F.4.5 Electronic Boards

Part No.

Description

AW630 087

Interconnection PCB assembly

AW630 073

Applications PCB assembly

AW600 051

Aztec/Navigator PSU kit – AC

AW600 056

Aztec/Navigator PSU kit – DC

AW630 066

Front door assembly with membrane keypad

(excluding display)

AW630 068

Front door assembly with membrane keypad

plus display

IM/AZT6CR–EN Rev. R

F.4.6 Transmitter Assembly

Part No.

Description

AW630 010

Transmitter assembly (fully tested) – AC

AW630 011

Transmitter assembly (fully tested) – DC
