TV System Cable Connections
TABLE OF CONTENTS
1. INTRODUCTION..................................................................................................
2. IMPORTANT SAFETY PRECAUTIONS...............................................................
3. ASSEMBLING YOUR TREADMILL......................................................................
List of Parts...........................................................................................................
4. TREADMILL ASSEMBLY.......................................................................................
Pedestal and Handle Assembly Steps.................................................................
Display Installation Steps......................................................................................
Connect to Power.................................................................................................
TV System Cable Connections............................................................................
5. T680 DISPLAY.....................................................................................................
Display Features..................................................................................................
Display Functions................................................................................................
Button Functions..................................................................................................
Safety Key............................................................................................................
6. HOW TO USE YOUR T680 TREADMILL............................................................
Quick Start...........................................................................................................
Workout Setup.....................................................................................................
Operating Procedure While Working...................................................................
Cool Down...........................................................................................................
7. PROGRAMS.......................................................................................................
User Parameter Setting.......................................................................................
Automatic channel scan......................................................................................
8. GUIDELINES FOR EXERCISE...........................................................................
9. ADJUST THE WALK BELT..................................................................................
10. FLOOR LEVEL ADJUSTMENT.........................................................................
11. MAINTENANCE.................................................................................................
12. MAIN FUSE FAILURE......................................................................................
13. ERROR MESSAGE..........................................................................................
14. WIRING SCHEMATIC.......................................................................................
1
2
4
4
6
6
9
11
12
15
15
16
17
19
20
20
20
21
22
23
24
25
31
32
34
35
39
40
41
Advertisement
Table of Contents
Related Manuals for SportsArt Fitness T680
Summary of Contents for SportsArt Fitness T680
-
Page 1: Table Of Contents
Connect to Power....................TV System Cable Connections................5. T680 DISPLAY..................... Display Features....................Display Functions....................Button Functions....................Safety Key......................6. HOW TO USE YOUR T680 TREADMILL............Quick Start......................Workout Setup..................... Operating Procedure While Working..............Cool Down......................7. PROGRAMS....................... User Parameter Setting.................. -
Page 2: Introduction
INTRODUCTION Congratulations on purchasing one of the finest pieces of commercial exercise equipment on the market today, the SportsArt T680 Commercial Treadmill. The T680 is designed with the end-user in mind and constructed of high quality materials and designed for years of trouble-free use. -
Page 3: Important Safety Precautions
Your SportsArt treadmill was designed and built for optimum safety. However, certain precautions apply whenever you use your treadmill. Please read the entire manual before assembly and operation. Also, please note the following safety precautions: IMPORTANT SAFETY PRECAUTIONS ˙ Please read the instruction carefully and install the treadmill as instructed. ˙... - Page 4 Check with a qualified electrical or service person if you are in doubt as to whether the treadmill is properly grounded. DO NOT modify the plug provided with T680 treadmill, if it doesn't fit the outlet; get the proper outlet installed by a qualified technician.
-
Page 5: Assembling Your Treadmill
ASSEMBLING YOUR TREADMILL Thank you for purchasing our product. Even though we go to great efforts to ensure the quality of each product, occasional errors and/or omissions do occur. In any event should you find the product to be defective or missing a part, please contact your local dealer. - Page 6 14. One double open wrench (22/24) (In vacuum-packed container) 15. One fuse 15A (110V) / 10A (220V) (In vacuum-packed container) 16. Six M8*L18 socket-head screws (For pedestals - on the treadmill) 17. Six M8 spring washers (For pedestals - on the treadmill) 18.
-
Page 7: Treadmill Assembly
TREADMILL ASSEMBLY PEDESTAL AND HANDLE ASSEMBLY STEPS When you remove the treadmill from its box, first check to make sure all of the parts are present. Then, read through the assembly instructions before you begin. STEP 1 . Use the PHILLIPS-HEAD SCREWDRIVER to remove the screws (3 pcs) from the side plates of the motor cover (both left and right) and remove... - Page 8 STEP 3. Use the PHILLIPS-HEAD SCREWDRIVER to remove left and right cup holders. (See Fig. 3.) Fig.3 STEP 4. Hold the handlebars onto the bracket on the pedestals. Then pull the data → → cable on the right pedestal through the right handle (C D E). Remove the tie on the data cable set.
- Page 9 STEP 5. Use the ALLEN WRENCH WITH THE L-SHAPED HANDLE (6 mm) securely tighten the pedestal screws in place; then put the side covers (both left and right) in place (FG) and secure them with the Phillips-head screws. Finally, set the waterproof rings in place near the hood. (See Fig. 5.) Fig.5...
-
Page 10: Display Installation Steps
DISPLAY INSTALLATION STEPS STEP 1. Use the ALLEN WRENCH WITH THE T-SHAPED HANDLE (4 mm) remove the four bolts from location (A) shown below. Hold the display into position and connect data cables and DTV cables. (See Fig. 6-1~6-3.) Use CABLE WRENCH to secure the cable. - Page 11 STEP 2. Rotate the display upward and fit it onto the handlebars. Using points (A), pivot the display back without pinching the wires. (See Fig. 7.) Fig.7 STEP 3. With one hand behind the display for support, push the display down gently until it connects securely.
-
Page 12: Connect To Power
STEP 4. Use the HEX ALLEN WRENCH WITH THE T-SHAPED HANDLE (4 mm) secure the display with the bolts as shown below. (See Fig. 9.) Fig.9 CONNECT TO POWER Connect the power cable as indicated in Fig.10, and secure it by tightening the screws. -
Page 13: Tv System Cable Connections
TV System Cable Connections The T680 treadmill is designed to receive TV signals in analog and digital formats. Analog (CATV) systems include NTSC, PAL, and SECAM. Digital (DTV) functionality allows for reception of over-the-air digital TV signals. Determine the type of analog TV signal (NTSC or PAL/SECAM) used in your area. - Page 14 2. Analog cable CATV and digital over-the-air signals with antenna Ca ble TV Antenna Fig.13 3. Analog and digital TV reception via a common external antenna and 2-way splitter or "T connector" Antenna Fig.14 CATV (Analog) System Set Up The CATV system setup is usually programmed into the product at the factory. If the CATV system of the product was not set at the factory, it may be necessary to activate the CATV system on the product.
- Page 15 Automatic Channel Scan (Analog) After connecting cables and providing TV signal, perform an automatic channel scan to locate channels as follows: 1. Turn the treadmill on. 2. Press the Source key to enter the TV mode. 3. Simultaneously, press Volume Down and Channel Up. The automatic channel scan function begins.
-
Page 16: T680 Display
T680 DISPLAY A. Display features Message Row Cardio Advisor Workout Goal Multimedia Dot Matrix Information Percentage Completed Selection Display Window... -
Page 17: Display Functions
Goal Setting Keys Setting Window Numeric Keypad Programs B. Display functions 1. SPEED: 0.1 to 15.0 MPH or 0.2 to 24.0 KPH in 0.1 increments 2. INCLINE: 0 to 15% in 0.5% increments 3. TIME: 0:00 to 99:59 4. DISTANCE: 0.01 to 9999 Km/Mile 5. -
Page 18: Button Functions
6. CAL/Hr: Calories burnt per hour, 0.0 to 999.9 KCAL 7. METS (Metabolic burn rate): 0.0 to 99.0 8. PROGRAM: Track, Random, Glute, Interval (1:1, 1:2, 2:2), 5K (Flat, Hill), 10K (Flat, Hill), Wt Loss, Cardio, Custom HR and Fit Test (Bruce or Gerkin) 9. - Page 19 11. RANDOM Press RANDOM to generate different courses. 12. GLUTE This program is specifically designed to exercise the gluteus muscle group of the body; 30 and 45 minute durations are available in these incline-based programs. 13. INTERVAL There are three kinds of INTERVALs (1:1, 1:2 and 2:2). For example, in 1:2, 1 = one minute of rest;...
-
Page 20: Safety Key
22. STOP/HOLD TO RESET a. While exercising: (1) If you pressed QUICKSTART to start exercising, press STOP to stop. (2) If you entered user information to start exercising, press STOP to stop the treadmill and enter pause mode. b. Under any status: Hold this button to reset to the banner display. -
Page 21: How To Use Your T680 Treadmill
HOW TO USE YOUR T680 TREADMILL 1. QUICK START If you select QUICKSTART, "TREAD STARTING" appears on the display and the walk belt moves at 0.1mph/0.2kph, after which the speed can be modified. The user information default is 165lbs/75kgs. WORKOUT SETUP... -
Page 22: Operating Procedure While Working
(2) WEIGHT: From 50 to 400LB / 20 to 140 KG (default value: 165LB / 75KG). ▲ ▼ a. Press or the numeric keypad to select your weight. b. Press ENTER to confirm your choice. D. PROGRAM SETTING PROCEDURE (1) When the previous selected program is Custom HR, the range of the TARGET HR is 84 ~ 200 bpm (default value: 120 bpm). -
Page 23: Cool Down
(2) WORKOUT GOAL Percent Complete. (3) Wt Loss Training Zone & Cardio Training Zone: the HR will be different because of age. (4) Setting window: to display the selected WORKOUT GOAL. C. Users can adjust settings while working: Programs can be changed during exercise. Press the corresponding program button to change programs. -
Page 24: Programs
PROGRAMS 1. TRACK One lap is equal to 400M (0.25 Mile). 2. RANDOM The random program includes an infinite number of programs. Continue to press this button until you find a course to your liking. 3. GLUTE The glute program is specifically designed to exercise the gluteus muscles. Press to choose between 30- and 45-minute programs in this incline-based exercise mode. -
Page 25: User Parameter Setting
(2) The message row displays "1-INGL 2-SPEED". Press 1 or 2 from the numeric keypad to select your heart rate control mode via speed or incline control. Press ENTER to complete your stepup. (3) Select SPEED control Before starting to exercise, select the maximum speed. The message row ▲... -
Page 26: Automatic Channel Scan
2. Display the total accumulative distance. The message row will display "DIST - XXXXXX MILE" or "DIST - XXXXXX KM". Press ENTER to confirm your choice or press STOP to quit (without changing parameters). 3. Display the total accumulative time. The message row will display "TIME - XXXXXX HOUR". - Page 27 DTV (ATSC-USA) Digital TV Functions 1. Operation: In DTV mode, press CH+ and VOL+ to access the ATSC digital TV menu. SportsArt Caption Setup V -Chip Channel Illustration (Remote) In menu mode, keys have the following functions: ▲ ˙ CH+ becomes scroll up. (UP) ●...
- Page 28 Caption Setup Chip SportsArt Channel Channel Signal Quality Auto Program Manual Program SportsArt Caption Setup Chip Channel Channel Signal Quality Auto Program Warning: Auto program Manual Program May erase all existing Channels! Press OK to Continue. Caption Setup Chip SportsArt Channel Channel Signal Quality...
- Page 29 SportsArt DTV TV screen B. Closed caption for the hearing impaired includes the following functions: (1) Mode on/off and on Mute characters （ (2) Analog CC: Analog TV Closed Caption This function does not operate on ） ATSC DTV. (3) Digital CC: Digital TV Closed Caption (4) Font size selection (5) Font color selection (6) Font style selection...
- Page 30 SportsArt Caption Setup Chip Channel Setup Adjust Language Time Zone Sleep Transparency Theme Info Services ★ ATSC DTV brightness, contrast, saturation, color adjustment: From menu select Setup. Then select Setup Adjust to adjust （ Brightness, Contrast, Saturation, Hue Use CH+, CH- to select ）...
- Page 31 c. V-Chip: This function requires a license. The user must pay and apply for a V-Chip royalty number. SportsArt Caption Setup V -Chip Channel Enter Password： Special notes In menu mode, if no activity is selected within 15 seconds, the display returns to （...
-
Page 32: Guidelines For Exercise
GUIDELINES FOR EXERCISE How hard should I exercise? Studies show that to achieve the benefits of aerobic exercise, it is necessary to work within your training zone. Your training zone depends on your age and level of fitness. The above chart indicates the recommended Heart Rate training zones (darkened area of the chart). -
Page 33: Adjust The Walk Belt
ADJUSTING THE WALK BELT For optimum performance, the walk belt must track in the center of the deck. Failure to align the belt properly could cause the belt to tear or fray, which is not covered under the warranty. Caution: To avoid injury, special care must be taken when adjusting the walk belt. - Page 34 6. If the belt is too far right, turn the right adjustment bolt clockwise 1/4 turn, then turn the left adjustment bolt counterclockwise 1/4 turn. Turn on the treadmill. Press the SPEED button to increase the speed until the speed reaches 2.0 mph/3.2kph on the display.
-
Page 35: Floor Level Adjustment
Periodically monitor the position of the belt to ensure peak performance To avoid injury, special care must be taken when adjusting the walk belt. Remove any loose clothing or shoes lace and tie back your hair. Be very careful to keep your fingers or any other objects clear of the belt and rollers. -
Page 36: Maintenance
MAINTENANCE Periodic maintenance is crucial to the performance of fitness equipment, just like it is to the performance of an automobile. The better you maintain a product, the longer it will serve your needs. This treadmill requires periodic lubrication of the walk belt and has a built-in system to prevent overuse without maintenance. - Page 37 1. Remove one treadmill end cap. ▲ ▼ 2. Simultaneously press and hold INCLINE + INCLINE + 0 keys for two seconds. The treadmill will operate at low speed. At this point, no UP or DN keys will operate. 3. Insert the applicator tube so the line on the applicator touches the side of the walk belt.
- Page 38 6. Remove the applicator and the bottle of lubricant. 7. Secure the end cap on the treadmill. 8. Then the message "PLEASE PRESS THE STOP KEY AFTER FINISHING LUBRICATION" appears. Press the STOP key to complete the lubrication procedure. The treadmill will recalculate the total distance and operate normally.
- Page 39 Lubricating When Not prompted The physical task of lubricating the treadmill can be done at any time. When the startup banner, SPORTSART-T680, is displayed, simultaneously press and hold ▲ ▼ INCLINE + INCLINE + 0 for two seconds. The motor will operate at low speed at which time you can apply lubricant to the walk belt.
-
Page 40: Main Fuse Failure
Turn the fuse holder clockwise to secure the fuse in place. (See Fig. 15-2 to Fig. 15-4.) Fig.15-1 Fig.15-2 Fig.15-4 Fig.15-3 If the unit does not work after changing the fuse, please contact your authorized SportsArt Fitness service technician for more information. -
Page 41: Error Message
ERROR MESSAGES 1. Display format: 2. Explanations for each error message: ERROR_1_1_ The AC servo motor encoder is out of order. Please re-start the unit. ERROR_1_2_ The AC servo motor is overheated. Speed is restricted to half. ERROR_1_3_ The AC servo motor suddenly accelerated. Please re-start the unit. ERROR_2_1_ The IGBT current is too high. -
Page 42: Wiring Schematic
Wiring Schematic: T680 Your Authorized Distributor...
