PES-1014
Phoneline-Ethernet Switch
Version 1.14
November 2001
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PES-1014 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZyXEL Communications PES-1014

Summary of Contents for ZyXEL Communications PES-1014

  • Page 1 PES-1014 Phoneline-Ethernet Switch Version 1.14 November 2001 User’s Guide...

  • Page 2: Copyright

    ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein.

  • Page 3: Zyxel Limited Warranty

    PES-1014 User’s Guide ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two (2) years from the date of purchase. During the warranty period, and upon...

  • Page 4: Interference Statements And Warnings

    PES-1014 User’s Guide Interference Statements and Warnings Interference Statement: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operations.

  • Page 5: Customer Support

    If you have questions about your ZyXEL product or desire assistance, contact ZyXEL Communications Corporation offices worldwide, in one of the following ways: Contacting Customer Support When you contact your customer support representative, have the following information ready: Product model and serial number.

  • Page 6: Table Of Contents

    Table of Contents ... vi List of Figures... ix List of Tables ... xi Preface ... xii Chapter 1 Getting to Know the PES-1014 ... 1-1 1.1 PES-1014 Phoneline Ethernet Switch ... 1-1 1.2 Features... 1-1 1.2.1 Easy Management ... 1-1 1.2.2 Interface... 1-1 1.2.3 High Performance...
  • Page 7 6.3.1 Current Trunk Status ... 6-2 6.3.2 Load Balancing Method Selection ... 6-2 6.3.3 MAC-based Mode Trunk Configuration... 6-3 6.3.4 Port-based Mode Trunk Configuration ... 6-4 6.3.5 Port-based Mode Port Mapping ... 6-5 Chapter 7 VLAN ...7-1 Table of Contents PES-1014 User’s Guide...
  • Page 8 PES-1014 User’s Guide 7.1 Introduction ... 7-1 7.1.1 VLAN Status ... 7-1 7.2 Edit VLAN Group ... 7-2 Chapter 8 Forwarding DB (Database)... 8-1 8.1 Introduction ... 8-1 8.2 Current Forwarding DB Status ... 8-1 8.2.1 Current Static Entries ... 8-2 8.2.2 Edit Static Entry ...

  • Page 9: List Of Figures

    PES-1014 User’s Guide List of Figures Figure 1-1 MTU Application...1-3 Figure 2-1 PES-1014 Front Panel...2-1 Figure 2-2 Phoneline Port Connections...2-3 Figure 2-3 MDF-2 Connections ...2-3 Figure 2-4 PES-1014 Rear Panel...2-4 Figure 3-1 Login...3-1 Figure 3-2 Welcome Screen ...3-2 Figure 3-3 Main Screen ...3-3 Figure 3-4 ...3-3...
  • Page 10 PES-1014 User’s Guide Figure 8-1 Forwarding Database Bar ... 8-1 Figure 8-2 Current Forwarding DB Status ... 8-2 Figure 8-3 Current Static Entries ... 8-3 Figure 8-4 Edit Static Entry ... 8-3 Figure 9-1 Statistics ... 9-1 Figure 9-2 TX/RX Counters... 9-2 Figure 9-3 Error Counters ...
  • Page 11 PES-1014 User’s Guide List of Tables Table 2-1 Front Panel Ports ...2-1 Table 2-2 PES-1014 Network Module LED Descriptions...2-1 Table 2-3 Connecting to a Switch...2-2 Table 3-1 Information Descriptions...3-4 Table 3-2 Manager Front Panel LEDs...3-4 Table 4-1 System Info Description...4-2 Table 4-2 System Configuration Description ...4-3...

  • Page 12: Preface

    This preface introduces you to the PES-1014 and discusses the conventions of this user’s guide About the PES-1014 The PES-1014 is a Phoneline to Ethernet switch that multiplexes traffic from up to 14 phone lines to an Ethernet network before it is forwarded to the Internet. It operates without a need for splitters.

  • Page 13: Getting To Know The Pes-1014

    PES-1014 Phoneline Ethernet Switch The PES-1014 is a sixteen port (14 RJ-11 and 2 RJ-45) intelligent phoneline networking switch for Multi-Tenant Unit and Multi-Dwelling Unit (MTU/MDU) applications. It works with well-known SNMP management platforms such as Hewlett Packard’s Open View, and web browsers like Netscape or Internet Explorer (IE) for configuration and supervising network status.

  • Page 14: Security Mode

    Speed and Activity/Link LEDs for each Ethernet port Link and Activity LEDs for each phoneline networking port Physical Specifications 1.3.1 Dimensions and Weight Dimensions: 440 x 192 x 44 mm Weight: 2.5kg Metal case that is 483mm (19 inch) rack mountable Getting to Know the PES-1014...

  • Page 15: Operating Environment And Power

    Line Frequency Range 50 — 60 Hertz MTU Application The PES-1014 delivers 1Mbps data service over existing copper telephone wires. It does not interfere with Plain Old Telephone Service (POTS), digital telephone or ISDN traffic and does not require splitters. The PES-1014 is also compatible with ADSL lines, allowing service providers to deploy the PES-1014 in buildings where broadband service already exists.

  • Page 17: Chapter 2 Hardware Overview

    The following figure shows the front panel of the PES-1014. 2.1.1 Front Panel Ports The following table describes the ports on the front panel of the PES-1014. PORTS CONSOLE An RJ-45 10/100 Mbps auto-sensing Ethernet port for configuring the PES-1014.

  • Page 18: Console Port

    Phoneline Networking Port Connections An MDF (Main Distribution Frame) is the point of termination for the telephone company and in-building telephone lines. Use standard telephone wire to connect the RJ-11 ports (numbered 1-14) on the PES-1014 to Y- connectors and then the MDF.

  • Page 19: Mdf Connections

    PES-1014 User’s Guide Figure 2-2 Phoneline Port Connections 2.4.1 MDF Connections For MDF-1, install wires from the CO in the upper ports and to the Y-connector or MDF-2 in the lower ports. For MDF-2, connect the upper ports to MDF-2 or the Y-connector and connect the customer lines to the lower ports.

  • Page 20: Rear Panel

    Figure 2-4 PES-1014 Rear Panel Connect the female end of the power cord to the power receptacle on the rear panel of your PES-1014. Connect the other end of the cord to a power outlet. Make sure that no objects obstruct the airflow of the fan (located on the side of the unit).

  • Page 21: Chapter 3 Getting Started

    After the first login, refer to 4.5 for information on configuring the switch’s IP address. Login Procedure for a first login (using the out-of-band console Type in your PES-1014’s IP address as the URL in your web browser (192.168.11.1 for the out-of-band Step 1. console port).

  • Page 22: Welcome Screen

    PES-1014 User’s Guide The web-based management system Welcome screen appears. Step 4. Refer to section 12.3 for adding accounts after logging in. After adding accounts, type in the User Name and Password when logging in. Welcome Screen Figure 3-2 Welcome Screen The Welcome screen gives you links to the main ZyXEL web-site and e-mail for support and sales.

  • Page 23: Main Screen

    Figure 3-3 Main Screen 3.5.1 Information Panel The left side of the Main screen links you to every main subject of this management system. Move the cursor over a link to bring up corresponding submenus for further information. PES-1014 User’s Guide System Information...

  • Page 24: Front Panel

    Statistics Use Statistics to view the statistical contents of each port and host. Use STP to edit the Spanning Tree Protocol switch and port parameters. Reset Use Reset to reset counters and factory defaults or restart the switch.

  • Page 25: System Info

    The phoneline networking link is up. The phoneline networking link is down. Blinking The phoneline networking link is sending/receiving data. The phoneline networking link is not sending/receiving data. of the panel to hide the front panel. Figure 3-10 System Info PES-1014 User’s Guide DESCRIPTION...

  • Page 26: Saving Changes

    3.5.4 Saving Changes If you do not save your configuration changes to flash memory, all of your changes will be lost when the switch is restarted. Use the following steps to save changes when you are done configuring a screen.

  • Page 27: Chapter 4 System

    PES-1014 User’s Guide Chapter 4 System Introduction Move the cursor over the System link to display the submenus shown in the next figure. Figure 4-1 System System...

  • Page 28: System Info

    System Info Move the cursor over the System link and click System Info to display the System Info screen shown next. Use this screen to display general system information and record the switch’s name, location and contact person. FIELD Device Name Type in up to 255 characters for the name of the switch here.

  • Page 29: System Configuration

    Use this option to limit the number of consecutive broadcast packets Control transmitted to the switch. The available selections are 16, 32, 48 or 64 Threshold packets. The PES-1014 discards consecutive incoming broadcast packets that exceed this number. System Figure 4-3 System Configuration DESCRIPTION PES-1014 User’s Guide...

  • Page 30: Port Monitoring Configuration

    Port Monitoring Configuration The PES-1014 allows you to use a network analyzer (or sniffer) program on a computer to do port snooping on an individual port. You can monitor and analyze data traffic, as well as capture packets. Move the cursor over the System link and click Port Monitoring to display the Port Monitoring Configuration screen shown next.

  • Page 31: Networking

    This read-only field is the number of the type of interface that connects to the switch. Type This read-only field is the type of interface that connects to the switch. Out-of-band stands for the console port and in-band stands for the switch’s other ports.

  • Page 32: Snmp

    Click Apply to save your changes to working memory or click Reset to go to the previous configuration. Refer to 3.5.4 for directions on saving your changes to flash memory and restarting the switch. You must restart the switch to make changes in this screen effective.

  • Page 33: Snmp Host

    SNMP Host This SNMP Host screen gives SNMP host information. The maximum number of SNMP hosts is six. You must configure the SNMP Host screen for an SNMP server (like HP’s Open View) to be able to manage the PES-1014. FIELD...

  • Page 34: Save Changes

    SNMP management functions of each management host. Click Apply to save your changes to working memory or click Reset to go to the previous configuration. Refer to 3.5.4 for directions on saving your changes to flash memory before you restart the switch. Save Changes Move the cursor over the System link and click Save Changes to display the Save Changes screen shown next.

  • Page 35: Figure 4-9 Firmware Upgrade

    A bar with the text “Upgrade in Progress” is displayed during the upgrade. The system will complete the upgrade process automatically. Restart the device to finish the upgrade process. System Figure 4-9 Firmware Upgrade PES-1014 User’s Guide Click Browse and choose the file stored on your computer...

  • Page 37: Chapter 5 Port

    PES-1014 User’s Guide Chapter 5 Port Introduction Move the cursor over the Port link to display the submenus shown in the next figure. Figure 5-1 Port bar Port...

  • Page 38: All Ports Status

    PES-1014 User’s Guide All Ports Status Move the cursor over the Port link and then click All Ports to display the All Ports Status screen shown next. This screen shows the link status, transmission speed and duplex mode of the current ports. Click a port’s number to link directly to the selected port.

  • Page 39: Port Configuration

    This port is sending or receiving at 100Mbps in one direction only at a time (half duplex). This port is sending or receiving at 10Mbps in one direction only at a time (half duplex). Figure 5-3 Port Configuration Table 5-3 Port Configuration Description DESCRIPTION PES-1014 User’s Guide EXAMPLE myportname Enable (default)

  • Page 40: Port Assigned

    Select Disable to cancel Broadcast Storm Control. Click Apply to save your changes to working memory or click Reset to go to the previous configuration. Refer to 3.5.4 for directions on saving your changes to flash memory before you restart the switch. Port Assigned Move the cursor over the Port link and then click Port Assigned to display the Port Assigned screen shown next.

  • Page 41: Figure 5-4 Port Assigned

    Choose up to four properties to copy from the Source Port to the target port(s). Click Apply to save your changes to working memory. Refer to 3.5.4 for directions on saving your changes to flash memory before you restart the switch. Port...

  • Page 43: Chapter 6 Trunk

    Fast Ethernet (100Mbps) links could be aggregated into one single 200Mbps link. Trunking is an advanced feature of the PES-1014. Exercise extreme caution if you decide to configure Configure up to four trunks with two to four ports in each trunk. The last number of the trunk set must be port 2, 6, 10, or 14.

  • Page 44: Current Trunk Status

    PES-1014 User’s Guide 6.3.1 Current Trunk Status Move the cursor over the Trunk link and click Current Status to display the Trunk Status screen shown next. This read-only screen displays the current status of each trunk, including which Load-balance method you are using and which ports are assigned to which trunk.

  • Page 45: Mac-Based Mode Trunk Configuration

    PES-1014 User’s Guide Figure 6-3 Load Balancing Mode Selection Screen 6.3.3 MAC-based Mode Trunk Configuration Configure this screen when you choose MAC Address Based Method in the previous screen. Select which trunk should use MAC Address Based Method load balancing and which ports should be included in the selected trunk(s).

  • Page 46: Port-Based Mode Trunk Configuration

    PES-1014 User’s Guide The designated two bits of the SA and DA are Exclusive Or’d (XOR). These combinations map to trunk ports as shown next. The left value represents SA and the right represents DA. MAC Address Based Mode Bit Selection Example Select Trunk 2 from Trunk Assignment and [0,1] MAC Address Based Mode Bit Selection in the MAC-based Mode Trunk Configuration screen.

  • Page 47: Port-Based Mode Port Mapping

    Trunk Port These are the trunk ports in the trunk ID that you selected above. Assigned This field shows whether or not individual trunk ports have been assigned to this trunk. Trunk Table 6-4 Port-based Mode Mapping DESCRIPTION PES-1014 User’s Guide...
  • Page 48 Click radio buttons to select ports to map to trunk ports. Mapping Click Apply to save your changes to working memory or click Reset to go to the previous configuration. Refer to 3.5.4 for directions on saving your changes to flash memory before you restart the switch. DESCRIPTION Trunk...

  • Page 49: Chapter 7 Vlan

    Move the cursor over the VLAN link and click Current Status to display the read-only VLAN Status screen shown next. This screen shows the current VLAN status in the switch. Click the Group ID (number of a VLAN Group) to set the related attributes of that group regarding Status, Name and Port Members.

  • Page 50: Edit Vlan Group

    PES-1014 User’s Guide FIELD Group ID There are 128 possible VLAN Groups (VLAN Group 1 is the default and non-editable). Click any of the other Group ID numbers to display the corresponding VLAN editing screen. VLAN Status This column indicates the current status of all VLAN groups. “Enable” means that the selected VLAN is active.

  • Page 51: Table 7-2 Edit Vlan Group Description

    At least two ports must be selected to form a VLAN group. Click Apply to save your changes to working memory or click Reset to go to the previous configuration. Refer to 3.5.4 for directions on saving your changes to flash memory before you restart the switch. VLAN...

  • Page 53: Chapter 8 Forwarding Db (Database)

    SAs. The switch does not age out or update static entries. The only way to change the static entries is through manual editing in the Edit Static Entry screen.

  • Page 54: Current Static Entries

    Port/Trunk/CPU shows whether the MAC address of a received packet Port/Trunk/CPU is from a port, trunk or the switch respectively. Click Port/Trunk/CPU to sort the table in descending or ascending order. This column indicates the MAC address of each entry. Click MAC to sort the table in descending or ascending order.

  • Page 55: Edit Static Entry

    Choose a static entry to edit its status, as well as port or Forwarding Database Figure 8-3 Current Static Entries Table 8-2 Current Static Entries Description DESCRIPTION Figure 8-4 Edit Static Entry PES-1014 User’s Guide 00-C0-00-00- trunk. EXAMPLE Port 9 00-1A...

  • Page 56: Table 8-3 Edit Static Entry Description

    Click Apply to save your changes to working memory or click Reset to go to the previous configuration. Refer to 3.5.4 for directions on saving your changes to flash memory before you restart the switch. Table 8-3 Edit Static Entry Description...

  • Page 57: Chapter 9 Statistics

    PES-1014 User’s Guide Chapter 9 Statistics Introduction Statistics leads to the statistical contents of each port and host, all figures reflect the latest facts since the last time the port has been turned on. Move the cursor over Statistics to bring up the following submenus.

  • Page 58: Tx/Rx Counters

    PES-1014 User’s Guide TX/RX Counters Move the cursor over the Statistics link and click TX/RX Counters to display the TX/RX Counters screen shown next. FIELD Port ID This is the label of a port. Packet TX The port’s total number of successfully transmitted packets. This is the sum of unicast TX, multicast TX, and broadcast TX packets.

  • Page 59: Error Counters

    The number of packets received that were of the proper size but had a CRC error and a non- integral number of octets. Late The number of times a collision was detected later than the first 512 bits of a transmission. Collision Statistics Figure 9-3 Error Counters Table 9-2 Error Counters Description DESCRIPTION PES-1014 User’s Guide...

  • Page 60: Packet Analysis (Tx)

    PES-1014 User’s Guide Packet Analysis (TX) Move the cursor over the Statistics link and click Packet Analysis(TX) to display the Packet Analysis (TX) screen shown next. FIELD Port ID This is the label of a port. 64 in_length The number of packets (including bad packets) transmitted that were 64 octets in length.

  • Page 61: Packet Analysis (Rx)

    The number of packets (including bad packets) received that were between 512 and 1023 octets in length 1024-1518 The number of packets (including bad packets) received that were between 1024 and 1518 octets in length. Statistics Figure 9-5 Packet Analysis (RX) Table 9-4 Packet Analysis (RX) Description DESCRIPTION PES-1014 User’s Guide...

  • Page 62: Packet Attribute

    PES-1014 User’s Guide Packet Attribute Move the cursor over the Statistics link and click Packet Attributes to display the Packet Attribute screen shown next. FIELD Port ID This is the label of a port. Unicast TX The total number of good packets addressed to a unicast address that the port transmitted.

  • Page 63: Collision Info

    The number of packets with 1 collision detected. Multi Collisions The number of packets with 2 to 15 collisions detected. Excessive Collision The number of packets with more than 15 collisions detected. Statistics Figure 9-7 Collision Info Table 9-6 Collision Info Description DESCRIPTION PES-1014 User’s Guide...

  • Page 64: Single Port Statistics

    PES-1014 User’s Guide 9.7.1 Single Port Statistics Move the cursor over the Statistics link and click Single Port to display the Single Port Statistics screen shown next. This screen displays the single port information of a selected Port ID. See earlier in this chapter for field descriptions.

  • Page 65: Chapter 10 Stp

    Spanning Tree Protocol (STP) is IEEE standard (802.1d) that avoids looping in the network while maintaining multiple Ethernet bridges. STP can avoid loops by placing ports in forwarding state or in blocking state to establish redundant paths. When STP is enabled, the switch will execute STP Bridge Protocol Data Unit (BPDU) packets as below: If the port is in Block-N-Listen State or Learning State, the BPDU packet is forwarded to the CPU, other packets are discarded.

  • Page 66: Figure 10-2 Spanning Tree Configuration (Bridge)

    Click Apply to save your changes to working memory or click Reset to go to the previous configuration. Refer to 3.5.4 for directions on saving your changes to flash memory before you restart the switch. 10-2...

  • Page 67: Spanning Tree Configuration (Port)

    Priority Priority decides which port should be disabled when more than two ports form a (0.255) loop in a switch. A higher priority value means that the port is easier to disable. Priority ranges from 0 to 255. Path Cost Displays the path cost of the port.

  • Page 69: Chapter 11 Reset

    Use this screen to reset all the counters of your device. Click Apply to reset all counters of the device (the statistic counters) to zero. Reset Figure 11-1 Reset Figure 11-2 Reset Counters PES-1014 User’s Guide Chapter 11 Reset 11-1...

  • Page 70: Reset To Factory Default

    Move the cursor over the Reset link and click Factory Default to display the Reset to Factory Default screen shown next. Use this screen to reload the factory default settings and restart the switch to make the factory defaults effective.

  • Page 71: Chapter 12 Account

    Both the user ID and password of the factory default are null string. ZyXEL recommends adding new accounts for security protection immediately after you enter the system. Anyone trying to access the switch is prompted to type in an ID and password after any account is properly established.

  • Page 72: Add/Del Account

    Click Apply to save your changes to working memory or click Reset to go to the previous configuration. Refer to 3.5.4 for directions on saving your changes to flash memory before you restart the switch. 12-2...

  • Page 73: Change Password

    Click Apply to save your changes to working memory or click Reset to go to the previous configuration. Refer to 3.5.4 for directions on saving your changes to flash memory before you restart the switch. You can only change the password of the account that you are logged in on.

  • Page 75: Appendix A System Parameters

    The IP addresses of the devises included in the network Device IP Mask Set up a subnet mask Default Gateway A gateway IP is used for the switch to connect to a non- local IP PES-1014 User’s Guide Appendix A...
  • Page 76 The community that the management host belongs to (case- commu. sensitive) enable/disable Allow/disallow an IP address to function in SNMP any port in the switch Select a port to set its configuration 1-255 characters Give the selected port a name for convenience (case- sensitive) enable/disable...
  • Page 77 Choose a static entry ID for editing its status and port/trunk enable/disable Activates or deactivates the selected static entry 1-24 port / 1-6 trunk Assign the entry to a certain port or trunk MAC address Give a MAC address to each entry PES-1014 User’s Guide NOTE...
  • Page 78 PES-1014 User’s Guide CATEGORY DEFAULT VALUE Spanning Tree Protocol(STP) Spanning Tree Configuration Spanning Tree disable Protocol State Bridge Priority 32768 Bridge Hello Time 2 sec. Bridge Max Age 20 sec. Forward Delay 15 sec. Port Parameters Port ID Priority Path cost...

  • Page 79: Appendix B Safety Warnings And Instructions

    1. Be sure to read and follow all warning notices and instructions. 2. The maximum recommended ambient temperature for the PES-1014 is 50º Celsius. Care must be taken to allow sufficient air circulation or space between units when the PES-1014 is installed inside a closed rack assembly.

  • Page 81: Index
