Wall Mount Wi-Fi
Install On Sectional Doors With Torsion Assemblies Only
This product is intended for installation only by trained garage door technicians. This product may
require adjustments to door springs and/or track configurations. This product is not intended for
use on low headroom tracks or garage doors utilizing extension springs.
• Please read this manual and the
enclosed safety materials carefully!
• The door WILL NOT CLOSE unless the
Protector System
monitor are connected and properly aligned.
• Periodic checks of the garage door opener
are required to ensure safe operation.
• The model number is located on the
front cover of the opener.
• This garage door opener is ONLY
compatible with myQ
accessories.
• Attach warning labels to the location
indicated on label.
LiftMaster
300 Windsor Drive
Oak Brook, IL 60523
For more information, please visit www.devancocanada.com or call toll free at 855-931-3334
Models 8500W, 8500W-267
For Residential Use
and cable tension
®
and Security+ 2.0
®
Garage Door Opener
®
Register your garage door opener to receive
updates and offers from LiftMaster
®
Take a photo of the
camera icon including
the points ( ).
Send it in by texting
the photo to 71403
(US) or visit
www.Liftmaster.photo
(Global).com
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Chamberlain 8500W-267
Summary of Contents for Chamberlain 8500W-267
- Page 1 Wall Mount Wi-Fi Garage Door Opener ® Models 8500W, 8500W-267 For Residential Use Install On Sectional Doors With Torsion Assemblies Only This product is intended for installation only by trained garage door technicians. This product may require adjustments to door springs and/or track configurations. This product is not intended for use on low headroom tracks or garage doors utilizing extension springs.
-
