16.SPECIFICATION

Model
Item Specification
Length
Width
Height
Wheel base
Net Weight
Type
Fuel
Compression ratio
Maximum HP
Maximum torque
Starting methods
Front shock absorber
Rear shock absorber
Clutch
Transmission
Front tire
Rear tire
Wheel
Tire pressure
Front brake
Rear brake
Headlight deep/main beam
Position Lamps
Taillight/Stoplight
Turn Signal Light front/rear
Engine oil capacity
Transmission oil capacity
Fuel tank capacity
Fuse
Spark plug
Battery capacity
Air cleaner
XE05W2-EU/XE05W2-IT
4- stroke single cylinders engine
UNLEADED (OCTANE 90 OR HIGHER)
11.0±0.2:1
2.2kw/8000 rpm
3.0N.m/6000 rpm
Front: STD 2.00 kg/cm
Rear: STD 2.00kg/cm
Disk type (Ø 226 mm)
Drum type (Ø 110 mm)
12V 10W *2/12V 10W *2
0.8L (0.7 L for change)
100c.c (90c.c for change)
20A*1&15A*2&10A*1
24
1915±20 mm
680±10 mm
1125±20 mm
1290±20 mm
107±5kg
2.2kw/6000 rpm（Apply to
model :Speed limited :25km/h）
3.2N.m/5500 rpm（Apply to
model :Speed limited :25km/h）
electrical starter
TELESCOPE
UNIT SWING
Centrifugal type
CVT
110/70-12 47J
120/70-12 51J
Aluminum
2
,
2
for 1 person, 2.25kg/cm
12V 35W/35W *1
12V 5W *1
12V 5W /21W *1
6.2±0.2 L
CR6HSA
12V 6Ah
Paper type
XE05W2-NL
11.0±0.2:1
2
for 2 persons
