Mode of Operation

The 510 thermostat has two modes of operation:
• Off: Does not provide heating.
• Heat: Provides heating only.
To choose the Mode of Operation:
1. Use the Menu button to select the
menu.
2. Use the Item button to select MODE.
3. Use the or
desired mode of operation.

Schedules

By default, this thermostat uses four adjustable 'events' on a 24 hour cycle. Each
event is a time of day requiring a room temperature change. This optimizes system
efficiency by reducing room temperatures when the building is less likely to be
occupied.
Although default schedule settings are
recommended, they are fully adjustable.
Please refer to the "Advanced Schedule
Settings" section on Page 9 for more
detailed settings.
Displays
the current
event when
a schedule is
active
© 2012 U 510 - 02/12
button to select the
510 Thermostat MODE options
Default Schedule Settings
Schedule
Mode
4 events per
day
or
2 events per
day
6 of 12
Event Time
Wake 6:00 AM
Unoccupied 8:00 AM
Occupied 6:00 PM
Sleep 10:00 PM
Occupied 6:00 AM
Unoccupied 10:00 PM
