OPERATION MANUAL
AIR CONDITIONER
Cassette type
□ AUTH09KVLA
□ AUTH12KVLA
□ AUTH18KVLA
MODEL:
* Please check the model name.
(Refer to the rating label.)
R32
REFRIGERANT
This Air Conditioner contains and
operates with refrigerant R32.
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED
BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation,
regulations, codes, installation & operation manuals, before
the installation, maintenance or service of this product.
PART No. 9383813085
Before using this product, read these instructions
thoroughly and keep this manual for future
reference.
Advertisement
Table of Contents
Related Manuals for Fujitsu AUTH09KVLA
Summary of Contents for Fujitsu AUTH09KVLA
- Page 1 OPERATION MANUAL AIR CONDITIONER Cassette type □ AUTH09KVLA □ AUTH12KVLA □ AUTH18KVLA MODEL: * Please check the model name. (Refer to the rating label.) REFRIGERANT This Air Conditioner contains and operates with refrigerant R32. THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED Before using this product, read these instructions BY QUALIFIED PERSONNEL.
-
Page 2: Table Of Contents
[Original instructions] Contents CAUTION This symbol shows that the operation manual should 1. SAFETY PRECAUTIONS .......... 1 be read carefully. 2. PREPARATION ............2 CAUTION 3. NAME OF PARTS ............. 3 This symbol shows that a service personnel should be handling this equipment with reference to the 4. -
Page 3: Preparation
WARNING CAUTION • This product is not intended for use by persons • Do not expose animals or plants to the direct airfl ow. (including children) with reduced physical, sensory • Do not drink the drainage from the air conditioner. or mental capabilities, or lack of experience and •... -
Page 4: Name Of Parts
3. NAME OF PARTS 4. BASIC OPERATIONS For detailed instructions on how to operate, refer to the NOTES: For detailed instructions on how to operate, refer to the operation manual of the remote controller. operation manual of the remote controller. When you use the optional remote controller, the operation The operation mode and the temperature setting range are procedure may diff... -
Page 5: Airflow Settings
5. AIRFLOW SETTINGS 6. TIMER OPERATIONS NOTES: For detailed instructions on how to operate, refer to the 6.1. On timer or Off timer operation manual of the remote controller. 5.1. Fan speed setting The On timer starts the operation at your desired time. The Off... -
Page 6: Demand Response
(1) Contact your electricity supplier to check whether they are activating the DR mode. (2) Is the air conditioner under the Demand controlling? Contact your electricity supplier. No • Contact Fujitsu General (AUST.) PTY LIMITED. (Refer to your warranty card.) • Visit our website (www.fujitsugeneral.com.au). • Air intake grille •... -
Page 7: General Information
Cleaning air fi lter 10. GENERAL INFORMATION Push the intake grille’s ■ Inverter hooks inward towards the On start-up, the air conditioner will operate at maximum capacity to center of the unit to open bring the room quickly down to desired temperature. the intake grille. -
Page 8: Optional Parts
■ When indoor and outdoor temperatures are ● If you discover that 1 or more units delivers a low level of cooling or heating during simultaneous operation, we recommend that you stop high simultaneous operation of the multiple units. When both indoor and outdoor temperatures are high during use of the ●... - Page 9 Poor cooling or heating performance. Airfl ow direction does not change according to the setting or does not change at all. □ Is the unit operating under the conditions except the permissible temperature range? □ <In the Auto mode> In the Auto mode, the airfl ow direction is set In this case, the air conditioner may stop because of the automatic automatically.
- Page 10 Immediately stop operation and turn off the electrical breaker in following cases. Then consult authorized service personnel. • The problem persists even if you perform these checks or diagnostics. • Error sign is shown on the wired remote controller display or the indicator lamps on the indoor unit.
