Example: Wiring “single ended” measurement ..............13 5.2.3 Example: Wiring “differential” measurement ..............13 5.2.4 2x Analog Input 0..10V (“SILVER”: “M49076”, “C49076” ) ..........14 5.2.5 Extension 2x Analog Input 0..10V (“E490A2”) as add-on to “RS485 Silver” (“M42076”, “C42076”) ............................15...
Page 3
Jump to: Table of Content Configuration: ‘PC Companion Software’ ................... 17 How to configure Avisaro “Series 4.0” products ................ 17 Concept of operation ........................17 Detailed documentation ......................17 “PC Companion Software” Installation ..................18 Driver installation ........................18 Initial Set-Up ..........................19 Using the PC Companion Tool .....................
Page 4
Jump to: Table of Content 7.1.3 Via USB Stick ........................30 Firmware Update ........................31 7.2.1 Introduction ........................31 7.2.2 Via USB stick ........................32 7.2.3 Via “PC Companion” Software .................... 32 7.2.4 Via FTP server / internet ..................... 32 Declarations ............................
2021/05/02 Initial version extracted from existing documents 2.2 A UDIENCE The intended reader of this document are technical personnel installing, configuring, and using the Avisaro device. 2.3 L OCATION Check for the latest document version the following link: Link: https://www.avisaro.de/files/Avisaro/40_Docu/M49076-C49076-QuickGuide.pdf 2.4 L...
2.7 D OCUMENT CREATION This document was created using the “Avisaro Document Builder”. Single text blocks are merged into targeted documents. Thus, text blocks can be reused in several places, yet no need to update them manually when changes occur.
NCLOSURE AND ONTROLS 3.1 S TART AND STOP OPERATION The Avisaro 4.0 starts with operation right after power on if an USB stick is inserted. Also, after re- inserting a USB stick, the operation starts automatically. 3.2 LED B LINK ODES There is one multicolor LED to signal states of the Avisaro device.
Jump to: Table of Content 3.4 E “4.0 S ” NCLOSURE ILVER WITH SCREW TYPE CONNECTOR View into the enclosure with the lid unscrewed. Optional, a DIN rail fitting is available: During normal operation, the enclosure is sealed. Page : 8 2023/05/23...
Companion Software” .. “USB Storage” ether in this document, or in the overall “User Manual Serie 4.0” document. Alternatively, third party tools for Windows can be used to format large USB sticks. Please note: Avisaro can not support those third party tools within our technical support via telephone or email.
Jump to: Table of Content The appropriate memory size also depends on the intended use. Due to the technology, memory sticks with an extremely high capacity are typically less robust than smaller memory sizes. The loggers have a "ring memory" that can be optionally activated. If the memory stick becomes full (approx. less than 100MB free memory) the oldest files are deleted - this is a useful setting for some applications.
Jump to: Table of Content Innodisk USB Drive 3SE 4-32 GB Industrial SLC Technology 4.4.2 Not recommended Manufacturer Model Picture Capacity Technology Remarks Verbatim Slider 8 GB Consumer Stick failures after Store N Go short period of time Page: 11 2023/05/23...
Heads-up: There are sometimes Micro USB cable which only do power supply, but not data. Those are used i.e., with mobile phones. If the Avisaro device is powered, but no data connection to the PC – just choose a different USB cable.
Jump to: Table of Content 5.2.2 Example: Wiring “single ended” measurement As the data logger allows for advanced differential measurements, single ended measuring needs to have all negative inputs wired to reference ground. The signal side is isolated from the power side - thus signal ground can be different from supply ground. 5.2.3 Example: Wiring “differential”...
Jump to: Table of Content 5.2.4 2x Analog Input 0..10V (“SILVER”: “M49076”, “C49076” ) 1 2 3 4 5 6 7 8 Connector Interface Signal Direction Screw Type ADC3 & ADC4 Power & Signal Page : 14 2023/05/23...
Jump to: Table of Content 4..20mA VCC (6..32V) Power ADC4 0-10V (-) ADC4 0-10V (+) ADC3 0-10V (-) ADC3 0-10V (+) Future Use (not connected) Future Use (not connected) 5.2.5 Extension 2x Analog Input 0..10V (“E490A2”) as add-on to “RS485 Silver” (“M42076”, “C42076”) 1 2 3 4 5 6 7 8 Connector Interface...
Page 16
GND (Signal & Power) ADC4 0-10V (Signal) Analog in ADC3 0-10V (GND) GND (Signal & Power) ADC3 0-10V (Signal) Analog in See documentation for datalogger and gateway “4.0 Silver 0..10V” for details on the analog input: https://www.avisaro.de/files/Avisaro/40_Docu/M49076-C49076-QuickGuide.pdf Page : 16 2023/05/23...
6.3 D ETAILED DOCUMENTATION This current document shows only selected parts of the full “Avisaro PC Companion Software” user manual. The motivation is to keep this document as compact as possible. Please find the extensive “Avisaro PC Companion Software” document in the support section of the...
6.5 D RIVER INSTALLATION If you connect the Avisaro Device to the PC using a Micro USB cable, a virtual COM port driver is installed. If this driver does not install automatically, you can download and install this manually: http://www.avisaro.de/de/40-PC-Treiber.html (German site) http://www.avisaro.com/en/40-ENG-PC-Driver.html...
SING THE OMPANION Click on “Write Config” to transmit changes in the PC tool to the Avisaro device. Click on “Read Config” to display the currently stored values (if you navigate between options, the latest settings are read of course automatically).
In most cases, devices are shipped with proper settings on this page. 6.8.1 Global HW settings ⇨ System functions Don’t touch those settings unless advised by technical support team from Avisaro. Global HW settings ⇨ Networking 6.8.2 Activate the network interface which is physically present.
Jump to: Table of Content ⇨ 4..20 6.9 I A / 0..10V NTERFACES The analog interfaces for 4..20mA and 0..10V are managed in the same settings page. 6.9.1 Sample Rate Select the desired sample rate in samples per seconds (hz). 6.9.2 Stream to In this point of time, only “Analog data (generic)”...
Jump to: Table of Content ⇨ 4..20 6.10 D A / 0..10V ROCESSING Settings for collection 0..10V or 4..20mA analog data. 6.10.1 Storage Format ⇨ Storage format This is the default setting. … Page : 22 2023/05/23...
Jump to: Table of Content 4x Current (mA)(NMEA) Storage format example with the setting above: 2022/03/02,15:45:33,332, $20MA, 9.979 mA, 0.761 mA, 0.001 mA,-0.001 mA 2022/03/02,15:45:34,331, $20MA, 9.980 mA, 0.730 mA,-0.001 mA, 0.001 mA 2022/03/02,15:45:35,330, $20MA, 9.980 mA, 0.742 mA,-0.001 mA, 0.000 mA 2x Current (mA)(NMEA) Storage format example with the setting: 2022/03/02,16:41:24,795, $20MA,...
Jump to: Table of Content No network forwarding Network (IP) Data are forwarded to the “Network (IP)” endpoint The same format is used as set in “Storage format” (PC companion version 2.65 and firmware version 2.65 or higher required) ⇨ USB S 6.11 D NDPOINTS TICK...
Jump to: Table of Content ⇨ “Create new file” No log file is created, no data are logged one file every hour Every hour a new file Log file name: yymmddhh.txt every hour with ringbuffer Every hour a new file. If memory space is exceeded, the oldest file is deleted.
Target port: port data are sent to Local port: not used TCP/IP client Data is send and received using the TCP/IP protocol. The Avisaro device is server – thus it is waiting for a client to connect to the Avisaro device. Page : 26 2023/05/23...
IP address) ⇨ C 6.13 D NDPOINTS LOUD ETTINGS The Cloud features of the Avisaro devices are best described in separate application specific documents. Thus, here the settings are described briefly without the ‘large picture’ behind it. Page: 27...
Stored data are made available to be picked up by a Server Software. Parameter are: • User and Password • Device Name Typically, “Store&Collect” goes along with the “Avisaro Dashboard Software” (see separate documentation) 6.13.2 Data Endpoints ⇨ Remote firmware update Page : 28 2023/05/23...
Page 29
Jump to: Table of Content Check chapter “Firmware and Configuration Update” later in this document for details. Page: 29 2023/05/23...
7.1.1 Introduction The configuration of the Avisaro 4.0 defines how the devices behave. Settings like baud rate, time and date, Internet access parameter, etc. are variable and can be defined by the user. There are two ways to configure the Avisaro 4.0 devices: 1) Connect the device to a PC using a Micro-USB cable.
There are three ways to update the firmware of the Avisaro 4.0 family: 1. Via USB Stick If the Avisaro 4.0 product has a USB Host port, a new firmware can be uploaded using a USB stick. See details below.
7.2.4 Via FTP server / internet Avisaro Devices can be updated remotely. This is a powerful service feature. To enable, navigate to “Data Endpoints”->“CLoud setting” and activate “Remote firmware update”. Please refer to the document “PC Companion” for details, chapter “Data Endpoints-> Cloud Settings”.
Page 33
30 seconds which is sensitive to power failure) Recommendations: • It is highly recommended to create a different user pointing to a different subdirectory for each Avisaro Data logger. This way, a firmware update can be directed to each. Page: 33 2023/05/23...
Jump to: Table of Content ONTACT AND UPPORT Please contact Avisaro if there are any questions: Avisaro AG Grosser Kolonnenweg 18 E 30163 Hannover Germany Email: support@avisaro.com End of this documentation Page: 35 2023/05/23...
