- Page 1 AIR CONDITIONER Cassette type DESIGN & TECHNICAL MANUAL SINGLE INDOOR AUTA30LBLU OUTDOOR AOTA30LBTL AOTA30LFTL AOTA30LGTL...
- Page 2 1. INDOOR UNIT CASSETTE TYPE : AUTA30LBLU D2D_AU036E/06 2011.11.07...
-
Page 3: Table Of Contents
CONTENTS 1. INDOOR UNIT 1. FEATURE ........................01 - 01 2. REMOTE CONTROLLER ................01 - 04 3. SPECIFICATIONS ....................01 - 06 4. DIMENSIONS ......................01 - 07 5. WIRING DIAGRAMS ..................01 - 09 6. CAPACITY TABLE .................... 01 - 10 6-1. -
Page 4: Indoor Unit
FEATURE MODEL INDOOR UNIT OUTDOOR UNIT AOTA30LBTL AUTA30LBLU AOTA30LFTL AOTA30LGTL FEATURES Energy saving • All DC design • Heat exchange efficiency increased and larger air flow by adoption of new type turbo fan Advancement in comfort • Quiet operation was realized by adoption of new type turbo fan •... -
Page 5: Improvement Of Installation & Maintenance
3 Wide & powerful airflow The wind is widely delivered by a high efficiency fan and round flap. [ m ] Side view [ m ] Airflow range of 2m / s Improvement of installation & maintenance • Adjustment of nut is possible after installation Mounting position of body can be fine adjusted after Decoration panel mounting. -
Page 6: Function Setting
FUNCTION SETTING Outlet direction selection • Performs operation matched to the number of outlets when 4 directions are unnecessary and outlets are blocked when the ceiling cassette is installed in a corner, etc. 4-way direction 3-way direction 4-way direction mode: Set when there are 4 outlets (shipped state). -
Page 7: Remote Controller
REMOTE CONTROLLER WIRED REMOTE CONTROLLER FEATURES Various timer setup (ON / OFF / WEEKLY) are possible. Equipped with weekly timer as standard function. (2 times Start / Stop per day for a week) When setting up a timer, operation mode and a temperature setup can be changed. -
Page 8: Specification
FUNCTIONS START/STOP button Pressed to start and stop operation. SET TEMP. button Selects the setting temperature. MODE button Selects the operating mode(AUTO, HEAT, FAN, COOL, DRY). FAN button Selects the fan speed (AUTO, QUIET, LOW, MED, HIGH). ECONOMY button Turns the economy efficient mode on and off. TIMER MODE (CLOCK ADJUST) button Selects the timer mode (OFF TIMER, ON TIMER, WEEKLY TIMER). -
Page 9: Specifications
SPECIFICATIONS CASSETTE MODEL Type INVERTER HEATPUMP Indoor unit AUTA30LBLU Model name AOTA30LFTL Outdoor unit AOTA30LBTL AOTA30LGTL Power source 240V ~ 50Hz Available voltage range 198 - 264V ~ 50Hz Cooling STAR RATING INDEX 10 STAR standard Heating 8.50 Rated Btu/h... -
Page 10: Dimensions
DIMENSIONS MODEL : AUTA30L Ceiling opening and hanging bolt pitch (Unit : mm) 950 mm(Panel frame) 860 - 910 mm(Ceiling opening) 840 mm(Body frame) 795 mm(Hanging bolt pitch) 50 mm 130 mm 200 mm Refrigerant piping and drain piping positions 358 mm 278 mm 60 mm... -
Page 11: Installation Place
INSTALLATION PLACE (Unit : mm) Strong and durable ceiling 1,500 or more 3,000 or more Ceiling mode “Low” : 2.7 m Obstruction Ceiling mode “Standard” : 3.2 m Ceiling mode “High” : 3.6 m Floor 3-way directions setting (Unit : mm) 100 or more To set “3-way directions”, the air outlet shutter plate (UTR-YDZC) sold separately must be installed and “outlet-direction”... -
Page 12: Wiring Diagrams
WIRING DIAGRAMS MODEL : AUTA30L - (01 - 09) -... -
Page 13: Capacity Table
CAPACITY TABLE 6-1. COOLING CAPACITY This table is created using the maximum capacity. MODEL : AUTA30L 26.7 Indoor temperature °CDB °CWB °CDB 8.67 6.58 1.20 9.66 6.62 1.22 9.99 7.20 1.22 10.65 7.22 1.24 10.98 7.80 1.24 11.64 7.77 1.25 12.29 8.27 1.27 8.52 6.38... -
Page 14: Heating Capacity
6-2. HEATING CAPACITY This table is created using the maximum capacity. MODEL : AUTA30L 26.7 Indoor temperature °CDB °CDB °CWB 8.34 3.37 8.14 3.44 7.94 3.51 7.75 3.58 7.55 3.65 8.79 3.38 8.58 3.45 8.37 3.52 8.16 3.59 7.95 3.66 9.55 3.41 9.32... -
Page 15: Fan Performance
FAN PERFORMANCE 7-1. AIR VELOCITY DISTRIBUTION Note: Condition 7-1-1. STANDARD MODE Fan speed : High Operation mode : FAN Ceiling mode : Standard MODEL : AUTA30L 4-way air outlet Unit : m/s TOP VIEW VERTICAL LOUVER : Upward Unit : m/s SIDE VIEW VERTICAL LOUVER : Upward... - Page 16 Note: Condition Fan speed : High Operation mode : FAN Ceiling mode : Standard MODEL : AUTA30L 3-way air outlet Unit : m/s TOP VIEW VERTICAL LOUVER : Upward Unit : m/s SIDE VIEW VERTICAL LOUVER : Upward Unit : m/s SIDE VIEW VERTICAL LOUVER : Downward...
-
Page 17: Special Upward Mode
Note: Condition 7-1-2. SPECIAL UPWARD MODE Fan speed : High Operation mode : FAN Ceiling mode : Standard MODEL : AUTA30L 4-way air outlet Unit : m/s SIDE VIEW VERTICAL LOUVER : Special upward - (01 - 14) -... -
Page 18: Air Flow
7-2. AIR FLOW 7-2-1. 4-WAY OUTLET MODEL : AUTA30L Cooling / Heating Number of Fan speed rotations Airflow (r.p.m) 1600 HIGH 1400 1270 1150 QUIET - (01 - 15) -... - Page 19 7-2-2. 3-WAY OUTLET MODEL : AUTA30L Cooling / Heating Airflow Number of Fan speed rotations *Max. *Min. (r.p.m) 1550 1350 HIGH 1350 1200 1250 1100 1100 QUIET - (01 - 16) -...
-
Page 20: Fresh Air
7-3. FRESH AIR MODEL : AUTA30L Air flow volume - Static pressure of Fresh air intake characteristic Duct (Inside Dia. ø70mm) Duct Fan Static pressure required to take in fresh air Air flow (m /min) Installation 70 mm Refrigerant pipe Drain pipe 2.5 mm hole 62 mm... -
Page 21: Duct Connection
7-4. DUCT CONNECTION MODEL : AUTA30L Outlet air AUTA30L Duct (Inside Dia. 350mm×100mm) Fan speed High Fan speed Qutiet L=10m L=5m L=1m Air flow (m /min) - (01 - 18) -... - Page 22 PRECAUTIONS WHILE CONNECTING AIR OUTLET DUCT Connect the air outlet duct at up to two locations among the four duct connection locations. (Do not connect ducts at three or more locations.) Blow-off pattern when a branch duct is installed Bi-directional branching, main unit bi-directional branching Branch Close Close...
-
Page 23: Operation Noise
OPERATION NOISE 8-1. NOISE LEVEL CURVE Condition Ceiling mode : Standard MODEL : AUTA30L Air outlet : 4-way air outlet Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 HIGH HIGH NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET... -
Page 24: Sound Level Check Point
8-2. SOUND LEVEL CHECK POINT Microphone 1.5m Microphone CENTER - (01 - 21) -... -
Page 25: Electric Characteristics
ELECTRIC CHARACTERISTICS Model Name AUTA30L Voltage 240 ~ Power Supply Frequency Max Operating Current (Indoor unit) Connection Cable 1.5 - 2.5 Wiring Spec. (Indoor unit to outdoor unit) Limited wiring length - (01 - 22) -... -
Page 26: Safety Devices
SAFETY DEVICES Model Protection form AUTA30L Circuit protection Current fuse (PCB) 3.15A 250V Thermal protection 110±15°C OFF Fan motor protection program 105±15°C ON - (01 - 23) -... -
Page 27: External Input & Output
EXTERNAL INPUT & OUTPUT Connector INPUT OUTPUT REMARKS Control input CN102 — (Operation/Stop) See external CN103 — Operation status output input/output settings for details. — Fresh air control output 11-1. EXTERNAL INPUT CONTROL INPUT (Operation/Stop) The air conditioner can be remotely operated by means of the following on-site work. Operation is started at the following contents by adding the contact input of a commercial ON/OFF switch to a connector on the external control PC board and turning it ON. -
Page 28: External Output
11-2. EXTERNAL OUTPUT OPERATION STATUS OUTPUT An air conditioner operation status signal can be output. Circuit diagram example Indoor Connected unit control PC board Connector Ex.)Relay unit Ex.)Display 24V DC Relay power supply *10 m Signal Field supply * Make the distance from the PC board to the connected unit within 10m. Relay spec. -
Page 29: Fresh Air Control Output
FRESH AIR CONTROL OUTPUT A signal linked to air conditioner indoor fan ON can be output. * However, signal becomes OFF during cold air prevention control operation. Circuit diagram example Indoor Connected unit control PC board Ex.) Fan Ex.) Relay unit 12 V Connector Relay... -
Page 30: Function Setting
FUNCTION SETTING 12-1. INDOOR UNIT INDOOR UNIT DIP SW Indoor unit address setting Remote controller signal code Jumper Wire Setting forbidden SWITCH POSITION MAIN PCB Indoor unit Printed circuit board DIP-SW SETTING Indoor unit address setting A number of indoor units can be operated at the same time using a wired remote controller. Set the unit number of each indoor unit using the DIP switches on the indoor unit circuit board. -
Page 31: Jumper Wire Setting
JUMPER WIRE SETTING Remote controller signal code setting (JM1, JM2) A number of indoor units can be operated at the same time using a single remote controller. Factory setting) Jumper wire Remote controller signal code JM 1 JM 2 Connect Connect Disconnect Connect... -
Page 32: Indoor Unit (Setting By Remote Controller)
12-2. INDOOR UNIT (Setting by remote controller) • The function settings of the control of the indoor unit can be changed by this procedure according to the installation conditions. Incorrect settings can cause the indoor unit malfunction. • After the power is turned on, perform the “FUNCTION SETTING” according to the installation conditions using the remote controller. - Page 33 (5) Press the TIMER SET button to confirm the setting. Press the TIMER SET button for a few seconds until the setting value stops flashing. If the setting value display changes or if “- -” is displayed when the flashing stops, the setting value has not been set correctly. (An invalid setting value may have been selected for the indoor unit.) SU MO TU WE TH FR SA Setting value...
-
Page 34: Contents Of Function Setting
CONTENTS OF FUNCTION SETTING • Follow the instructions in the Local Setup Procedure, which is supplied with the remote control, in accordance with the installed condition. After the power is turned on, perform the Function Setting on the remote control. •... - Page 35 1-4. Setting the vertical wind direction adjustment range •The use of “upward” is recommended if you wish to prevent draft. (The unit is factory-set to “00”) •Note that the ceiling may become dirty depending on your usage condition.When this happens, we recommend the use of the optional “PANEL SPACER KIT”.
-
Page 36: Wired Remote Controller
12-3. WIRED REMOTE CONTROLLER Can not be used. (Do not change) Dual remote controller setting Can not be used. (Do not change) DIP SW Can not be used. (Do not change) Can not be used. (Do not change) Memory backup setting SWITCH POSITION Front case (back side) Do not use this... -
Page 37: Optional Parts
OPTIONAL PARTS Exterior Parts name Model No. Summary Unit control is performed by wired remote controller. Wired remote controller is Wired remote UTB-TUD attached in one as accessories. controller Wired remote controller is two installation possibility in one indoor unit. Unit control is performed by IR Receiver kit UTY-LRHYA1... - Page 38 Exterior Parts name Model No. Summary It can be taken in fresh air of up to 10% of “high” air volume Fresh air intake UTZ-VXGA of the indoor unit by attaching Fresh Air Intake Kit to cassette type indoor unit. - (01 - 35) -...
-
Page 39: Outdoor Unit
2. OUTDOOR UNIT SINGLE TYPE : AOTA30LBTL AOTA30LFTL AOTA30LGTL D2D_AO030E/04 2011.11.07... - Page 40 CONTENTS 2. OUTDOOR UNIT 1. SPECIFICATIONS ....................02 - 01 2. DIMENSIONS ......................02 - 03 3. REFRIGERANT CIRCUIT ................02 - 04 4. WIRING DIAGRAMS ..................02 - 06 5. CAPACITY COMPENSATION RATE FOR PIPE LENGTH AND HEIGHT DEFFERENCE ..............
-
Page 41: Specifications
SPECIFICATIONS Type INVERTER HEATPUMP Model name AOTA30LBTL Power source 240V ~ 50Hz Available voltage range 198-264V ~ 50Hz Starting current 15.0 Cooling 1000 (3600) Airflow rate Heating 1056 (3800) Type × Q'ty Propeller × 1 Motor output Cooling Sound pressure level dB (A) Heating Dimensions (H ×... - Page 42 Type INVERTER HEATPUMP AOTA30LFTL Model name AOTA30LGTL Power source 240V ~ 50Hz Available voltage range 198-264V ~ 50Hz Starting current 15.0 Cooling 1000 (3600) Airflow rate Heating 1000 (3600) Type × Q'ty Propeller × 1 Motor output Cooling Sound pressure level Heating dB (A) Sound power level...
-
Page 43: Dimensions
DIMENSIONS MODEL : AOTA30LB, AOTA30LF, AOTA30LG (Unit : mm) Top view Front view Side view Air flow Bottom view INSTALLATION PLACE When there are obstacles at the back, When there are obstacles at the back When there are obstacles at the back, side(s), and top. -
Page 44: Refrigerant Circuit
REFRIGERANT CIRCUIT MODEL : AOTA30LB - (02 - 04) -... - Page 45 MODEL : AOTA30LF, AOTA30LG - (02 - 05) -...
-
Page 46: Wiring Diagrams
WIRING DIAGRAMS MODEL : AOTA30LB - (02 - 06) -... - Page 47 MODEL : AOTA30LF, AOTA30LG - (02 - 07) -...
-
Page 48: Capacity Compensation Rate For Pipe Length And Height Defference
CAPACITY COMPENSATION RATE FOR PIPE LENGTH AND HEIGHT DEFFERENCE This table is created using the maximum capacity. MODEL : AOTA30LB, AOTA30LF, AOTA30LG Pipe length (m) COOLING 0.908 0.894 0.876 0.935 0.923 0.909 0.891 Indoor unit is upper 0.968 0.951 0.938 0.924 0.906 than outdoor unit... -
Page 49: Additional Charge Calculation
ADDITIONAL CHARGE CALCULATION MODEL : AOTA30LB, AOTA30LF, AOTA30LG Refrigerant type R410A Refrigerant amount 2100 REFRIGERANT CHARGE Pipe length 20 or less 40g/m Additional charge 1200 - (02 - 09) -... -
Page 50: Air Flow
AIR FLOW MODEL : AOTA30LB COOLING Number of rotations Air flow (r.p.m) 3600 1000 2119 HEATING Number of rotations Air flow (r.p.m) 3800 1056 2236 - (02 - 10) -... - Page 51 MODEL : AOTA30LF, AOTA30LG COOLING Number of rotations Air flow (r.p.m) 3600 1000 2119 HEATING Number of rotations Air flow (r.p.m) 3600 1000 2119 - (02 - 11) -...
-
Page 52: Operation Noise
OPERATION NOISE 8-1. NOISE LEVEL CURVE MODEL : AOTA30LB, AOTA30LF, AOTA30LG COOLING HEATING NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000... -
Page 53: Sound Level Check Point
8-2. SOUND LEVEL CHECK POINT - (02 - 13) -... -
Page 54: Electric Characteristics
ELECTRIC CHARACTERISTICS Model name AOTA30LB, AOTA30LF, AOTA30LG Voltage 240 ~ Power supply Frequency *1) Max. operating current 17.0 Starting current 15.0 Main fuse (Circuit breaker) current *2) Wiring spec. Power cable 3.5 - 4.0 *3) Limited wiring length *1) The maximum current is the total current of indoor unit and outdoor unit. *2) Wiring spec. -
Page 55: Safety Devices
SAFETY DEVICES Model Protection form AOTA30LF AOTA30LB AOTA30LG Current fuse (NEAR THE TERMINAL) 25A 250V Circuit protection Current fuse (FILTER PRINTED CIRCUIT BOARD) 10A 250V Current fuse (MAIN PRINTED CIRCUIT BOARD) 3.15A 250V OFF : 140±20°C Fan motor protection Thermal protection program ON : 110±20°C OFF : 4.2±0.1MPa High Pressure Protection...
