- Page 1 Global 60XT BF RCE G20/G25/G25.3(Natural gas) G31(Propane) Installation manual Store this document in a safe place...
-
Page 2: Table Of Contents
I N S T A L LA T I O N M A N U A L Contents 1. Introduction 2. CE declaration 3. SAFETY 3.1 General 3.2 Regulations 3.3 Precautions/safety instructions during installation 3.4 Second thermocouple safety 3.5 Oxypilot safety 4. -
Page 3: Introduction
This declaration will lose its validity if adjustments are made to the appliance, without prior written permission by DRU. A copy of the CE test certificate can be downloaded via www.druservice.com. Product: Gas-fired heating appliance Type: Global 60XT BF RCE Conformity assessment agency: Kiwa 0063 EC regulation: 2016/426/EU Harmonized standards: NEN-EN-613;... -
Page 4: Safety
I N S T A L LA T I O N M A N U A L 3. SAFETY 3.1 General !Caution • Please observe the generally applicable regulations and precautions/safety instruction in this manual. • First check the exact technical version of the appliance to be installed in Appendix 2, Table 2. 3.2 Regulations Please install the appliance in accordance with the applicable national, local and constructional (installation) regulations. -
Page 5: Second Thermocouple Safety
IN S T A LLA TION M A NU A L 3.4 Second thermocouple safety (if applicable, see Appendix 2, Table 2) It is possible, that the appliance to be installed has 2 thermocouples. Thermocouple 1 is always next to the pilot burner, thermocouple 2 is always elsewhere above the main burner. If the appliance is provided with a second thermocouple safety on the main burner, you need to know that it will intervene if no proper transfer has taken place from the pilot burner to the main burner or from the main burner itself. -
Page 6: Gas Connection
I N S T A L LA T I O N M A N U A L 5.2 Connection 5.2.1 Gas connection Place a gas tap in the gas pipe in accordance with the applicable regulations. !Caution • Make sure there is no dirt in the gas pipes and connections. •... -
Page 7: Placing The Chimney Breast
IN S T A LLA TION M A NU A L Follow the procedure described below: Ø Disconnect the pipes from the gas control (flexible gas pipe, aluminium pilot burner pipe and thermocouple 1); The red wire of thermocouple 2, if applicable, must remain connected to the gas control. !Caution Ø... -
Page 8: Placing The Control Hatch
I N S T A L LA T I O N M A N U A L Ø If applicable, do not plaster on or over the edges of the construction frame, because: • the heat of the appliance could cause cracks; •... -
Page 9: Connection Flue Gas Discharge System
IN S T A LLA TION M A NU A L • When the appliance is installed in a house with a mechanical air extraction system and/or an open kitchen !Caution with cooker hood, you will need a permanent ventilation hole in the room where the appliance is installed; please observe the gas installation regulations and the local regulations for dimensions and other required provisions. -
Page 10: Placing The Concentric System
I N S T A L LA T I O N M A N U A L The concentric system with wall or roof terminal has to comply with the following conditions: • In appendix 2, table 4 or 5 you can find whether a concentric pipe should be connected and what the minimum vertical length would have to be. -
Page 11: Connection Existing Chimney
IN S T A LLA TION M A NU A L When using the wall terminal, place the terminal with a downward slope of 1 cm / metre towards the outside, in !Caution order to prevent rain water from raining in. 5.8.4 Connection to an existing chimney It is possible to connect the appliance to an existing chimney. -
Page 12: Additional Instructions
I N S T A LL A T I O N M A N U A L 5.9 Additional instructions Ø Attach the appliance to the wall by means of wall brackets (B) (see Appendix 3, fig. 1). 5.10. Glass pane After placing the wood set you can place the glass pane as described below. •... -
Page 13: Restrictor Slide
IN S T A LLA TION M A NU A L 5.11 Setting the appliance The appliance has to be set in such a way that it works correctly in combination with the used concentric system. For that purpose, a restrictor slide is placed and/or the air inlet guide is removed. The conditions for application with wall terminal and roof terminal are stated in Appendix 2, Tables 4, 5 and 6. -
Page 14: Placing The Wood/Pebble Set
I N S T A LL A T I O N M A N U A L 5.12 Placing the wood or pebble set The appliance is supplied with a wood set or a pebble set. Strictly observe the following instructions to prevent unsafe situations: !Caution Ø... -
Page 15: Connecting The Receiver
IN S T A LLA TION M A NU A L 6. Control The appliance is supplied with a wireless remote control. Controlling the flame height, igniting and switching off take place through a remote control controlling a receiver. Chapter 4, Wireless remote control, in the User Manual describes the operation of the appliance and how you should use the remote control. -
Page 16: Final Inspection
I N S T A LL A T I O N M A N U A L 6.3 Alternative operation Appliances made with an electronic ignition and radio remote control can be connected to an alternative external control system (e.g. Domotics). For this purpose, there are 4 connection points at the side of the receiver (see Appendix 3, fig. -
Page 17: Ignition Pilot And Main Burner
IN S T A LLA TION M A NU A L 7.3 Ignition pilot and main burner For igniting the pilot and main burner, see the User Manual, chapter 4, section 4.2, Remote control. 7.3.1 First ignition of the appliance after installation or adjustments !Caution After installation, or after work has been performed, you should ignite the appliance for the first time without the glass window. -
Page 18: Maintenance
I N S T A LL A T I O N M A N U A L 8. Maintenance The appliance must be inspected once per year by a skilled installer in the field of gas-fired heating, and repaired if necessary. Check at least whether the appliance is working properly and safely. -
Page 19: Delivery
IN S T A LLA TION M A NU A L 9. Delivery You must explain to the user how to operate the appliance. You must give him/her instructions on putting it in operation, the safety measures, the operation of the remote control and annual maintenance (see the User Manual). -
Page 20: Appendix 1 Diagnosis Of Malfunctions
I N S T A L LA T I ON M A N U A L Appendix 1 diagnosis of malfunctions Fires with electronic ignition, fault finding: Ignition and burning Start 2.10 Do(es) main burner(s) 2.06 Pilot can be lit. 2.08 Does main burner ignite smoothly and across 2.01 Can pilot be lit? Does it stay alight? - Page 21 IN S T A LLA TION M A NU A L 2.12 Does appliance switch off 2.20 Perfect! 2.14 Does main burner go out exactly 22 sec after 2.16 Is flame picture OK? 2.18 Can fire be switched off? You have a well functioning after 'some time'? servomotor starts running? fire...
- Page 22 I N S T A LL A T I O N M A N U A L Malfunction search diagram atmospheric gas-fired heating appliance with electronic ignition: Starting up cycle. Start 1.05 1.01 Does receiver beep? 1.03 Short sound signals, 1 sec after One long 5 second beep, (possibly each other, followed by the preceded by 7 short beeps).
-
Page 23: Appendix 2 Various Tables
IN S T A LLA TION M A NU A L Appendix 2 Tables Table 1: Parts included with the delivery Part Number Wood set / pebble set Control hatch Available separately Control hatch manual Available separately Installation manual User manual Restrictor slide Spare self-tapping screws for mounting the glass panes Socket spanner 8 mm Remote control with receiver... - Page 24 I N S T A LL A T I O N M A N U A L Table 2: Technical data Model identifier(s) Global 60XT BF RCE Type of appliance Built-in Combustion Closed combustion Type C11, C31, C91 Categorie 2ELL...
- Page 25 IN S T A LLA TION M A NU A L Table 3: Line-pressure when using G31 Country mbar NL / DK / FI / NO / SE / HU / BA / GR FR / BE / IT / PT / ES / GB / IE Permissibility and conditions concentric system with wall terminal ...
- Page 26 I N S T A L LA T I ON M A N U A L Permissibility and conditions concentric system with roof terminal Table 5: Determining permissibility concentric system G20/G25/ Total number of meters Total no. of meters vertical and/or sloping pipe length G25.3/G31 horiz. pipe length no bends 2 bends 3 bends...
-
Page 27: Appendix 3 Figures
IN S T A LLA TION M A NU A L Appendix 3 Figures 38C-1794... - Page 28 I N S T A LL A T I O N M A N U A L Tot.min 200cm² 38c-1078 1x90° 1x90° 38c-744w 38c-744q 1x90° 38c-744v 1 - 4m...
- Page 29 IN S T A LLA TION M A NU A L 38C-1820/0 38C-1822 /0 38C-1821 /0 38C-1823 /1 38C-1824 /0 38C-1825 /0...
- Page 30 I N S T A LL A T I O N M A N U A L 38P-0301 38P-0302 38P-0303 38P-0304 38p-0023...
- Page 31 IN S T A LLA TION M A NU A L 38P-0300 38P-0305...
- Page 32 I N S T A LL A T I O N M A N U A L 38P-0306 38P-0307...
- Page 33 IN S T A LLA TION M A NU A L 38C-1826 /0 38P-0308...
- Page 34 I N S T A LL A T I O N M A N U A L 38p-0180 38p-0181 38p-0179 38p-0182 38C-1827 /0...
- Page 35 IN S T A LLA TION M A NU A L 38C-1940...
- Page 36 DRU Verwarming B.V. The Netherlands Postbus 1021, NL-6920 BA Duiven Ratio 8, NL-6921 RW Duiven EN ...
