5.2.2 Numeric Editing

If the field to be edited requires a numeric value, a number-pad
is displayed:
To enter a number, use the
the required number and press
To finish, highlight 'OK' and press
without making any changes.
The 'C' key cancels the edit operation and exits back to the
previous screen.
The 'Del' key executes the delete and backspace functions on
characters or digits entered in the text box

5.2.3 Other Methods of Editing

There are several other methods of editing, for example:
Checkboxes
To toggle the selection, use the
required checkbox and press
To finish, highlight 'OK' and press
or press to exit without making any changes.
Slider Bars
To select a value, use the
To finish, press to exit and save changes or press
without making any changes.
IM/AZT6CR–EN Rev. R
, , and keys to highlight
.
or press
and keys to highlight the
.
to exit and save changes
and keys to move the slider.
Tabs
To select a tab, use the
Note. The
available.

5.2.4 Menus

Press to open the menu and use the
select a menu item. Press
to exit

5.3 Software Screen Structure

5.3.1 Indicator View Menus

When menus are accessed from the 'Indicator View', the
'Operate' and 'Diagnostics' menu options are displayed.

5.3.2 Chart View Menus

When menus are accessed from the 'Chart View', the 'Chart
Functions' and 'Statistics' menu options are displayed.
to exit
and keys.
tab indicates that there are more tabs
and
to open the menu item:
see Section 6, page 24
see Section 7, page 42
see Section 9, page 51
see Section 10, page 52
see Section 3.2, page 11
see Section 8, page 49
see Section 11, page 55
5 Operation
keys to
