APPENDIX
2
B: I T T L A
IME IMIT LGORITHM
2
The current loop I T limit specifies the maximum amount of time that the peak current can be
applied to the motor before it must be reduced to the continuous limit or generate a fault. This
2
chapter describes the algorithm used to implement the I T limit.
Copley Controls Corp. 161
