NEVER use this product if there are any loose or missing fasteners, loose joints, broken parts, or torn mesh/fabric. Check before assembly and periodically during use. Contact Delta Children’s Product Costumer Service Department at 212-645-9033 (8:00am ~ 4:30pm PST) for replacement parts, repair or instructions.
Page 3
Parts IMPORTANT! Please remove all parts from the package and identify them before assembly. Frame Base with Wheels - 2 Liner Mattress Support Mattress Pad Cross Tubes -2 Legs -2 Canopy Storage Basket M5 X 2.6cm Screw -2 Sheet M6 x 4cm Screw – 8 2.5.Pre-installed Screw in Mobile arm -2 Mobile Mobile arm...
Bassinet Assembly Cross Tubes Storage Basket Tunnels Slots Base Note: You may need the help of another adult to help steady all parts for assembly. • Place a base on a flat surface with the slots facing up. • Fit a cross tube into each slot. Push down on each tube to be sure it is in place.
Page 5
Bassinet Assembly Receptacles Base Short Tunnels Cross Tubes Legs • First, fit the ends of a leg into short fabric sleeves in the storage basket. • Then, fit the ends of the leg into receptacle in each base. • Repeat this procedure to assemble the other leg to the storage basket and bases.
Page 6
Bassinet Assembly M6 x 4cm Screws M6 x 4cm Screws PULL PULL • Turn the assembly upright. • Insert four M6 x 4cm screws through the holes in the frame and legs. • Check to be sure the legs are secure. While gently holding the base down, pull up on the legs.
Page 7
Bassinet Assembly Mattress Support • While holding an M6 lock nut in place with the wrench, completely tighten a screw with the Philips screwdriver. • Repeat this procedure tighten the other three screws. • Place the mattress support into the frame. •...
Page 8
Bassinet Assembly Mobile Attachment Icon Liner M5 Lock Nuts Rounded Side • Attached a M5 lock nut to the end of the screw. Make sure the Mobile Arm rounded side of the lock nut faces down. Hand-tighten the lock Attachment Mount nuts onto the screws.
Page 9
Bassinet Assembly Snaps Pocket Pocket Snaps Mattress Support • Stretch the pockets on the bottom of the liner around the ends of the Snap Mattress Support mattress support. • Snap both straps on the bottom of the liner to the bottom of the mattress support.
Page 10
Bassinet Assembly hook and loop patches Canopy hook and loop Ratchet patches Frame • Position the canopy over the top end of the bassinet opposite the warning label. • Open the hook and loop fasteners on the liner and push aside foam to expose metal.
Page 11
Consumer Information WARNING Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE. • A mobile is intended for visual stimulation and is not intended to be grasped by the child. • From birth to 5 months. •...
Battery Installation Battery Compartment Cover 1.5V x 4 "AA" (LR6) In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage: • Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).
Mobile Assembly SLIDE TO REMOVE Latch • Place the mobile arm over the mobile icon located on the side rails. “snap” • Push down until you hear it into the bracket located inside the side rail. To Remove the Mobile Arm Assembly •...
Page 14
Mobile and Vibrations Unit Operation Rotate Mobile Toys Twinkling Lights Music Music / Nature Sounds Night Light Music Volume Mobile Functions On/Off Switch Mobile Functions On/Off Switch Music Button • Slide the Mobile Functions On/Off switch at the base of the •...
Retractable Wheels Wheel Lock To Lower Wheels To Retract Wheels Rocking Mode • Turn the wheel lock to lower the wheel. Make sure you hear a “click” • First, pull the wheel down . Then push it up into the base as the wheel locks in place.
Page 16
Manufactured for and distributed by: 114 West 26th Street, New York, NY 10001 Customer Service Tel. 212-645-9033 www.DeltaChildrensProducts.com MADE IN CHINA...
