Autel MaxiDAS DS808S Manual
Hide thumbs Also See for MaxiDAS DS808S:

Advertisement

Quick Links

Trademarks
®
®
Autel
, MaxiSys
, MaxiDAS
®
MaxiCheck
are trademarks of Autel Intelligent Technology Corp., Ltd., registered in
China, the United States and other countries. All other marks are trademarks or
registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise
without the prior written permission of Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on the latest
information available at the time of printing.
Autel reserves the right to make changes at any time without notice. While information of
this manual has been carefully checked for accuracy, no guarantee is given for the
completeness and correctness of the contents, including but not limited to the product
specifications, functions, and illustrations.
Autel will not be liable for any direct, special, incidental, indirect damages or any
economic consequential damages (including the loss of profits).
IMPORTANT
Before operating or maintaining this unit, please read this manual carefully, paying extra
attention to the safety warnings and precautions.
For Services and Support
pro.autel.com
www.autel.com
1-855-288-3587 (North America)
+86 (0755) 8614-7779 (China)
support@autel.com
For technical assistance in all other markets, please refer to
manual.
®
®
, MaxiScan
, MaxiTPMS
i
®
®
, MaxiRecorder
, MaxiCOM
Technical Support
®
, and
in this

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MaxiDAS DS808S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Autel MaxiDAS DS808S

  • Page 1 All information, specifications and illustrations in this manual are based on the latest information available at the time of printing. Autel reserves the right to make changes at any time without notice. While information of this manual has been carefully checked for accuracy, no guarantee is given for the completeness and correctness of the contents, including but not limited to the product specifications, functions, and illustrations.
  • Page 2: Safety Messages

    Safety Instructions The safety messages herein cover situations Autel is aware of. Autel cannot know, evaluate or advise you as to all of the possible hazards. You must be certain that any condition or service procedure encountered does not jeopardize your personal safety.
  • Page 3 DANGER When an engine is operating, keep the service area WELL VENTILATED or attach a building exhaust removal system to the engine exhaust system. Engines produce carbon monoxide, an odorless, poisonous gas that causes slower reaction time and can lead to serious personal injury or loss of life.
  • Page 4: Table Of Contents

    CONTENTS ......................AFETY NFORMATION ........................ AFETY ESSAGES ......................AFETY NSTRUCTIONS USING THIS MANUAL....................1 ......................1 ONVENTIONS GENERAL INTRODUCTION ..................3 DAS DS808S T ..................3 ABLET ..................5 ECHNICAL PECIFICATIONS ......................7 CCESSORY GETTING STARTED ....................8 ........................ 8 OWER ......................
  • Page 5 (DPF) S ................ 42 IESEL ARTICLE ILTER ERVICE (TPMS) S ............43 RESSURE ONITOR YSTEM ERVICE (IMMO) S .................. 43 MMOBILIZER ERVICE OEM AUTHORIZATION ................... 45 DATA MANAGER ....................46 ..................... 46 EHICLE ISTORY ..................48 ORKSHOP NFORMATION ......................49 USTOMER ........................
  • Page 6 10.2 ..................62 UPPORT CREEN AYOUT REMOTE DESKTOP ....................64 MAXIVIEWER ..................... 66 QUICK LINK ......................68 MAXIVIDEO ......................69 14.1 ..................70 DDITIONAL CCESSORIES 14.2 ......................73 PERATIONS MAINTENANCE AND SERVICE ................75 15.1 ................. 75 AINTENANCE NSTRUCTIONS 15.2 ................
  • Page 7: Using This Manual

    Using this Manual This manual contains device usage instructions for the Autel MaxiDAS DS808S. Some illustrations shown in this manual may contain modules and optional equipment that are not included in your system. Conventions The following conventions are used: Bold Text Bold text is used to highlight selectable items such as buttons and menu options.
  • Page 8 Hyperlinks Hyperlinks are available in electronic documents. Blue italic text indicates a selectable hyperlink and blue underlined text indicates a website link or an email address link. Illustrations Illustrations used in this manual are samples, the actual testing screen may vary for each vehicle being tested.
  • Page 9: General Introduction

    General Introduction When it comes to ultra-portability, MaxiDAS DS808S is your perfect companion. Installed with a fast quad-core processor, DS808S offers maximum convenience and swift diagnosis. The intuitive user screen makes using the device effortless through a 7-inch LCD touchscreen that displays at 1024 x 600 quality. Together with the ability to quickly...
  • Page 10 A. Green ⚫ Illuminates green when the tablet is charging and the battery level is above 90%. ⚫ Illuminates green when the tablet is powered on and the battery level is above 15%. B. Yellow ⚫ Illuminates yellow when the tablet is charging and the battery level is below 90%. C.
  • Page 11: Technical Specifications

    2.1.2 Power Sources The tablet can receive power from any of the following sources: Internal battery pack ⚫ Vehicle power ⚫ External power supply ⚫ 2.1.2.1 Internal Battery Pack The tablet can be powered via the internal rechargeable battery, which if fully charged can provide sufficient power for about 7 hours of continuous use.
  • Page 12 Item Description Input: N/A ⚫ Audio Input/Output Output: buzzer ⚫ 3.7 V/5000 mAh lithium-polymer battery ⚫ Power and Battery Charges via 5 V DC power supply ⚫ Tested Battery Life Around 7 hours of continuous use Battery Charging Input 5 V/2 A 500 mA (LCD on with default brightness, Wi-Fi on) Power Consumption @ 3.7 V...
  • Page 13: Accessory Kit

    2.3 Accessory Kit Main Cable Connects the tablet to the vehicle’s ODBII port (DLC). Mini USB Cable Connects the tablet to the computer or power adapter. Power Adapter Together with the mini USB cable, connects the tablet to the external DC power port for power supply.
  • Page 14: Getting Started

    Getting Started Ensure the tablet is sufficiently charged or is connected to an external power supply (see Power Sources). Power Up Press and hold the Power/Lock button on the top-right of the tablet to power on the unit. The power LED will illuminate green. The system boots up and displays the lock screen. Slide the Lock icon up to unlock.
  • Page 15 Accesses the system settings menu and general Settings tablet menu. See Settings. Accesses system software update menu. Update See Update. Synchronizes Autel's online service database with Support the MaxiDAS tablet. See Support. Configures your unit to receive remote support using Remote the TeamViewer application.
  • Page 16 3.1.2 Locator and Navigation Buttons Operations of the Navigation buttons at the bottom of the screen are described in the table below: Table 3-2 Locator and Navigation Buttons Button Name Description Indicates the location of the current screen. Locator Swipe left or right to view the previous or next screen.
  • Page 17: Power Down

    Power Down All vehicle communications should be terminated before shutting down the tablet. A warning message displays if a shutdown is attempted while the tablet is communicating with the vehicle. Forcing a shutdown while the tablet is communicating with the vehicle may lead to ECU problems on some vehicles.
  • Page 18: Diagnostics

    Diagnostics The Diagnostics application can access the electronic control unit (ECU) for various vehicle control systems, including engine, transmission, antilock brake system (ABS), airbag system (SRS). Getting Started Prior to first using of the Diagnostics application, ensure a communication link is established between the tablet and the test vehicle via the main cable.
  • Page 19 Top Toolbar Buttons The operations of the toolbar buttons at the top of the screen are listed and described in the table below: Table 4-1 Top Toolbar Buttons Button Name Description Home Returns to the MaxiDAS Job Menu. Tap to display a dropdown list. Tap Auto Detect VID Scan for auto VIN detection;...
  • Page 20: Vehicle Identification

    Vehicle Identification The MaxiDAS diagnostics system supports four methods of Vehicle Identification. Auto VIN Scan Manual Input Automatic Selection Manual Vehicle Selection 4.2.1 Auto VIN Scan The MaxiDAS diagnostics system features the latest VIN-based Auto VIN Scan function to identify vehicles with just one tap, enabling you to quickly identify the exact vehicle and scan its available systems for fault codes.
  • Page 21 Figure 4-3 Auto Detect Screen Tap Yes to confirm the vehicle profile or No if the information is not correct. Figure 4-4 Vehicle Profile Confirmation Screen The tablet will establish communication with the vehicle and read the control unit information. Choose Auto Scan to scan all the available systems or tap Control Unit to access a specific system to diagnose.
  • Page 22 Figure 4-5 Diagnostic Menu Screen 4.2.2 Manual Input For vehicles that do not support the Auto VIN Scan function, you may manually enter the vehicle VIN. ➢ To perform Manual Input Tap the Diagnostics application button from the MaxiDAS Job Menu. The Vehicle Menu displays.
  • Page 23 4.2.3 Automatic Selection The vehicle VIN can also be automatically acquired after a vehicle manufacturer is selected. ➢ To perform Automatic Selection Tap the Diagnostics application button from the MaxiDAS Job Menu. The Vehicle Menu displays. Tap a manufacturer button. Tap Automatic Selection and the VIN information will be automatically acquired.
  • Page 24: Diagnostics Screen Layout

    Diagnostics Screen Layout After the test vehicle is identified, the diagnostic menu will appear. This section consists of various commonly used functions, including Auto Scan and Control Unit. The available functions displayed vary depending on the test vehicle. Figure 4-8 Diagnostic Screen The diagnostics screen typically includes four sections.
  • Page 25 Button Name Description Settings Opens the settings screen. See Settings. Saves and prints a copy of the displayed data. Print Printing Settings for additional information. Provides instructions or tips for operations of various Help diagnostics functions. Tap to open a sub menu. ⚫...
  • Page 26 Status Information Bar The Status Information Bar at the top of the Main Section displays the following items: Menu Title — displays the menu heading of the Main Section. Battery Icon — indicates the battery status of the vehicle. Main Section The Main Section varies depending on the stage of operations, which displays vehicle identification selections, the main menu, test data, messages, instructions, and other diagnostics information.
  • Page 27: Diagnosis

    Diagnosis The Diagnostics application enables a data link to the electronic control system of the test vehicle for vehicle diagnosis. The application performs functional tests, retrieves vehicle diagnostics information such as trouble and event codes and live data for various vehicle control systems, such as engine, transmission, and ABS.
  • Page 28 Main Section Column 1 — displays the system numbers. Column 2 — displays the scanned systems. Column 3 — displays the scan results.  : Indicates that the scanned system may not support the code-reading function, or there is a communication error between the tablet and the control system. ...
  • Page 29 Figure 4-10 Function Menu Screen Available functions may vary by vehicle. The function menu may include: ECU Information — displays detailed ECU information. Select to view the ⚫ information screen. Trouble Codes — contains Read Codes and Erase Codes. The former displays ⚫...
  • Page 30 Figure 4-11 ECU Information Screen Diagnostics Toolbar Buttons — see Table 4-2 Diagnostics Toolbar Buttons detailed descriptions for the operations for each button. Main Section — the left column displays the item names, and the right column shows the specifications or descriptions. Function Button —...
  • Page 31 Diagnostics Toolbar — see Table 4-2 Diagnostics Toolbar Buttons for details. Main Section Column 1 — displays the retrieved codes from the vehicle. ⚫ Column 2 — indicates the status of the retrieved codes. ⚫ Column 3 — detailed descriptions for the retrieved codes. ⚫...
  • Page 32 Figure 4-13 Live Data Screen Diagnostics Toolbar Buttons — tap the drop-down button at the top center of the screen and the toolbar buttons will display. See Table 4-2 Diagnostics Toolbar Buttons for details. Main Section Name Column — displays the parameter names. ⚫...
  • Page 33 Figure 4-14 Display Mode Screen Each parameter item displays its selected mode independently. ⚫ Analog Gauge Mode — displays the parameters in gauge charts. ⚫ Text Mode — the default mode that displays the parameters as a text list. NOTE Status parameters, such as a switch reading like ON, OFF, ACTIVE, and ABORT, can only be displayed in Text Mode.
  • Page 34 Scale Button — changes the scale values. ⚫ There are two scale buttons, displayed above the waveform graph to the right side, which can be used to change the scale values of the X axis and Y axis of the graph. There are four scales available for the X axis: x1, x2, x4 and x8.
  • Page 35 Figure 4-16 Waveform Edit Screen ⚫ Digital Gauge Mode — displays the parameters in the form of a digital gauge graph. Trigger Settings On the Trigger Settings screen, you can set a standard range by filling in a minimum value and a maximum value. When exceeding this range, the trigger function will be executed and the tablet will automatically record and save the generated data.
  • Page 36 Buzzer Alarm — switches the alarm on and off. The alarm function makes a beeping sound to alert you when the data reading reaches the preset minimum or maximum values. The buzzer alarm will only sound at the first trigger. MIN —...
  • Page 37 ⚫ This mode only supports quantitative parameters that can be represented digitally. If non-digital parameters are selected, a message will display advising the user that the selected parameters are not supported in this mode and to select 2 to 5 digital parameters. Tap Got It to return to the previous screen and select supported parameters.
  • Page 38 Flag — displays when the Record function is applied. Tap to set flags to mark ⚫ points of interest when recording data. Notes can be added during playback in Review or Data Manager. Select the preset flag to open a popup window and display a virtual keyboard to enter notes.
  • Page 39 Figure 4-18 Active Test Screen The function buttons in the lower-right corner of the Active Test screen manipulate the test signals. Operational instructions are displayed in the main section of the test screen. Follow the on-screen instructions and make appropriate selections to complete the tests. Tap the ESC button to exit the test when finished.
  • Page 40 Select a function to display detailed information and the execution screen. Figure 4-20 Special Function Screen 2 List Tab Page: ⚫ Column 1 — displays the description of the function being performed or the live data corresponding to the special function. ⚫...
  • Page 41: Generic Obdii Operations

    Generic OBDII Operations OBDII/EOBD vehicle diagnosis option offers a quick way to check for DTCs, isolate the cause of an illuminated malfunction indicator lamp (MIL), check monitor status prior to emissions certification testing, verify repairs, and perform other emissions-related services. The OBDII direct access option is also used for testing OBDII/EOBD-compliant vehicles that are not included in the Diagnostics database.
  • Page 42 Figure 4-21 OBDII Diagnostics Menu Screen 4.5.2 Function Descriptions This section describes the various functions of each diagnostic option: DTC & FFD When this function is selected, the screen displays a list of stored codes and pending codes. When the Freeze frame data of certain DTCs are available for viewing, a snowflake button will display on the right side of the DTC item.
  • Page 43 Stored Codes ⚫ Stored codes are emissions-related DTCs from the ECU of the vehicle. OBDII/EOBD codes are prioritized according to their emissions severity, with higher-priority codes overwriting lower-priority ones. The priority of the code determines the illumination of the Malfunction Indicator Light (MIL) and the codes erase procedure. Manufacturers rank codes differently, so DTCs may vary by vehicle.
  • Page 44: Exiting Diagnostics

    Live Data This function displays the real time PID data from the ECU. Displayed data includes analog and digital input and output, and system status information broadcast in the vehicle data stream. Live data can be displayed in various modes. See Live Data for detailed information.
  • Page 45 On the Vehicle Menu screen, tap the Home button on the top toolbar; or tap the Back button on the navigation bar at the bottom of the screen. Or Tap the Home button on the diagnostics toolbar to exit the application directly and return to the MaxiDAS Job Menu.
  • Page 46: Service

    Service The Service application is specially designed to provide quick access to the vehicle systems for various scheduled service and maintenance tasks. The typical service operation screen is a series of menu-driven commands. Follow the on-screen instructions to select appropriate options, enter values or data, and perform necessary actions.
  • Page 47: Battery Management System (Bms) Service

    Ensure that the EPB control system is reactivated after the maintenance work has been completed. NOTE Autel accepts no responsibility for any accident or injury arising from the maintenance of the EPB system. Battery Management System (BMS) Service The BMS (Battery Management System) allows the tool to evaluate the battery charge state, monitor the closed-circuit current, register the battery replacement, and activate the rest state of the vehicle.
  • Page 48: Steering Angle Sensor (Sas) Service

    NOTE ⚫ AUTEL accepts no responsibility for any accident or injury arising from servicing the SAS system. When interpreting DTCs retrieved from the vehicle, always follow the manufacturer’s recommendation for repair. ⚫...
  • Page 49: Tire Pressure Monitor System (Tpms) Service

    Before performing a forced DPF regeneration using the tool, check the following items: The fuel light is not on. ⚫ ⚫ No DPF-relevant faults stored in system. ⚫ The vehicle has the specified engine oil. The oil for diesel is not contaminated. ⚫...
  • Page 50 transponder sends a signal with a unique identification code to the reader, which relays it to a receiver in the vehicle's computer control module. If the code is correct, the computer allows the fuel supply and ignition systems to operate and start the car. If the code is incorrect or absent, the computer disables the system, and the car will be unable to start until the correct key is placed in the ignition.
  • Page 51: Oem Authorization

    OEM Authorization The OEM Authorization application allows to unlock the gateway ECU (CGW) for some vehicles to perform advanced diagnostics tests. NOTE Make sure the tablet is connected to the Internet before launching the OEM Authorization application. ➢ To unlock the gateway ECU (CGW) Connect the MaxiDAS Diagnostics Platform to the vehicle using the Main Cable.
  • Page 52: Data Manager

    Data Manager The Data Manager application allows you to store, print, and review the saved files, manage the workshop information, customer information records and keep test vehicle history records. Selecting the Data Manager application opens the file system menu. There are nine main functions available.
  • Page 53 Figure 7-2 Vehicle History Screen Top Toolbar Buttons — navigation and application controls. Main Section — displays all vehicle test records. ➢ To activate a test session for the recorded vehicle Tap Data Manager on the MaxiDAS Job Menu. Select Vehicle History to open the screen. Tap Diagnostics or Service to select diagnostic test records or service test records.
  • Page 54: Workshop Information

    Figure 7-3 Test History Sheet ➢ To edit the Test History Tap Data Manager on the MaxiDAS Job Menu. Select Vehicle History. Select the specific vehicle record thumbnail from the main section. The vehicle test record sheet will appear. Tap Edit (a pen icon) to edit the record. Tap each item to enter information or attach data files or images.
  • Page 55: Customer

    Figure 7-4 Workshop Information Sheet ➢ To edit your Workshop Information Tap the Data Manager application on the MaxiDAS Job Menu. Select Workshop Information. Tap on each field to enter information. Tap Done to save the updated workshop information record, or tap Cancel to exit without saving.
  • Page 56: Image

    ➢ To edit a customer account Tap Data Manager on the MaxiDAS Job Menu. Select Customer. Select a customer account by tapping the corresponding name card. A Customer Information record will appear. Tap Edit on the top toolbar to edit the record. Tap on the input field to edit the information, and enter updated information.
  • Page 57: Pdf Files

    Toolbar Buttons — used to edit, print or delete image files. See the following table for detailed information. Main Section — displays stored images. Table 7-1 Toolbar Buttons in Image Button Name Description Back Returns to the previous screen. Search Tap to search the database.
  • Page 58: Review Data

    Review Data The Review Data section allows you to play back recorded data frames of live data streams. On the Review Data main screen, select a record file to play back. Figure 7-6 Data Playback Screen Main Section — displays the recorded data frames. Navigation Toolbar —...
  • Page 59: Report

    Report This section stores and displays all diagnostic reports. The reports stored in this area will be uploaded automatically when you set ON to the Report upload to Cloud in Report Settings. See Report Settings for further details. Tap one of the reports to view it or save it to the cloud.
  • Page 60: Settings

    Settings Selecting Settings application opens a setup screen, on which you can adjust default settings and view information about the MaxiDAS system. The following options are available for the MaxiDAS system settings: Unit ⚫ Language ⚫ Printing Settings ⚫ Report Settings ⚫...
  • Page 61: Printing Settings

    To install the MaxiSys Printer driver program Download the Maxi PC Suite software from > Support > www.autel.com Downloads > Autel Update Tools, and install it to your windows-based computer. Double click the Setup.exe item. Select the installation language and the wizard will load.
  • Page 62: Report Settings

    This section below describes how to receive files from the tablet and perform printing through the computer. NOTE ⚫ Make sure the tablet is connected to the same network with your computer, either via Wi-Fi or LAN, before printing. ⚫ Make sure the computer installed with the Printing Services program is connected to a printer.
  • Page 63: Auto Update

    Figure 8-1 Firmware Upgrade Screen ➢ To upgrade the firmware Connect the tablet to the vehicle using the main cable. Tap Settings on the MaxiDAS Job Menu. Tap Firmware Upgrade on the left column. Tap the Update Now button to upgrade the latest firmware version. Tap the Home button on the top-left corner to return to the MaxiDAS Job Menu, or select another setting option for system setup.
  • Page 64: Vehicle List

    Vehicle List This option allows you to sort the vehicles either by alphabetic order or by using frequency. ➢ To adjust the vehicle list setting Tap Settings on the MaxiDAS Job Menu. Tap Vehicle List on the left column. Select the desired sort order. A check mark will appear to the right of the selected item.
  • Page 65: Update

    Update The Update application allows you to download the latest released software. The updates can improve the MaxiDAS applications’ capabilities, typically by adding new tests, new models, or enhanced applications to the database. The tablet automatically searches for available updates for all of the MaxiDAS software when it is connected to the Internet.
  • Page 66 Main Section Left Column — displays manufacturer buttons. ⚫ Middle Column — displays a brief introduction about the new changes to the ⚫ software operation or capabilities. Tap the button to open an information screen to view more details, and tap the dim area around to close the window. Right Column —...
  • Page 67: Support

    If you have an Autel account, sign in with your account ID and password and skip to step 7. If you are a new member to Autel, click the Register button to create your Autel Enter the required personal information in the input fields.
  • Page 68: Support Screen Layout

    User Information — displays detailed information of your registered online Autel ⚫ account, such as your Autel ID, Name, Address, and other contact information. Device Information — displays the registered product information, including the ⚫ serial number, registration date, expire date, and warranty period.
  • Page 69 Tap Send to deliver your message to Autel support. 10.2.3 Training The Training section provides quick links to Autel’s online video library. Select a video channel by language to see all available online tutorial videos on topics such as product usage techniques and vehicle diagnostics practice.
  • Page 70: Remote Desktop

    You can use the application to receive remote support from Autel’s support center, colleagues or friends, by allowing them to control your MaxiDAS tablet on their PC via the TeamViewer software.
  • Page 71 Provide your ID to the partner and wait for them to send you a remote control request. A prompt will appear asking you to allow remote control on your device. Tap Allow to accept or Deny to reject. Refer to the associated TeamViewer documents for additional information.
  • Page 72: Maxiviewer

    MaxiViewer The MaxiViewer application allows you to search the functions supported by our tools and the version information. There are two ways of searching, either by searching the product and the vehicle or searching the functions. ➢ To Search by the vehicle Tap the MaxiViewer application on the MaxiDAS Job Menu.
  • Page 73 NOTE Fuzzy search is supported. Figure 12-2 Function Viewer Screen 2...
  • Page 74: Quick Link

    Quick Link The Quick Link application provides you with convenient access to Autel’s official website and many other well-known sites in automotive service industry to provide technical help, knowledge bases, forums, and training and expertise consultations. Figure 13-1 Quick Link Screen ➢...
  • Page 75: Maxivideo

    MaxiVideo The MaxiVideo application configures the MaxiDAS Diagnostics Device to operate as a digital video scope by simply connecting the tablet to a MaxiVideo Camera. This function allows you to examine difficult-to-reach areas normally hidden from sight, with the ability to record digital still images and videos, which offers you an economical solution to inspect machinery, facilities, and infrastructure in a safe and quick way.
  • Page 76: Additional Accessories

    14.1 Additional Accessories The MaxiVideo Camera and its fittings are the additional accessories. Both sizes (8.5 mm and 5.5 mm) of the imager head are optional and available for purchase along with the standard MaxiDAS tool kit. 14.1.1 MaxiVideo Camera Figure 14-1 MaxiVideo Camera 1.
  • Page 77 Figure 14-3 5.5 mm Imager Head Accessories 1. Mirror — helps to look around corners and see the unreachable areas. 2. Magnet — picks up small metal objects, such as dropped rings or screws. 14.1.3 Accessory Assembly For 8.5 mm Imager Head The three accessories, the Magnet, Hook, and Mirror, can be attached to the Imager Head in the same manner as described below: 1.
  • Page 78 1. Hold the accessory and the imager head. 2. Screw the thread part of the accessory over the imager head to fix the accessory. 14.1.4 Technical Specifications Item Description ⚫ 0.79 to 2.36" (2 to 6 cm) with 8.5 mm-diameter imager head Optimal Viewing Distance...
  • Page 79: Operations

    14.2 Operations Before opening the MaxiVideo application, the imager head cable must be connected to the tablet through the USB port. Install the correct imager head accessories according to the specific needs. NOTE When in operation, the imager head cable can be manipulated so as to better access confined or awkward spaces.
  • Page 80 Tap the gallery icon at the bottom-right corner to review all the recorded videos. Select the corresponding button on the upper-right corner to search or delete a video.
  • Page 81: Maintenance And Service

    Maintenance and Service To ensure that the MaxiDAS diagnostic tablet performs at its optimum level, we advise that the product maintenance instructions covered in this section is read and followed. 15.1 Maintenance Instructions The following shows how to maintain your devices, together with precautions to take. Use a soft cloth and alcohol or a mild window cleaner to clean the touchscreen of ⚫...
  • Page 82: Troubleshooting Checklist

    Your device may have not been connected to the charger properly. Check the ⚫ connector. NOTE If your problems persist, please contact Autel’s technical support personnel or your local selling agent. 15.3 About Battery Usage Your tablet is powered by a built-in Lithium-ion Polymer battery. This means that, unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your tablet’s autonomy due to the “battery memory effect”...
  • Page 83: Service Procedures

    Technical Support If you have any question or problem on the operation of the product, please contact us (see the following contact info) or your local distributor. Autel China Headquarters ⚫ Phone: +86 (0755) 8614-7779 (Monday-Friday, 9AM-6PM Beijing Time) ⚫...
  • Page 84 Email: ⚫ Address: 906-17, Preatoni Tower (Cluster L), Jumeirah Lakes Tower, DMCC, Dubai, UAE ⚫ Web: www.autel.com Autel Latin America Mexico: ⚫ Phone: +52 33 1001 7880 (Spanish in Mexico) ⚫ Email: latsupport@autel.com ⚫ Address: Avenida Americas 1905, 6B, Colonia Aldrete, Guadalajara, Jalisco,...
  • Page 85 Web: www.autel.com/br 15.4.2 Repair Service If it becomes necessary to return your device for repair, please download the repair service form from www.autel.com, and fill it in. The following information must be included: Contact name ⚫ Return address ⚫ Telephone number ⚫...
  • Page 86: Compliance Information

    Compliance Information FCC Compliance This device complies with Part 15 of the FCC rules and Industry Canada’s license- exempt RSSs. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 87 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact is minimized during normal operation.
  • Page 88: Warranty

    Warranty 17.1 Limited One Year Warranty Autel Intelligent Technology Corp., Ltd. (the Company) warrants to the original retail purchaser of this MaxiDAS Diagnostic Device, that should this product or any part thereof during normal consumer usage and conditions, be proven defective in material or...
