Multitech RBS3010NA0EBN0 User Manual page 18

COMMON MESSAGES
Refer to the Battery Estimator for battery life estimates relative to sampling rate:
https://radiobridge.com/documents/Sensor%20Battery%20Estimator.xlsx
A value of 0 in this field leaves the sampling rate at the current value. Use the following table to determine the
sampling rate if the value is not zero.
Note: Sampling period only applies to sensors that take measurements like temperature and tilt, it does not
apply to sensors with binary inputs such as door/window sensors or push buttons.
This feature is available in firmware v2.0 and above.
Bit 7:6
00
01
10
11
18
Bits 5:0
Sampling period defined in increments of 250ms (0.25-15 seconds).
Sampling period defined in increments of seconds (1-63 seconds).
Sampling period defined in increments of minutes (1-63 minutes).
Sampling period defined in increments of hours (1-63 hours).
Radio Bridge LoRaWAN
®
Wireless Sensor Air Temperature Humidity Sensor User Guide
