Global Fires 70XT BF Installation Manual

Hide thumbs Also See for 70XT BF:
Table of Contents

Advertisement

Quick Links

Download this manual
Global 70XT BF-01 RCE
G20/G25/G25.3 (Natural gas), G31 (Propane)
Installation manual
Store this document in a safe place
Scan this QR-Code for
DRU Video Assist
EN

Advertisement

Table of Contents
loading

Related Manuals for Global Fires 70XT BF

Summary of Contents for Global Fires 70XT BF

  • Page 1 Global 70XT BF-01 RCE G20/G25/G25.3 (Natural gas), G31 (Propane) Installation manual Store this document in a safe place Scan this QR-Code for DRU Video Assist...

  • Page 2: Table Of Contents

    I N S T A L LA T I O N M A N U A L Contents  1. Introduction 2. CE declaration 3. SAFETY 3.1 General 3.2 Regulations 3.3 Precautions/safety instructions during installation 3.4 Second thermocouple safety 3.5 Oxypilot safety 4.

  • Page 3: Introduction

    A copy of the CE test certificate can be downloaded via www.druservice.com. Product: Gas-fired heating appliance Type: Global 70XT BF-01 RCE Product identification number: 0063CS3334 Conformity assessment agency: Kiwa Netherlands B.V. (0063)

  • Page 4: Safety

    I N S T A L LA T I O N M A N U A L 3.    SAFETY                                                                                                                         3.1 General !Caution • Please observe the generally applicable regulations and precautions/safety instruction in this manual. • First check the exact technical version of the appliance to be installed in Appendix 2, Table 2. 3.2 Regulations Please install the appliance in accordance with the applicable national, local and constructional (installation) regulations.

  • Page 5: Second Thermocouple Safety

    IN S T A LLA TION M A NU A L 3.4 Second  thermocouple safety (if applicable, see Appendix 2, Table 2) It is possible, that the appliance to be installed has 2 thermocouples. Thermocouple 1 is always next to the pilot burner, thermocouple 2 is always elsewhere above the main burner. If the appliance is provided with a second thermocouple safety on the main burner, you need to know that it will intervene if no proper transfer has taken place from the pilot burner to the main burner or from the main burner itself.

  • Page 6: Connection

    I N S T A L LA T I O N M A N U A L 5.2 Connection 5.2.1 Gas connection Place a gas tap in the gas pipe in accordance with the applicable regulations. !Caution • Make sure there is no dirt in the gas pipes and connections. •...

  • Page 7: Placing The Chimney Breast

    IN S T A LLA TION M A NU A L Follow the procedure described below: Ø Disconnect the pipes from the gas control (flexible gas pipe, aluminium pilot burner pipe and thermocouple 1); The red wire of thermocouple 2, if applicable, must remain connected to the gas control. !Caution Ø...

  • Page 8: Placing The Control Hatch

    I N S T A L LA T I O N M A N U A L Ø If applicable, do not plaster on or over the edges of the construction frame, because: • the heat of the appliance could cause cracks; •...

  • Page 9: General

    IN S T A LLA TION M A NU A L 5.7.1 General The connection dimensions and the minimum length of the discharge system are indicated in Annex 2, table 2. The appliance should be connected in accordance with the applicable national, local and constructional (installation) regulations.

  • Page 10: Construction Of The Concentric System

    I N S T A L LA T I O N M A N U A L 5.8.2 Construction of the concentric system Depending on the construction of the concentric system, the appliance will have to be further adjusted with possibly a restrictor slide or air inlet guide. See Tables 4 and 6 for determining the correct adjustment and section 'Adjustment of the appliance' for the method of working.

  • Page 11: Connection Existing Chimney

    IN S T A LLA TION M A NU A L Place the concentric system as follows: Ø Build the system up from (the flue spigot of) the appliance. Ø Connect the concentric pipe pieces and, if necessary, the bend(s). Ø...

  • Page 12: Additional Instructions

    I N S T A LL A T I O N M A N U A L 5.9 Additional instructions Keep combustible objects and/or materials outside the appliance's radiation range. This radiation range is 700 mm !Caution (see appendix 3 fig. 2). Ø...

  • Page 13: Adjusting The Appliance

    IN S T A LLA TION M A NU A L 5.11 Adjusting the appliance The appliance has to be set in such a way that it works correctly with the used exhaust system. For that purpose a restrictor slide and/or air inlet guide is mounted. The conditions for use with wall terminal and roof terminal are stated in appendix 2, tables 4, 5 and 6.

  • Page 14: Placing The Wood Set

    I N S T A LL A T I O N M A N U A L 5.12 Placing the wood set The appliance is supplied with a wood set. The figures do not always show the correct colours. !Caution !Caution Observe the instructions below to prevent unsafe situations. •...

  • Page 15: Control

    IN S T A LLA TION M A NU A L 6.     Control                                                                                         The appliance is supplied with a wireless remote control. Controlling the flame height, igniting and switching off take place through a remote control controlling a receiver. Chapter 4, Wireless remote control, in the User Manual describes the operation of the appliance and how you should use the remote control.

  • Page 16: Alternative Operation

    I N S T A LL A T I O N M A N U A L 6.3 Alternative operation Appliances made with an electronic ignition and radio remote control can be connected to an alternative external control system (e.g. Domotics). For this purpose, there are 4 connection points at the side of the receiver (see Appendix 3, fig.

  • Page 17: Ignition Pilot And Main Burner

    IN S T A LLA TION M A NU A L 7.3 Ignition pilot and main burner For igniting the pilot and main burner, see the User Manual, chapter 4, section 4.2, Remote control. 7.3.1 First ignition of the appliance after installation or adjustments !Caution After installation, or after work has been performed, you should ignite the appliance for the first time without the glass window.

  • Page 18: Maintenance

    I N S T A LL A T I O N M A N U A L 8.  Maintenance The appliance must be inspected once per year by a skilled installer in the field of gas-fired heating, and repaired if necessary. Check at least whether the appliance is working properly and safely.

  • Page 19: Delivery

    IN S T A LLA TION M A NU A L 9.     Delivery                                                                                                                               You must explain to the user how to operate the appliance. You must give him/her instructions on putting it in operation, the safety measures, the operation of the remote control and annual maintenance (see the User Manual).

  • Page 20: Appendix 1 Diagnosis Of Malfunctions

    I N S T A L LA T I ON M A N U A L Appendix 1 diagnosis of malfunctions   Fires with electronic ignition, fault finding: Ignition and burning Start 2.10 Do(es) main burner(s) 2.06 Pilot can be lit. 2.08 Does main burner ignite smoothly and across 2.01 Can pilot be lit? Does it stay alight?
  • Page 21 IN S T A LLA TION M A NU A L 2.12 Does appliance switch off 2.20 Perfect! 2.14 Does main burner go out exactly 22 sec after 2.16 Is flame picture OK? 2.18 Can fire be switched off? You have a well functioning after 'some time'? servomotor starts running? fire...
  • Page 22 I N S T A LL A T I O N M A N U A L Malfunction search diagram atmospheric gas-fired heating appliance with electronic ignition: Starting up cycle. Start 1.05 1.01 Does receiver beep? 1.03 Short sound signals, 1 sec after One long 5 second beep, (possibly each other, followed by the preceded by 7 short beeps).

  • Page 23: Appendix 2 Various Tables

    IN S T A LLA TION M A NU A L Appendix 2 Tables Table 1: Parts included with the delivery Part Number Wood set Glow material Installation manual User manual Restrictor slide Air inlet guide Key bolts M8x 140x50 Hexagonal nut M8 Washer M8 Spare self-tapping screws for mounting the glass panes Socket spanner 8 mm...
  • Page 24 I N S T A LL A T I O N M A N U A L Table 2: Technical data Model identifier(s) Global 70XT BF-01 RCE Type of appliance Built-in Combustion Closed combustion Type C11, C31, C91 Categorie 2ELL...
  • Page 25 IN S T A LLA TION M A NU A L Table 3: Line-pressure when using G31 Country mbar NL / DK / FI / NO / SE / HU / BA / GR FR / BE / IT / PT / ES / GB / IE Permissibility and conditions concentric system with wall terminal ...
  • Page 26 I N S T A L LA T I ON M A N U A L Table 5: Determining permissibility concentric system with roof terminal G20/G25/ Total number of meters Total no. of meters vertical and/or sloping pipe length G25.3 horiz.
  • Page 27 IN S T A LLA TION M A NU A L Table 5: Determining permissibility concentric system with roof terminal Total number of meters Total no. of meters vertical and/or sloping pipe length horiz. pipe length no bends 2 bends 3 bends 4 bends 5 bends...

  • Page 28: Appendix 3 Figures

    I N S T A LL A T I O N M A N U A L Appendix 3 Figures 38C-2575/0...
  • Page 29 IN S T A LLA TION M A NU A L Tot.min. min.93* min. 230* 200cm * min. 230 Tot.min. 80cm max. max.
  • Page 30 I N S T A LL A T I O N M A N U A L 0 - 3m 1x90° 38C-744ZJ 1x90° 38C-744ZZ 38C-2587/0...
  • Page 31 IN S T A LLA TION M A NU A L...
  • Page 32 I N S T A LL A T I O N M A N U A L 38P-0804-0 38P-0805-0 38p-0022 38P-0608 38P-0028 /1...
  • Page 33 IN S T A LLA TION M A NU A L 38P-0806-0 38P-0807-0...
  • Page 34 I N S T A LL A T I O N M A N U A L 38P-0808-0 38P-0809-0...
  • Page 35 IN S T A LLA TION M A NU A L 38P-0810-0 38p-0180 38p-0181 38p-0179...
  • Page 36 I N S T A LL A T I O N M A N U A L 122° SECTION A-A SCALE 1 : 3 38p-0182 38c-2579/0 38C-1940...
  • Page 37 IN S T A LLA TION M A NU A L...
  • Page 38 I N S T A LL A T I O N M A N U A L...
  • Page 39 IN S T A LLA TION M A NU A L...
  • Page 40 DRU Verwarming B.V. The Netherlands Postbus 1021, NL-6920 BA Duiven Ratio 8, NL-6921 RW Duiven EN ...
