  • Page 1 LBR iisy Quick Setup Guide...
  • Page 2 Unbox all components except the robot Leaving the LBR iisy robotic arm in the box, remove all other components, accessories and cables. 1.1 Take off the lid 1.2 Remove the sides of the box (two parts) and the cover layer 1.3 Leave the LBR iisy...
  • Page 3 Depending on your configuration, the box when connecting cables to the controller and power supply. may include additional accessories, components or cables that are not listed here. KUKA smartPAD pro and cable KR C5 micro robot controller KR C5 micro power cable Connection cable set (engine cable & data cable)
  • Page 4 Use a hoist to lift up the robot from the horizontal position and remove the packaging material. 3.3 Hoist transport Use a hoist to transport the LBR iisy to its final installation location. Keep the robot inside the sling until it is mounted completely.
  • Page 5 There are three wires that need to be connected Additionally, the smartPAD Pro and the power cable between the LBR iisy and the KR C5 micro controller. have to be connected to the KR C5 controller. XD 80...
  • Page 6 Details provided about the properties and usability of the products are purely for information purposes and do not constitute a guarantee of these characteristics. The extent of goods delivered is determined by the subject matter of the specific contract. No liability accepted for errors or omissions. Subject to alterations. © 2022 KUKA www.kuka. com...
