Disable Sensor Events
The following table shows the disable sensor event bit definitions.
Bit Description
7:1 Not used
0 Disable all sensor events
Radio Config
The following table shows the radio config byte definition.
Note: Available in firmware version 1.4 or newer.
Bits Description
7 Not used (reserved)
6 Enable duty cycle requirement. EU868 only. To enforce the EU868 band duty cycle requirements,
enable before production deployment. Cannot be disabled. Available in firmware 2.2.1 or later.
5:2 Uplink retries. . The range for uplink retries is 1-8 for confirmed messages (ACK required) and does
not apply to unconfirmed messages. Default 0 (leave unchanged). Available in firmware v1.4 and
above.
1 Use unconfirmed messages. If set to use the unconfirmed messages bit, the sensor does not look
for an ACK from the network server. Default is 1 (unconfirmed messages, no ACK required). EU
sensors can't use confirmed messages, setting this bit to 0 on an EU device causes an invalid
downlink error (0xFF01). Available in firmware v1.4 and above.
0 Disable Adaptive Data Rate (ADR). To enable ADR, set to 0. To disable ADR, set to 1. Default is 0
(enabled). Available in firmware v1.3 and above.
Important: The duty cycle bit is always set for production deployments in the EU868 band. It cannot be
changed.
Supervisory Period
The general configuration command's supervisory period controls the time between supervisory messages as
defined in the following table.
Bit 7 Bits 6:0
0 Period defined in hours (1-127 hours). Available in firmware v1.3 and above.
1 Period defined in minutes (1-127 minutes) Available in firmware v1.3 and above.
For example, to receive a report every 4 hours, set Byte 1 to 0x04. To receive a periodic report every 15 minutes,
set Byte 1 to 0x8f.
Sampling Rate
Sampling rate controls the frequency at which devices wake from low power sleep mode to check the sensor state.
Some sensors require very little power to check the state and need to react quickly. Other sensors can be sampled
at a lower rate, such 30-second or 30-minute intervals. Increasing the time between samples increases battery life.
®
