2-Port VGA Auto Switch w/ EDID Emulation
ST122VGA
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 07/26/2013
Advertisement
Table of Contents
Related Manuals for StarTech.com ST122VGA
Summary of Contents for StarTech.com ST122VGA
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 07/26/2013...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Product Diagram ..................1 Front View ..............................1 Rear View ..............................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Installation ....................2 Hardware Installation ..........................2 Hardware Operation ..........................2 Specifications ..................5 Technical Support ..................6 Warranty Information ................6 Instruction Manual... -
Page 4: Product Diagram
Product Diagram Front View 1. VGA Input Port #1 2. VGA Input Port #2 3. P1 & P2 LED Indicators Rear View 1. Power Adapter Port 2. Manual / Priority switch 3. VGA Output Port 4. Manual Select Switch 5. EDID Rotary Switch Instruction Manual... -
Page 5: Introduction
1. Connect a M/M VGA Cable (not included) from the VGA Output Port on the ST122VGA, to the VGA input port on your VGA enabled display device (i.e. television, projector). 2. Connect a M/M VGA cable (not included) from each VGA enabled input device (up to 2) to the VGA Input Ports on your video source devices (i.e. - Page 6 “VGA Input Port 1”. When the Blu-ray player is turned on to watch a movie the ST122VGA will automatically switch to the Blu-ray player. When the movie is over, simply turn off your Blu-ray player and the ST122VGA will automatically switch back to your set top box.
- Page 7 d. Press and hold the “Manual Select Switch” for 3 to 5 seconds until the LED flashes green. e. The LED flashes red and green alternately and then lights green indicating the EDID/DDC copy was successful. Note: If the LED lights red last, this indicates EDID copy failure. This means that the monitor is not properly connected, the monitor is not powered on, or EDID/DDC data is not available on that monitor.
-
Page 8: Specifications
Specifications Ports AV Input AV Output Maximum Digital Resolutions 1920x1200 Wide Screen Supported Universal Adapter Wall Plugs Included NA, EU, UK, AUS Power Adapter Included Input Voltage 100~240V Input Current 0.12 A Output Voltage 5 DC V Output Current Instruction Manual... -
Page 9: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 10 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
