RAISING THE PLATFORM ABOVE THE LAST ANCHOR IS NOT ALLOWED NOTE! USE ONLY MAXIANCHORS NOTE! CHECK THE STRENGHT OF WALL ANCHORING V110B_10.13 SC Snake Pos 3 Instruction manual...

  • Page 69: Anchoring Instructions - Mast On Mini Chassis

    SNAKE ERECTION 3.3.2 Anchoring instructions - mast on Mini chassis NOTE! USE ONLY MAXIANCHORS 4,1m RAISING THE PLATFORM ABOVE THE LAST ANCHOR IS NOT ALLOWED NOTE! CHECK THE STRENGHT OF WALL ANCHORING V110B_10.13 SC Snake Pos 3 Instruction manual...
  • Page 70 SNAKE ERECTION PT100484 Drawing 3.5. Maxianchor. PG124119 Drawing 3.6. Maxianchor with longer pipe set. V110B_10.13 SC Snake Pos 3 Instruction manual...
  • Page 71 SNAKE ERECTION PG111528 Drawing 4.7. Vertically adjustable Maxianchor. V110B_10.13 SC Snake Pos 3 Instruction manual...

  • Page 72: Anchoring Forces Sc5000 + Snake

    SNAKE ERECTION 3.3.3 Anchoring forces SC5000 + Snake The tables below show the anchoring forces F1 and F2 for SC5000 PG111640+ Snake and SC5000 PG127033 + Snake with anchored mast. The used anchor is Maxianchor, and anchoring spaces are according to the anchoring instructions. The an- choring forces indicate how much one anchoring ☞...

  • Page 73: Anchoring Forces In Storm Sc5000 + Snake

    SNAKE ERECTION 3.3.3.1 Anchoring forces in storm SC5000 + Snake • max. wind speed 42 m/s • platform down, out of service • anchoring distance 18 m ☞ NOTE ! Do not use the A/B combi- nations with empty values in the table.

  • Page 74: Anchoring Forces Sc6000 + Snake

    SNAKE ERECTION 3.3.4 Anchoring forces SC6000 + Snake The tables below show the anchoring forces F1 and F2 for SC6000 + Snake with anchored mast. The used anchor is Maxianchor, and anchoring spaces are according to the anchoring instruc- tions. The anchoring forces indicate how much ☞...

  • Page 75: Anchoring Forces In Storm Sc6000 + Snake

    SNAKE ERECTION 3.3.4.1 Anchoring forces in storm SC6000 + Snake • max. wind speed 42 m/s • platform down, out of service • anchoring distance 18 m ☞ NOTE ! Do not use the A/B combi- nations with empty values in the table.

  • Page 76: Anchoring Forces Sc8000 + Snake

    SNAKE ERECTION 3.3.5 Anchoring forces SC8000 + Snake The tables below show the anchoring forces F1 and F2 for SC8000 + Snake with anchored mast. The used anchor is Maxianchor, and anchoring spaces are according to the anchoring instruc- tions. The anchoring forces indicate how much one anchoring wall bracket has to hold.

  • Page 77: Anchoring Forces In Storm Sc8000 + Snake

    SNAKE ERECTION 3.3.5.1 Anchoring forces in storm SC8000 + Snake • max. wind speed 42 m/s • platform down, out of service • anchoring distance 18 m ☞ NOTE ! Do not use the A/B combi- nations with empty values in the table.

  • Page 78: Snake Platform Adjustment

    Angle of each platform section can be adjusted steplessly ± 45 degrees. The adjustment can be made safely at any height. To left and right ± 45 degrees Drawing 3.4.1 Snake platform adjustment. V110B_10.13 SC Snake Pos 3 Instruction manual...
  • Page 79 SNAKE ERECTION socket wrench 24mm ratchet ☞ NOTE! Do not damage the worm screws during the platform assem- bly. V110B_10.13 SC Snake Pos 3 Instruction manual...
  • Page 80 SNAKE ERECTION Connection of each platform must be secured with linch pin. V110B_10.13 SC Snake Pos 3 Instruction manual...

  • Page 81: Safety Harness

    250mm and railings are not used. Each platform section has a safety harness fasten- ing ring. Fasten the safety harness to these rings. Safety harness fastening ring. V110B_10.13 SC Snake Pos 3 Instruction manual...

  • Page 82: L-Adapter Assembly

    SNAKE ERECTION 3.6 L-Adapter assembly main platform root platform platform section 0,6m platform section 1,5m L-adapter L-adapter Drawing 3.6.1 Snake platform mounted with L-adapter to SC5000 V110B_10.13 SC Snake Pos 3 Instruction manual...
  • Page 83 SNAKE ERECTION L-adapter V110B_10.13 SC Snake Pos 3 Instruction manual...

  • Page 84: T-Adapter Assembly

    SNAKE ERECTION 3.7 T-Adapter assembly T-adapter root platform platform section 1,5 m platform section 1,5 m T-adapter Drawing 3.7.1 Snake platform mounted with T-adapter to SC5000 V110B_10.13 SC Snake Pos 3 Instruction manual...
  • Page 85 SNAKE ERECTION T-adapter chassis outrigger T-adapter chassis outrigger ☞ When using T-adapter, chassis out- riggers should be fully extended (otherwise T-adapter can destroy chassis jack). chassis outrigger fully extended V110B_10.13 SC Snake Pos 3 Instruction manual...
