SCANCLIMBER LT500 Instruction Manual

Lifting table
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Lifting table
LT500
INSTRUCTION MANUAL
LT500 SERIAL NO:________
OY SCANINTER NOKIA LTD
• Turkkirata 26 • FI-33960 PIRKKALA, FINLAND •
• TEL. +358 10 680 7000 • FAX. +358 10 680 7033 •
V24_06.04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT500 and is the answer not in the manual?

Questions and answers

Related Manuals for SCANCLIMBER LT500

Summary of Contents for SCANCLIMBER LT500

  • Page 1 Lifting table LT500 INSTRUCTION MANUAL LT500 SERIAL NO:________ OY SCANINTER NOKIA LTD • Turkkirata 26 • FI-33960 PIRKKALA, FINLAND • • TEL. +358 10 680 7000 • FAX. +358 10 680 7033 • V24_06.04...
  • Page 2 I n s t r u c t i o n m a n u a l V24_06.04 LT500...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS LIFTING TABLE LT500 ..............General information ..........3 Technical data ............4 2.1 Capacity ................4 2.2 Technical measures and weights ........4 2.3 Electrical data ..............4 2.4 Technical data of electrical chain winch, optional ..4 Components ............... 5 Instruction and warning decals ........
  • Page 4 I n s t r u c t i o n m a n u a l V24_06.04 LT500...

  • Page 5: Lifting Table Lt500

    LIFTING TABLE LT500 1. General information The lifting table LT500 can be used for transporting material to a height of 0,3 - 1,6 meters. The maximum load capacity is 500 kg. The lifting table is set to a desired position with jacks (4). The loading procedu- re is carried out through a loading bridge.

  • Page 6: Technical Data

    2.4 Technical data of electrical chain winch, optional Power supply 400 VAC, 50 Hz Motor power 0,64 kW Current 1,14 A Lifting speed 0,1 m/s I n s t r u c t i o n m a n u a l V24_06.04 LT500...

  • Page 7: Components

    3. Components LT500_2 PARTS LIST LT500 Frame PG104992 Telescopic beam PG104648 Platform complete PG104995 Wheel complete PG104639 Jack 07010100 Electrical chain winch, optional CPM 6-6 YALE 50723096 Loading bridge PG105091 Railing PG105020 LT500_4 Roller complete PG104994 Grid PG105086 Grid PG104553 V24_06.04...

  • Page 8: Instruction And Warning Decals

    4. Instruction and warning decals LIFTING TABLE T01_LT500 500 kg T 0 2 _ L T 5 0 0 I n s t r u c t i o n m a n u a l V24_06.04 LT500...
  • Page 9 T03_LT500 V24_06.04 I n s t r u c t i o n m a n u a l LT500...

  • Page 10: Electric Drawing

    5. Electric drawing I n s t r u c t i o n m a n u a l V24_06.04 LT500...
