Notes.

1. Alarm Status

–

Flashing red alarm event icon – alarm active and unacknowledged

–

Continuous red alarm event icon – alarm active and acknowledged

2. Alarm Event and Operator Message Annotations

If Alarm event annotation is enabled and an alarm becomes active, a red alarm event icon surrounded by a channel colored

box is displayed at the point at which the alarm occurred, together with the alarm time and tag, for example:

11:58:00 1.1A High Level

If more than one alarm occurs in the same sample period:

–

and the second alarm on a channel becomes active, its icon is added behind the first.

–

and more than one operator message is active (max. 6), a second icon is added behind the first.

–

the new alarm event icons appear to the left of earlier icons.

–

the time and tag of the oldest alarm (right-most icon) only is displayed.

IM/AZT6CR–EN Rev. R
