Summary of Contents for Delta 6902
- Page 2 *CHECK THIS PRODUCT FOR DAMAGED HARDWARE, LOOSE JOINTS, MISSING PARTS OR SHARP EDGES BEFORE AND AFTER ASSEMBLY AND FREQUENTLY DURING USE. DO NOT USE CRIB IF ANY PARTS ARE MISSING, DAMAGED OR BROKEN. CONTACT DELTA CHILDREN'S PRODUCTS FOR REPLACEMENT PARTS AND INSTRUCTIONAL LITERATURE IF NEEDED. DO NOT SUBSTITUTE PARTS.
- Page 3 NOTES ON CARE AND MAINTENANCE: - DO NOT SCRATCH OR CHIP THE FINISH. - INSPECT THE CRIB PERIODICALLY, CONTACT DELTA CHILDREN'S PRODUCTS FOR REPLACEMENT PARTS OR QUESTIONS. - DO NOT STORE THE CRIB OR ANY PARTS IN EXTREME TEMPERATURES AND CONDITIONS SUCH AS A HOT ATTIC OR A DAMP, COLD BASEMENT.
- Page 4 PARTS A. LEFT CRIB END B. RIGHT CRIB END D. RIGHT C. LEFT CRIB POST CRIB POST F. STABILIZER BAR E. CRIB BACK RAIL POUCH ATTACHED TO MATTRESS SUPPORT - KEEP INSTRUCTIONS AND ANY EXTRA HARDWARE AND TOOLS IN THIS POUCH AFTER ASSEMBLY WARNINGS RELATED TO THE SAFE USE OF THIS CRIB ARE PRINTED ON THE POUCH...
- Page 6 SECTION 1: CRIB ASSEMBLY STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP K. BOLT - 53mm x 4 A. LEFT B. RIGHT M4 ALLEN WRENCH D. RIGHT C. LEFT SUPPLIED CRIB END CRIB END CRIB POST CRIB POST ATTACH THE LEFT CRIB END (PART A) TO THE LEFT CRIB POST (PART B) USING (2) BOLT - 53mm (PART K).
- Page 7 SECTION 1: CRIB ASSEMBLY STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP FINISHED RIGHT FINISHED LEFT CRIB SIDE CRIB SIDE J. BOLT - 66mm x 4 P. WOOD DOWEL x 2 E. CRIB BACK M4 ALLEN WRENCH SUPPLIED RAIL INSTALL THE CRIB BACK RAIL (PART E) TO THE FINISHED RIGHT CRIB SIDE AND FINISHED LEFT CRIB SIDE FROM STEP 1 USING (2) BOLT - 66mm (PART J) AND (1) WOOD DOWEL (PART P) ON EACH END AS SHOWN BELOW.
- Page 8 SECTION 1: CRIB ASSEMBLY STEP 3 PARTS AND TOOLS REQUIRED TO COMPLETE STEP F. STABILIZER BAR L. BARREL NUT x 2 M. METAL DOWEL x 2 J. BOLT - 66mm x 2 FLAT HEAD SCREWDRIVER REQUIRED FOR ASSEMBLY FROM STEP 2 - NOT INCLUDED M4 ALLEN WRENCH SUPPLIED...
- Page 11 FROM STEP 5 pre-assemled parts are tight. Store this instruction booklet for future reference. ADULT ASSEMBLY REQUIRED due to presence of small parts during assembly. ©2008 DELTA ENTERPRISE CORP. PLACE THE INSTRUCTION BOOKLET IN THE POUCH ATTACHED TO THE MATTRESS SUPPORT.
- Page 13 SECTION 2: TODDLER BED CONVERSION STEP 2 THE FINISHED TODDLER BED CAN ALSO BE USED AS A LOVESEAT SOFA.
- Page 15 SECTION 3: FULL SIZE BED CONVERSION STEP 2 BELOW IS AN EXAMPLE OF THE USE AS A HEAD BOARD. PURCHASE BED RAILS SEPERATELY. CONTACT DELTA CHILDREN'S PRODUCTS FOR HARDWARE OR INFORMATION.
- Page 16 Delta. To register your product for important safety alerts and updates to your product please visit http://deltaenterprise.com/register.asp...
