StarTech.com ST3504USB User Manual page 3

4
Monitoring Your USB Hub
The five LEDs on the front of the hub are the best indication of the hub's activity:
• The four red LEDs indicate activity on each of the four USB ports. Each LED is
numbered to correspond to a port.
• The green PW LED indicates that the hub is properly powered.
Technical Specifications
Ports 1 upstream (root), 4 downstream (peripheral)
Output Voltage +5V DC (each port)
Output current 500mA (max) per port
Power Supplied by LP-4 power supply connector
Connectors 4 front USB "A" female
1 rear USB "B" female
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . .
Monitoring Your USB Hub . . . . . . . . . .
Technical Specifications . . . . . . . . . . . . .
Technical Support . . . . . . . . . . . . . . . . . .
Warranty Information . . . . . . . . . . . . . . .
