T645L/T645S LED OWNER'S MANUAL CONTENTS
1. INTRODUCTION ................................................................................ 2
2. SAFETY PRECAUTIONS ..................................................................
3. LIST OF PARTS .................................................................................
4. ASSEMBLE THE PRODUCT ............................................................. 11
STEP 0 Preparation: Inspect the Walk Belt Placement ......................... 12
STEP 1 Install the Pedestals and Handlebar Assembly ........................ 13
STEP 2 Install the Display ..................................................................... 20
STEP 3 Install the Right/Left Side Covers ............................................. 23
STEP 4 Move the Treadmill into Place for Use ...................................... 24
STEP 5 Level the Treadmill ................................................................... 25
STEP 6 Align the Walk Belt ................................................................... 26
STEP 7 Adjust the Walk Belt Tension .................................................... 27
STEP 8 Install the Power Cord .............................................................. 28
5. UNDERSTAND THE T645L/T645S LED DISPLAY ........................... 29
DISPLAY Overview ............................................................................... 29
DISPLAY Specifications .......................................................................
DISPLAY Windows ............................................................................... 30
DISPLAY Keys ...................................................................................... 30
DISPLAY Safety Key ............................................................................
6. OPERATE THE PRODUCT .............................................................
OPERATION Quick Start .....................................................................
OPERATION Start a Workout Program ...............................................
OPERATION Display ...........................................................................
OPERATION Cool Down .....................................................................
OPERATION Idle Mode .......................................................................
OPERATION Energy Smart Function ..................................................
OPERATION Workout Programs .........................................................
OPERATION User Preferences and Component Versions .................
OPERATION Error Messages ..............................................................
7. ABOUT HEART RATE DETECTION ................................................
HEART RATE Telemetry ......................................................................
HEART RATE Contact .........................................................................
8. GUIDELINES FOR EXERCISE .......................................................
9. MAINTENANCE ...............................................................................
MAINTENANCE Safety Precautions ..................................................
MAINTENANCE How to Replace a Fuse ...........................................
MAINTENANCE Lubrication System ...................................................
MAINTENANCE Schedule ...................................................................
MAINTENANCE Task List ....................................................................
MAINTENANCE One-Year Maintenance Log ......................................
10. ACCESSORIES .............................................................................
ACCESSORIES Entertainment Cap ....................................................
ACCESSORIES Options .....................................................................
11. APPENDIXES ................................................................................
APPENDIXES Electronics Block Diagram ...........................................
4
9
30
32
33
33
33
34
35
35
35
36
39
40
41
41
41
42
43
43
44
45
48
49
50
51
52
53
55
56
56
Advertisement
Table of Contents
Related Manuals for SportsArt Fitness T645S 2 Series
Summary of Contents for SportsArt Fitness T645S 2 Series
-
Page 1: Table Of Contents
T645L/T645S LED OWNER’S MANUAL CONTENTS 1. INTRODUCTION ................2 2. SAFETY PRECAUTIONS ..............3. LIST OF PARTS ................. 4. ASSEMBLE THE PRODUCT ............. 11 STEP 0 Preparation: Inspect the Walk Belt Placement ......12 STEP 1 Install the Pedestals and Handlebar Assembly ......13 STEP 2 Install the Display .............. -
Page 2: Introduction
1. INTRODUCTION Congratulations on the purchase of a high quality SportsArt product, the T645L/ T645S LED treadmill. Constructed of high quality materials and designed for years of reliable performance, this product was made for full commercial use. Before this product is assembled or operated, we recommend that you familiarize yourself with this manual. - Page 3 1. INTRODUCTION (CONTINUED)
-
Page 4: Safety Precautions
2. SAfETy PRECAUTIONS This product was designed and built for optimum safety. However certain precau- tions apply during the use of this product. Please note the following safety precautions: • Please read the entire manual before assembly and operation. Make sure the product is installed and operated as instructed in this manual. - Page 5 2. SAfETy PRECAUTIONS (CONTINUED) CAUTION: If you feel any pain or any abnormal sensations, STOP YOUR WORKOUT and consult your physician immediately. Work within your recommended exercise level. DO NOT work to exhaustion. Before beginning any exercise program, you should consult with your doctor. It is recommended that you undergo a complete physical examination.
- Page 6 2. SAfETy PRECAUTIONS (CONTINUED) If you are a French speaking person in North America, please place the sticker contained in the owner’s manual on the product as shown. Custom- ers in other areas will not receive the sticker.
- Page 7 2. CONSIGNES DE SÉCURITÉ IMPORTANTES Votre tapis de course SportsArt a été conçu et fabriqué afin d’assurer une sécurité optimale. Cependant certaines précautions s’appliquent chaque fois que vous uti- lisez votre tapis de course. • Lisez entièrement le manuel avant l’assemblage et l’utilisation. Veuillez aussi noter les consignes de sécurité...
- Page 8 2. CONSIGNES DE SÉCURITÉ (SUITE) • Pour éviter de vous blesser, restez sur les bandes de repos (barres latérales) avant de démarrer le tapis de course. • Ce tapis de course n’est pas destiné à être utilisé par des personnes (y com- pris des enfants) dont les capacités physiques, sensorielles ou mentales sont réduites ou qui ne disposent pas de l’expérience ou du savoir nécessaires, sauf si celles-ci ont au préalable été...
-
Page 9: List Of Parts
3. LIST Of PARTS Assembly Parts Name Qty. No. Name Qty. A1 Display A6b Left side cover A2 Handlebar assembly A7 Left pedestal A3 Right pedestal A8 Owner’s manual A4 Feeder cord A9 Hardware kit A5 Water guard A10 Power cord A6 Main frame A11 French Sticker (For USA) A6a Right side cover... - Page 10 3. LIST Of PARTS (CONTINUED) Components on the Product Name Specification Notes Inner hex screw M8*L25 Spring washer Serrated washer D18*d8.5*t2 Mushroom top inner hex screw M8*L20 T645S*2 T645L*4 Serrated washer (curved) D18*d8.5*t2 Mushroom top inner hex screw M8*L20 Serrated washer D18*d8.5*t2 44 Mushroom top inner hex screw M5*L12...
-
Page 11: Assemble The Product
4. ASSEMBLE THE PRODUCT Follow instructions below to assemble this product. Note that in this manual the words “left” and “right” are used to refer to the product and its parts. As such, these designations correspond to the “left” and “right” sides of a person in position to exercise on this product. -
Page 12: Step 0 Preparation: Inspect The Walk Belt Placement
STEP 0 Preparation: Inspect Walk Belt Placement Inspect the position of the walk belt in relation to the guide rollers. The walk belt should be in the groove of the guide rollers (image √). Make sure that the walk belt is not outside of the groove of the guide rollers (image X). If the walk belt is in the wrong position, press the walk belt into the groove of the guide rollers. -
Page 13: Step 1 Install The Pedestals And Handlebar Assembly
STEP 1 Install the Pedestals and Handlebar Assembly Follow instructions below to install the pedestals and handlebar assembly. The illustration below provides an overview of this step. - Page 14 STEP 1 Install the Pedestals and Handlebar Assy (Cont.) Follow instruction (a) below. (a) Remove screws (41) from the pedestal mount area. Inspect whether the screw sockets in areas A and B are in place on the product. If not, remove them from the hardware kit and insert them into place on the product.
- Page 15 STEP 1 Install the Pedestals and Handlebar Assy (Cont.) Follow instructions (a through d) below to thread the data cable through the right pedestal. Before assembly, make sure the left & right pedestals are align with left and right sides on the main frame. (a) Pull the cable from the right side of pedestal mount.
- Page 16 STEP 1 Install the Pedestals and Handlebar Assy (Cont.) For T645L, cut out the cutaway in area C of the main frame (A6) before installing the pedestals. (Note: Cut out the cutaway on both sides.) Hold the data cable at the top of the right pedestal (A3), and insert the bottom of the right pedestal (A3) onto the pedestal mount.
- Page 17 STEP 1 Install the Pedestals and Handlebar Assy (Cont.) Follow the instructions (a through f) to finish install handlebar assembly. (a) Remove screws (42, 43) from the mounting plates on the bottom of the handlebar assembly (A2). (Note: T645S has two sets screws (42) and T645L has four sets screws (42).) (b) Place the left side of handlebar assembly (A2) into left pedestal (A7).
- Page 18 STEP 1 Install the Pedestals and Handlebar Assy (Cont.) (d) Place the right side of handlebar assembly (A2) into right pedestal (A3). Make sure the cable is not shown or pinched. (e) Put the previously removed screws (42, 43) back into the pedestals. Tighten the screws (42) in area B first, then tighten the screws (43) in area C next.
- Page 19 STEP 1 Install the Pedestals and Handlebar Assy (Cont.) After the handlebars are in place, secure pedestal screws in area A on left and right sides.
-
Page 20: Step 2 Install The Display
STEP 2 Install the Display Follow instructions below to install the display onto the cowling. The illustration below provides an overview of this step. - Page 21 STEP 2 Install the Display (Continued) Please follow steps (a through f) to install the display. (a) First, remove screws (44) from the display mount on the handlebar assembly (A2). (b) Place the display (A1) onto the handlebar assembly (A2) Note: make sure the display is aligning with its guiding pieces to avoid damaging the control board.
- Page 22 STEP 2 Install the Display (Continued) (d) Connect cables in areas A & B. (e) After securing cable connections, arrange all the cables nicely, Afterwards push the display (A1) slightly upward, aligning it correctly, then press it into place on the handlebar assembly. Note: make sure the cables are not pinched.
-
Page 23: Step 3 Install The Right/Left Side Covers
STEP 3 Install the Right/Left Side Covers Put the right/left side covers (A6a) (A6b) in place and secure them with screws (40). Finally, put the water guards (A5) down against the motor cover on both sides. -
Page 24: Step 4 Move The Treadmill Into Place For Use
STEP 4 Move the Treadmill into Place for Use First, place hands under the frame in area A, lift the treadmill and then roll it into position as desired. -
Page 25: Step 5 Level The Treadmill
STEP 5 Level the Treadmill Press downward on the rear part of the treadmill as shown. Inspect whether the treadmill rests flat on the floor. If the treadmill wobbles, adjust treadmill levelers as follows: (a) Loosen the leveler nut. (b) Rotate the leveler foot downward, touching the floor. (c) Rotate the leveler nut upward, against the frame of the product, to secure this position. -
Page 26: Step 6 Align The Walk Belt
STEP 6 Align the Walk Belt (a) First, make sure the treadmill is on a leveled surface and the incline is at (b) Start the speed at a lower rate of 3kph/2.5mph to check if the walk belt is aligned and there is an equal amount of space between walk belt and side-rails on both sides. -
Page 27: Step 7 Adjust The Walk Belt Tension
STEP 7 Adjust Walk Belt Tension Walk belt tension is important to treadmill performance. As your foot hits the walk belt, does the walk belt stop sluggishly before regaining traction? Or, if you stomp your feet, bracing against the direction of rotation, does the walk belt not pause whatsoever? When either of these two conditions occurs, walk belt tension should be adjusted. -
Page 28: Step 8 Install The Power Cord
STEP 8 Install the Power Cord First remove screws (45) from the power cord socket on the product. Insert the power cord into place on the product. Secure the power cord (A10) connector screws (45). And insert the other end of the power cord into the power socket on the wall. -
Page 29: Understand The T645L/T645S Led Display
5. UNDERSTAND T645L/T645S LED DISPLAy DISPLAy Overview The T645L/T645S LED display was designed to help people obtain their fitness goals simply and conveniently. Please familiarize yourself with the features of this display and thereby get optimum benefit and enjoyment from this product. -
Page 30: Display Specifications
DISPLAy Specifications ● Speed: 0.2 to 20.0 kph; 0.1 to 12.0 mph ● Incline: 0% to 15%, in increments of 0.5% ● Time: 0:00 - 300:00 ● Distance: 0.00 - 9999 km or mile ● Calories: 0 - 9999 kcal ●... - Page 31 DISPLAy Keys (Continued) RANDOM – Press this key to select one of an almost endless number of randomly generated workout programs. Each key press, the console will randomly generate a different program. INTERVAL – Press this key to select one of three interval programs: 1:1, 1:2, 2:2. Numbers represent minutes.
-
Page 32: Display Safety Key
DISPLAy Keys (Continued) VOLUME + / - : iPod, iPhone analog audio volume adjustment. (Note: this is an option feature and it is only compatible with Apple 30 pin connector.) MYE wireless TV audio channel receivers volume adjustment. (MyE Wireless TV Audio_Channel Receivers and module not provided.) CHANNEL ▲/▼... -
Page 33: Operate The Product
6. OPERATE T645L/T645S LED TREADMILL There are two ways to start operating this product: (1) Press the QUICK START key, or (2) press the PROGRAM/GOAL SELECTION key to enter a preset program. Using the QUICK START key allows you to begin exercising immediately, without first entering user information. -
Page 34: Operation Display
OPERATION Start a Workout Program ● The CALORIE setting range is from 100 to 9999 kCal, with a default value of 100 kCal. Use ▲/▼ keys or numeric keys (0-9) to make your selection. Press the ENTER key to confirm your setting and proceed to the age setting. -
Page 35: Operation Cool Down
OPERATION Cool Down Once the workout goal (time, distance, or calorie expenditure) has been ob- tained, the product will enter a two-minute cool down period. The display will count down from two to zero. When the countdown reaches zero, the cool down period will end. The mes- sage “REVIEW SUMMARY”... -
Page 36: Operation Workout Programs
OPERATION Workout Programs Workout program details are explained below. MANUAL This program allows you to manually control speed and incline. In manual mode, simply press SPEED ▲/▼ keys to control speed and INCLINE ▲/▼ keys to adjust incline. HILL There are three hill workouts, HILL 1, HILL 2, and HILL 3, each of which is represented by a different hill illustration. - Page 37 OPERATION Workout Programs (Continued) The TRACK 5K workout automatically has a goal of 5 kilometers. (If the time limit function is activated, the time limit will become the workout goal.) The TRACK 10K workout automatically has a goal of 10 kilometers. (If the time limit function is activated, the time limit will become the workout goal.) fAT BURN In this program, there are 1-20 different difficulty levels to select from.
- Page 38 OPERATION Workout Programs (Continued) CARDIO & WT LOSS & ZONE TRAINER In heart rate control programs, speed or incline values automatically adjust to keep the exerciser’s pulse at the optimum rate to obtain his or her fitness goals. Target heart rate calculations are a percentage of a “maximum” heart rate based on age.
-
Page 39: Operation User Preferences And Component Versions
OPERATION User Preference and Component Versions User preference settings allow you to change default settings and review some historical data of this product. To access user preference settings, press the CHANGE DISPLAY key for 2 seconds during Banner page. ● Unit setting: the default unit is English. On the message window, “UNIT –... -
Page 40: Operation Error Messages
OPERATION Error Messages Error messages can appear on this treadmill as a troubleshooting aid. Error messages appear in the following format: “ERROR _X_Y”. X represents the category of the error. Y represents the specific issue. In the position of the X placeholder, the following numbers can appear to represent the category of the malfunction: Code Explanation... -
Page 41: About Heart Rate Detection
7. ABOUT HEART RATE DETECTION Heart rate detection functions are selected at the time of purchase. Not every product includes every type of heart rate detection device. The following explains factors that influence the performance of two of the most common types of heart rate detection devices. -
Page 42: Guidelines For Exercise
Note that in dry areas in particular, static electricity can interfere with unit operation and shock people. To discharge static electricity from your body, touch something else before touching metal on the product. 8. GUIDELINES fOR EXERCISE HOW HARD SHOULD I EXERCISE? Studies show that to benefit from aerobic exercise, people need to maintain a certain heart rate during their workouts. -
Page 43: Maintenance
9. MAINTENANCE This section covers maintenance topics, including instructions on replacing a fuse and lubricating the walk belt, along with the presentation of a main- tenance schedule, maintenance task list, one-year maintenance log, and electronics block diagram. MAINTENANCE Safety Precautions ●... -
Page 44: Maintenance How To Replace A Fuse
MAINTENANCE How to Replace a fuse If electrical current becomes too high, the fuse breaks. This protects the product. To replace a fuse, follow instructions (a) through (g) below. (a) Press the fuse cap inward. using a tool. (b) Turn the fuse cap counterclockwise. (c) The fuse cap springs out. -
Page 45: Maintenance Lubrication System
MAINTENANCE Lubrication System Lubrication System flowchart Model No. Display ex: T655 Total Exercise 5 seconds Distance Display (km) Power On RESET Walks Belt Version Display Total Exercise Total Exercise Total Exercise Speed Total ex:T655 Distance Display (mile) Distance Display (km) Distance Display (km) Running Time... - Page 46 MAINTENANCE Lubrication System (Continued) To replace the lubricant bottle, follow instructions (a) through (d) below. (a) Loosen the screws on the bezel and push the bezel up. (b) Take the old lubricant bottle out. (c) Unscrew the nozzle from the old lubricant bottle and screw it onto new bottle.
- Page 47 MAINTENANCE Lubrication System (Continued) Error Messages: There are 2 error messages with this system. Error 1: It indicates that the system memory failing and it will not be able to perform any auto lubrication. Error 2: It indicates motor is failing or system will not be able to perform any function.
-
Page 48: Maintenance Schedule
MAINTENANCE Schedule Area Day Week Month Quarter Year Notes Exterior Clean. Screws Inspect and secure loose parts. Treadmill test Ensure the treadmill operates properly. Inspect alignment (centering) and look Walk belt for wear. Walk deck Inspect for wear. Belt guides Inspect for normal rotation. -
Page 49: Maintenance Task List
MAINTENANCE Task List Like cars, fitness products require maintenance. Regular maintenance ex- tends product life, and failure to maintain products can void the manufac- turer’s warranty. Copy the maintenance log sheet, and record maintenance work for each fitness product. Daily tasks 1. -
Page 50: Maintenance One-Year Maintenance Log
MAINTENANCE One-year Maintenance Log Facility:_______________________ Supervisor:____________________ Product model number:__________ Serial number:_________________ Start date: ____________________ End date:_____________________ Daily Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Week 22-28 Completed Daily Tasks Week 29-35 Week 36-42 Week 43-49 Week 50-52 Completed Weekly Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Weeks 22-28... -
Page 51: Accessories
10. ACCESSORIES There are accessories attached to this console; some are standard and some are optional. The following explains the details of each accessory and its function. USB CHARGER (Standard) The USB charger will provide 5V 500mA voltage for the smart phone or other devices charging. -
Page 52: Accessories Entertainment Cap
ACCESSORIES Entertainment Cap (a) RFID member card slot: work with both optional SA WELL+ and ECOFIT member cards. (Not available yet.) (b) Bluetooth/WIFI connection button: press this button to pair the smart phone SA WELL+ App. (c) USB port: this port is used for device charging as well as optional data transferring. -
Page 53: Accessories Mye Wireless Tv Audio_Channel Receivers
ACCESSORIES MyE Wireless TV Audio_Channel Receivers If your equipment has been installed MYE Wireless TV Audio_Channel Receivers, the display must has Channel Keys. Please make sure your equipment is with the correct sticker as below. (a) None Treadmill (Bike, Elliptical and Stepper...etc.) Left display: Without Channel Keys. - Page 54 ACCESSORIES MyE Wireless TV Audio_Channel Receivers(Cont.) MyE Wireless TV Audio_Channel Receivers fuctions: 1. The receiver has two kinds of module as below. (Note: MyE Wireless TV Audio_Channel Receivers and Module not provided.) (1). MC3R-9(900MHZ) must work with MYE Wireless TV Audio_Channel Receivers MWTD-S9.
-
Page 55: Accessories Options
ACCESSORIES Options 1. Fan Set 2. External Mount TV Bracket 3. Long Handrails... -
Page 56: Appendixes
11. APPENDIXES APPENDIXES Electronics Block Diagram iPod Audio Board USB Board RFID Board Head Phone Board Option CSAFE Board Continua Adapter Board Option Control Board Numeric Key Board SA WELL+ Connection key HTR Board HRC Board Contact HTR plates Fan Board Bridge Board Safety Key Board Option... - Page 57 your Authorized Distributor...
