Global Fires 70BF Installation Manual

G20/g25 natural gas g31 propane
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Global 70BF
Global 70XT BF
G20/G25 Natural gas G31 Propane
Installation manual (GB/IE)
Store this document in a safe place
UK

Advertisement

Table of Contents
loading

Related Manuals for Global Fires 70BF

Summary of Contents for Global Fires 70BF

  • Page 1 Global 70BF Global 70XT BF G20/G25 Natural gas G31 Propane Installation manual (GB/IE) Store this document in a safe place...

  • Page 2: Table Of Contents

    I NS T AL L A TI O N MA N U A L Contents 1. Introduction 2. CE declaration 3. SAFETY 3.1 General 3.2 Regulations 3.3 Precautions/safety instructions during installation 3.4 Second thermocouple safety 3.5 Oxypilot safety 4. Removing the packaging 5.

  • Page 3: Introduction

    We hereby declare, that the design and construction method of the gas-fired heating appliance issued by Dru complies with the essential requirements of the gas appliance directive. Product: gas-fired heating appliance Type: Global 70BF / Global 70XT BF EEC directives: 90/396/EEC Standards: NEN-EN-613...

  • Page 4: Safety

    I NS T AL L A TI O N MA N U A L 3. SAFETY 3.1 General !Caution Please observe the generally applicable regulations and precautions/safety instruction in this manual. First check the exact technical version of the appliance to be installed in Appendix 2, Table 2. 3.2 Regulations Please install the appliance in accordance with the applicable national, local and constructional (installation) regulations.

  • Page 5: Removing The Packaging

    I NS T AL L AT I ON M A N U A L Removing the packaging Note the following items when removing the packaging: Ø Check the appliance and accessories for damages (during transport). Ø If necessary, contact your supplier. Ø...

  • Page 6: Installation

    I NS T AL L A TI O N MA N U A L Installation Read this manual carefully to ensure the proper and safe installation of the appliance. !Caution Install the appliance in the order described in this chapter. Ø...

  • Page 7: Placing A Built-In Appliance

    I NS T AL L AT I ON M A N U A L 5.4 Placing a built in appliance (if applicable) Not all built in appliances by DRU are supplied with a control hatch. If it is not included, this control hatch is available separately.

  • Page 8: Placing The Control Hatch

    I NS T AL L A TI O N MA N U A L When placing the chimney breast, you should take the following into account (see Appendix 3, fig. 2): !Caution the location of the control hatch: this must be placed as low as possible; the dimensions of the control hatch;...

  • Page 9: Flue Gas Discharge System In Appliances With Open Combustion

    I NS T AL L AT I ON M A N U A L !Tip You can place the outer frame in such a way, that the door turns to the left or to the right. 5.7 Flue gas discharge system in appliances with open combustion For connection to an existing chimney without a discharge pipe or flexible SS discharge –...

  • Page 10: Construction Of The Concentric System

    I NS T AL L A TI O N MA N U A L 5.8.2 Construction of the concentric system Depending on the construction of the concentric system, the appliance will have to be further adjusted with possibly a restrictor slide or air inlet guide. See Tables 4 and 6 for determining the correct adjustment and section 'Adjustment of the appliance' for the method of working.

  • Page 11: Connection Existing Chimney

    I NS T AL L AT I ON M A N U A L When using the wall terminal, place the terminal with a downward slope of 1 cm / metre towards the !Caution outside, in order to prevent rain water from raining in. 5.8.4 Connection to an existing chimney It is possible to connect the appliance to an existing chimney.

  • Page 12: Additional Instructions

    I NS T AL L A TI O N MA N U A L 5.9 Additional instructions ® For the appliances Global 70BF and Global 70XT BF a convection set - the Maxvent system - is available optionally. ® If required, install the Maxvent system prior to placing the appliance.

  • Page 13: Baffle (R)

    I NS T AL L AT I ON M A N U A L 5.11 Adjusting the appliance The appliance has to be set in such a way that it works correctly in combination with the concentric system. For that purpose, a baffle is placed and/or the air inlet guide is removed. The conditions for using a wall terminal and for using a roof terminal are described in section 5.8.

  • Page 14: Placing The Wood Set

    I NS T AL L A TI O N MA N U A L 5.12 Placing the wood set The appliance is supplied with a wood set. Strictly observe the following instructions to prevent unsafe situations: !Caution Ø only ever use the supplied wood set; Ø...

  • Page 15: Wireless Remote Control

    I NS T AL L AT I ON M A N U A L Wireless remote control The appliance is supplied with a wireless remote control. Controlling the flame height, igniting and switching off take place through a remote control controlling a receiver. Chapter 4, Wireless remote control, in the User Manual describes the operation of the appliance and how you should use the remote control.

  • Page 16: Final Inspection

    I NS T AL L A TI O N MA N U A L 7. Final inspection In order to check whether the appliance is working properly and safely, you must perform the following inspections before the appliance is used. 7.1 Gastightness All connections must be gastight.

  • Page 17: Main Burner

    I NS T AL L AT I ON M A N U A L 7.3.2 Main burner The pilot burner should ignite the main burner within a couple of seconds, and without popping. !Caution The main burner(s) must cross the full burner smoothly and without popping and continue to burn. Ø...

  • Page 18: Maintenance

    I NS T AL L A TI O N MA N U A L 8. Maintenance The appliance must be inspected once per year by a skilled installer in the field of gas-fired heating, and repaired if necessary. Check at least whether the appliance is working properly and safely. !Caution Always close the gas tap during maintenance work;...

  • Page 19: Delivery

    I NS T AL L AT I ON M A N U A L Delivery You must explain to the user how to operate the appliance. You must give him/her instructions on putting it in operation, the safety measures, the operation of the remote control and annual maintenance (see the User Manual).

  • Page 20: Appendix 1 Diagnosis Of Malfunctions

    I NS T AL L A TI O N MA N U A L Appendix 1 diagnosis of malfunctions Fires with electronic ignition, fault finding: Ignition and burning Start 2.10 Do(es) main burner(s) 2.06 Pilot can be lit. 2.08 Does main burner ignite ignite smoothly and across 2.01 Can pilot be lit? Does it stay alight?
  • Page 21 I NS T AL L AT I ON M A N U A L 2.12 Does appliance switch off 2.20 Perfect! 2.14 Does main burner go out exactly 22 sec after 2.16 Is flame picture OK? 2.18 Can fire be switched off? You have a well functioning after 'some time'? servomotor starts running?
  • Page 22 IN S TA L L A TI O N M A N U A L Malfunction search diagram atmospheric gas-fired heating appliance with electronic ignition: Starting up cycle Start 1.05 Short beeps, 1sec after another, 1.01 Does receiver beep? 1.03 One long 5 second beep, followed by clicking noise of gas (possibly preceded by 7 short valve opening, possibly followed...

  • Page 23: Appendix 2 Various Tables

    I NS T AL L AT I ON M A N U A L Appendix 2 Tables Table 1: Parts included with the delivery Part Number Wood set Control hatch Control hatch manual Installation manual User manual Decorative strip left Decorative strip right Gauge for restrictor slide Restrictor slide...
  • Page 24 IN S TA L L A TI O N M A N U A L Table 2: Technical data Product name Global 70BF / Global 70XT BF Type of appliance Built-in Combustion Closed combustion Supply and discharge system Concentric 150/100...
  • Page 25 I NS T AL L AT I ON M A N U A L Table 3: Line-pressure when using G31 Country mbar NL / DK / FI / NO / SE / HU / BA / GR FR / BE / IT / PT / ES / GB / IE Permissibility and conditions concentric system with wall terminal Table 4: Conditions for setting the appliance G20/G25/G31...
  • Page 26 IN S TA L L A TI O N M A N U A L Permissibility and conditions concentric system with roof terminal Table 5: Determining permissibility concentric system G20/G25/G31 Total number of meters Total no. of meters vertical and/or sloping pipe length horiz.

  • Page 27: Appendix 3 Figures

    I NS T AL L AT I ON M A N U A L Appendix 3 Figures Global 70 BF Global 70XT BF 38c-1378/1 38c-1377/1 min. 362 min. 362 max. 100 max. 100 min. 1450 min. 1450 min. 1350 min. 1350 Global 70 BF Global 70XT BF...
  • Page 28 I NS T AL L A TI O N MA N U A L 38c-1078...
  • Page 29 I NS T AL L AT I ON M A N U A L...
  • Page 30 IN S TA L L A TI O N M A N U A L...
  • Page 31 I NS T AL L AT I ON M A N U A L 38c-1386...
  • Page 32 IN S TA L L A TI O N M A N U A L 38p-0022 38p-0023 38P-0157 /0...
  • Page 33 I NS T AL L AT I ON M A N U A L 38P-0158 /0 38P-0159 /0 38P-0160 /0 38P-0335...
  • Page 34 IN S TA L L A TI O N M A N U A L 38P-0161 /0 38p-0180 38p-0181 38p-0179...
  • Page 35 I NS T AL L AT I ON M A N U A L 38p-0182 38C-1894 /0...
  • Page 36 DRU Verwarming B.V. The Netherlands Postbus 1021, NL-6920 BA Duiven Ratio 8, NL-6921 RW Duiven...
