Pos. Component Article Name
1 Bearingless Fan BFS-i04.1
Pos. Component Article Name
2 Adaptor Cable Hybrid ICH-5.1-03 (0.3 m)
3 AC/DC Power Supply
4 Interface Panel FIP-1.1
5 User Panel LUI-B.1-06
6 USB-RS485 Adaptor YN-485I-TR
IP Adaptor Cable ICS-1.1-10 (1 m)
7
Signal 6 Wires ICS-1.1-30 (3 m)
IP Adaptor Cable ICS-1.2-10 (1 m)
8
Signal 6 Wires ICS-1.2-50 (5 m)
IP Adaptor Cable
9 ICS-1.3-50 (5 m)
Signal 6 Wires
ATEX Cable ACS-A.1
10
Sealing System (Roxtec)
PL-3507-00, Rev00, DCO# 23-128
Article # Characteristics
Voltage, Power Input
Max. Pressure, Max. Flow
Point of Max. Power
ATEX / IECEx Marking
IP Rating
Electrical Interfaces
100-10224
Standard Firmware
Mechanical Interface
Cable Length
Materials
Weight
Table 1: Specification of standard configuration
Article # Characteristics
Specifications
190-10544
Purpose
Structure/Design
100-91638
Purpose
Specifications
100-30549
Purpose
Structure/Design
100-30392
Purpose
Specifications
190-10344
190-10345
Purpose
Specifications
190-10440
190-10346
Purpose
Specifications
190-10389
Purpose
Materials
100-90292
Note
Table 2: Specification of standard accessories
User Manual for BFS-i04
Value / Feature
24 V DC ±10%, 80 W
(Option: 12 V DC ±5%, 20 W, with reduced max. speed of 10000 rpm)
3
870 Pa (3.5 inH O), 4.4 m /min (155 cfm)
2
3
700 Pa, 3.7 m /min, 18000 rpm
(Optional 12 V supply voltage: 200 Pa, 2 m
II 2G Ex h mb IIC T6 Gb
1258
II 2D Ex h mb IIIC T85 °C Db
Ambient and gas temperature range 0 to 40 °C
IP67
PLC with 2 analog inputs
1 analog output
1 digital input
RS485 interface, Modbus protocol (extended control or service through
fieldbus or Levitronix Service Software)
®
V5.48
Flange on both motor sides with mounting holes 4 x Ø 5.8 mm on
diameter 90 mm. Flange inside Ø 72 mm, outside 80 mm x 80 mm
5 m with TE connector for power and PLC signals
Polypropylene, electrically conductive, flame retardant
Cable: PVC jacket, PVDF bushing
0.5 kg, 1.1 lb
Value / Feature
PVC insulated open wires (2 x 0.75 mm
signals) with TE connector
Connection of fan cable to DC power supply and PLC signals
See section 3.1.2 for a list of compatible and tested power supplies
DIN-rail mountable PCB with connectors for:
- 4 x BFS-i04 fans (TE Connectivity 1-1827875-4)
- 1 x Power supply connector (Wago 2624-3103)
- 18 x PLC push-in (analog inputs/outputs, digital inputs, RS485)
- 1 x Circular COM for LUI-B.1 or USB-RS485 adaptor
Easy wiring of power and PLC signals for up to four BFS-i04 fans, see
section 4.3 for further information
Firmware A8.00, IP65, 5 to 24 V supply voltage
Control of fan via handheld device
USB connector (A) with termination resistor and cable (2 m) with
connector pair (B and C) for external RS485 wire connection.
Magnetically isolated. Included is a USB space saver cable (D)
Control or service of fan via USB port of a PC with Levitronix® Service
Software
PVC jacket, connectors: circular to circular type
Connection of user panel (LUI-B.1) to interface panel (FIP-1.1)
PVC jacket, connectors: circular type to screw type
Connection of user panel (LUI-B.1) to adaptor cable (ICH-5.1) and 5 to
24 V supply
PVC jacket, connectors: circular type to screw type
Connection of interface panel (FIP-1.1) to USB adaptor (YN-485I-TR)
Sleeve (A) and Gasket (B): Stainless Steel, EPDM
Frame(C) and 2x Cable Module (D): Roxylon (EPDM Rubber)
Lubricant (E) and measurement plates (F) are included
