CTI 3
E l e c t r i c B i k e
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CTI3 and is the answer not in the manual?

Questions and answers

Related Manuals for Gotrax CTI3

Summary of Contents for Gotrax CTI3

  • Page 1 CTI 3 E l e c t r i c B i k e USER MANUAL...
  • Page 3 Congratulations on your purchase! This user manual will help you assemble and operate your new electric bicycle. Be sure to read ALL OF THE INFORMATION in this manual before riding. NOTE TO ALL RIDERS UNDER THE AGE OF 18: It’s very important that you get parental permission before riding your electric bicycle.

  • Page 4: Table Of Contents

    Contents Don’t Ride Until You Read This ............... Warning Message ..................Unpacking and Product Specs ..............Get to Know Your E-Bike ................. 1. Handlebar ..................... 2. Seat ........................ 3. Front Wheel & Front Brake ............... 4. Pedals ......................5. Fenders ......................6.
  • Page 5 Precautions for Battery Protection..............Troubleshooting Guidance ..............Warranty ....................

  • Page 6: Don't Ride Until You Read This

    Don’t Ride Until You Read This: ALWAYS wear a helmet when riding your electric bike. Make sure your electric bike has a full battery before taking it out to ride. Always be aware of local road laws, and follow them. Do not ride the bike under the influence of drugs or alcohol.

  • Page 7: Warning Message

    Abuse - We do not cover physical damage due to negligent care and extreme riding. Whenever you ride the GOTRAX Electric Bike, you risk severe injury or even death from loss of control, collisions, and falls. Use caution and ride at your own risk.
  • Page 8 15. Maximum Speed - Your electric bike goes the maximum speed of 20 mph. 16. Make note that additional insurance may be required to cover situations you encounter while riding an electric bike. It is recommended that you contact an insurance company or broker for advice and consultation.
  • Page 9 ALWAYS WEAR A HELMETIT COULD SAVE YOUR LIFE! A properly fitting, CPSC approved， bicycle helmet should be worn at all times when riding your bicycle. In addition, if you are carrying a passenger (only use an approved child safety seat), and remember, the passenger must also be wearing a helmet.
  • Page 10 following measures: *Reorient or relocate the receiving antenna. *Increase the separation between the equipment and receiver. *Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. *Consult the dealer or an experienced radio/TV technician for help.

  • Page 11: Unpacking And Product Specs

    Unpacking and Product Specs The following accessories are included with your 90% pre-assembled GOTRAX bike. Multi Tool Pedal / Wheel Wrench Front Reflector Pedal Battery Charger Battery Keys Small Bell CTI3 1890x720x1190 mm (74.4x28.3x46.8 in) 1495x310x880 mm (58.8x12.2x34.6in) 120 kg (264 Ibs) 32km (20 mph) 48V 13.6Ah...

  • Page 12: Get To Know Your E-Bike

    Charger Port...

  • Page 13: Handlebar

    1. HANDLEBAR HANDLEBAR COMPONENTS HAS BEEN PRE-ASSEMBLED Please tighten and secure all bolts You will use the 5mm allen key on the multi tool for these steps. Unscrew the bolts and remove the Place the handlebar riser on the Loosen the fixing screws between covers, bolts and sleeves, leaving all front fork, tighten the bolts on the top the stem and the handlebar,...
  • Page 14 You will need the +/phillips screw driver in the multi tool to install. Light Installation. Remove allen bolt and wrap bracket around center of stem. Reapply bolt and using the 4mm allen key tighten and secure. Adjust light angle for preference. You will need the 3mm allen key You will need the +/phillips screw driver on the multi tool to install.

  • Page 15: Seat

    2. SEAT 1. Push the saddle down. 2. Open the folder of the seat tube. 3. Adjusting and rotate the seat. 4. Finally lock the folder.

  • Page 16: Front Wheel & Front Brake

    3. FRONT WHEEL & FRONT BRAKE YOUR BIKE HAS A BOLT ON MECHANISM Remove packing block from disc Position the front wheel so it’s Align the disc brake rotor so it is brake caliper centered between the front fork centered in the slot of the brake –...

  • Page 17: Pedals

    4. PEDALS 1. Drive side of bike select R-Right pedal 1. NON drive size of bike select L-Left pedal Insert pedal into Crank/Drive side Insert pedal into Crank Arm/NON- Drive side and start to turn CLOCKWISE. and start to turn COUNTER CLOCKWISE. Once hand tight apply pedal wrench to Once hand tight apply pedal wrench to pedal pedal and tighten and secure.

  • Page 18: Fenders

    5. FENDERS You will use the 5mm allen key on this step You will use the 4mm allen key on the following 2 steps Locate front fork brake arch center Move the fixing rod to the corresponding fixing plate position hole and align front fender and and tighten the bolts on both sides.

  • Page 19: Adjustments

    6. ADJUSTMENTS Please confirm STEM AND FRONT WHEEL are in alignment.

  • Page 20: Uninstalling The Battery

    7. UNINSTALLING THE BATTERY 1. Turn key until you hear CLICK 3. Frame area is clear of battery. Check connectors toward the bottom of battery cavity 2. Lifting battery out 8. REINSTALLING THE BATTERY 1. With open battery cavity, check connectors. 3.

  • Page 21: Charge Your E-Bike

    Charge your E-Bike Before using the electric bike, you must fully charge the battery. 1. Locate the charging port. 2. Plug one side of the charger into the charging port and plug the other into an outlet. 3. A red light indicates the battery is charging, green indicates the battery is full. 4.

  • Page 22: Charge Your Battery

    Charge your Battery Plug one end of the charger into the Red light shows the battery is charging, battery and the other end into the power green light is full. supply. Power indicator: Press the button to light up. The three-color light corresponds to the power: blue(high),green(middle)and red(LOW).

  • Page 23: Tire Inflation Instructions

    Tire Inflation Instructions Tires and Tubes After assembling your bike, it will be necessary to inflate the tires. Check the sidewall of the tire for the correct tire pressure (PSI) and inflate tires accordingly with a MANUAL BICYCLE PUMP. Improper inflation is the biggest cause of tire failure. Due to the slightly porous nature of bicycle inner tubes, it is normal for your bike tires to lose pressure over time.
  • Page 24 Tire pressure is given either as maximum pressure or as a pressure range. How a tire performs under different terrain or weather conditions depends largely on tire pressure. Inflating the tire to near its maximum recommended pressure gives the lowest rolling resistance; but also produces the harshest ride. High pressures work best on smooth, dry pavement.

  • Page 25: Maintenance & Repair

    Maintenance & Repair Correct routine maintenance of your new bike will ensure a longer life for your bike and a safer ride for you. Every time you ride your bike, its condition changes. The more you ride, the more frequently maintenance will be required. We recommend you spend a little time on regular maintenance tasks.
  • Page 26 Note: The frequency of maintenance should increase with use in wet or dusty conditions. Do not over lubricate-remove excess lubricant to prevent dirt build up. Never use a degreaser to lubricate your chain (WD-40T™) Schedule2 - Service Checklist NOTE: Many instructions for adjustments can be found in the assembly portion of this manual.
  • Page 27 check all nuts and bolts are tight Every six months lubrication as per schedule 1 check all points as per monthly service check and replace brake pads, if required check chain for excess paly or wear lubrication as per schedule 1 Yearly NOTE: OWNERS ARE RESPONSIBLE FOR ALL MAINTENANCE AND SERVICE OF THE BICYCLE.

  • Page 28: Meter Function

    Meter Function Power on/off: After press and hold for 2 seconds, the meter will light up. In the power-on state, press and hold the to turn off the power of the E-bike. The bike will automatically shut down after 10 minutes of inactivity. When the instrument is turned on, it will firstly display as shown in the figure below:...
  • Page 29 Push-Assist Model: Press and hold the and do not release it. After 3 seconds, the E-bike enters the Push-Assist Model. The E-bike travels at a constant speed of 6 km/h when the push-assist logo lights up. The push-assisted model can only be used when the user pushes the E-bike, please do not use when riding.
  • Page 30 Battery capacity display: The battery capacity is displayed on the right in percentage. When the battery is fully charged, the power bar displays 100%, and each grid represents 10% of the battery capacity. Real-time speed, single mileage (TRIP) display interface: After the meter is turned on, the meter will display the real-time speed and single mileage interface by default.
  • Page 31 Maximum speed, total mileage (ODO) display interface: After the meter is turned on, the default interface of the meter is switched to the maximum speed and total mileage interface with pressing . The maximum speed indicates the highest speed during this ride, and the total mileage is the sum of the accumulated mileage of the E-bike.
  • Page 32 Setting interface: When the speed is zero, press and hold for 2 seconds to enter the setting interface. (Wheel diameter, value cannot be adjusted) Speed Limit Setting: In the speed limit setting interface, you can use short press to increase/decrease the setting. The setting range is 17-45 km/h (11-28 mph), with a default value of 32 km/h (20 mph) when shipped from the factory.
  • Page 33 Backlight setting: Press and hold at the same time for 2 seconds to enter the setting interface when the speed is zero. Press to switch to the backlight setting. Parameters 1, 2, and 3, indicating the brightness of the backlight, 1 is the darkest, 2 is the standard brightness, and 3 is the brightest.
  • Page 34 Unit setting: Press and hold at the same time for 2 seconds to enter the setting interface when the speed is zero. Press to switch to enter the unit setting interface. The setting parameters are optional km/h and MPH. The default MPH repre- sentation unit is imperial.
  • Page 35 Password enable/disable setting: Press and hold at the same time for 2 seconds to enter the setting interface when the speed is zero. After entering the general settings interface, press and hold at the same time for 2 seconds to select whether to use the power-on password or not. Initial password: 0000. After entering the password use setting, press to switch between options "y"...
  • Page 36 Modify password settings: After selecting whether to use power-on password, press to enter the interface for modifying the power-on password, firstly, input the existing 4-digit password (PS0), press to switch the number, press to confirm, and enter the modification interface after the 4-digit password input is correct. Enter the new password (PS1), if the input is wrong, return to the first digit and re-enter.

  • Page 37: Function Mode

    Function Mode 1. Three Riding Modes: Electric Assisted Mode, Pedal-Assisted Mode, Bicycle Mode. 2. Throttle Assisted Mode: When you turn the bike on, the assist level will be at 0. Press the button to increase auxiliary levels 1-5. Press the throttle to reach the start motor and move the bike.

  • Page 38: Battery Information

    Battery Information Before using the charger locate the voltage selector switch (li-ion chargers only) on the back of the charger. Select either 115 volts or 230 volts depending on your country of residence. Using the wrong voltage setting will permanenty damage the charger and/or electrical components on the hybrid electric bicycle.
  • Page 39 PRECAUTIONS FOR BATTERY PROTECTION 1. Do not place anything on the battery and charger when charging, otherwise the charger may overheat and cause serious damage. 2. Only use the charger supplied by the original factory to charge the battery, if you use a different charger your battery will be disqualified from warranty.
  • Page 40 Troubleshooting Guidance When the E-bike electric control system fails, the display will show the error codes, and only when the fault is removed can you exit the fault display program. After the fault occurs, the E-bikes can't able to continue working. Troubleshooting tips Code meaning Troubleshooting clearing...
  • Page 41 Warranty Please contact our customer service team if you are experiencing problems or need more detailed information. support@gotrax.com US team after-sales email: canada@gotrax.com CA team after-sales email: 1. Users should operate in accordance with the product manual. In case of any performance...
  • Page 44 (US) GOLABS, INC GOTRAX.com 2201 Luna Rd. Carrollton, TX 75006 (CA) Tao Motor Canada Inc. 170 Bartor Road, Unit 1 North York, Ontario M9M 2W6, Canada.
