Summary of Contents for ACU-RITE 06024
- Page 1 User Manual of Product 1: AcuRite Multi-Room Weather Station with Wireless Indoor/Outdoor Thermometer and Digital Color Display with Weather Forecaster (02082M), Full Color...
-
Page 2: Table Of Contents
Instruction Manual Home Environment Display models 06024/06036 auto This product requires at least one AcuRite Monitor or Sensor (sold separately) to be operational. CONTENTS Unpacking Instructions ... 2 Using the Display....12 Package Contents ....2 Programmable Alarms...13 Features & Benefits....2 Troubleshooting ....14... -
Page 3: Unpacking Instructions
Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LCD screen prior to using this product. - Page 4 BACK OF DISPLAY 1. Integrated Hang Holes 5. CLEAR Button For easy wall mounting. For resetting the high and low records that are stored for the location(s) that 2. Battery Compartment the display is tracking. 3. Plug-in for Power Adapter 6.
- Page 5 DISPLAY SCREEN auto 13 12...
- Page 6 Indicator “Learning Mode” Icon Indicates display is in auto-dimming Disappears after weather forecast brightness mode (see page 11). self-calibration is complete (see page 12). 14. Date 2. 12 to 24 Hour Weather Forecast 15. +SENSOR Icon Self-Calibrating Forecasting pulls data Indicates a Wired Sensor (sold from your backyard to generate your separately) is reporting data to the...
-
Page 7: Setup
SETUP Display Setup Install External Monitor or Install or Replace Backup Sensor Batteries Batteries (optional) BEFORE powering on the display, 1. Remove the battery install batteries for all external compartment cover. Monitors and/or Sensors (sold 2. Insert 3 x AAA alkaline separately) that you would like batteries into the battery to synchronize with the display. -
Page 8: Set The Time, Date & Units
Set the Time, Date & Units Press and release the “SET” button, located on the front of the display, to enter SET MODE. Once in set mode, the preference you are currently setting will blink on the display. To adjust the currently selected (flashing) item, press and release the “▲“ or “▼“... - Page 9 Compatible Monitors Perfect for: (continued) Indoor and outdoor applications Temperature & Humidity Sensor Model 06002RM Monitor + Wired Sensor Perfect for: • Basement flooding Roof leaks Leaky appliances Sump pump failure Track high or low water level Water Detector Model 06010RM Indoor pool, spa, pond or fountain...
- Page 10 4. Press and release the “SET” button. 5. Press and release the “▲“ or “▼“ buttons to cycle through the available location names. 6. Press and release the “SET” button to confirm a name selection. Location Names AQUARIUM HOT TUB OTHER BEDROOM 4 HUMIDOR...
- Page 11 Sync a New Monitor or Sensor with the Display To manually add a new Monitor or Sensor to the display: 1. Press and release the color-coded button next to a location on the display with the name “AVAILABLE.” Next, “ADD MONITOR” will flash at the top of the display.
-
Page 12: Backlight Settings
Backlight Settings The color display features three different lighting settings: High (100%) brightness, Medium (60%) brightness and Low (30%) brightness. Using battery power alone, the backlight is available momentarily for 10 seconds by pressing the Backlight button. When display is powered by the power adapter, backlight remains on at 100% brightness. -
Page 13: Using The Display
OPERATION Using the Home Environment Display Weather Forecast AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast of weather conditions for the next 12 to 24 hours by collecting data from a sensor in your backyard. It generates a forecast with pinpoint accuracy - personalized for your exact location. -
Page 14: Programmable Alarms
the highest and lowest values recorded since the unit was powered on. A timestamp is shown in the clock area of the display indicating when the record values were recorded. To manually clear the records currently being viewed, press and release the CLEAR button, located in the battery compartment of the display. -
Page 15: Troubleshooting
Troubleshooting Problem Possible Solution If the wireless signal indicator shows no bars: Relocate the display and/or synced Monitor/Sensor (if applicable). The products must be within 330 ft (100 m) of each other Make sure products (display, Monitors, Sensors) are placed at least 3 feet (.9 m) away from electronics No reception that may interfere with the wireless communication... - Page 16 Problem Possible Solution Check that the power adapter is plugged into the display and an electrical outlet. Display screen Reset the display by pressing the RESET button, not working located in the battery compartment of the display. Date and time will need to be entered after a reset If your AcuRite product does not operate properly after trying the troubleshooting steps, visit www.AcuRite.com or call (877) 221-1252 for assistance.
-
Page 17: Calibration
Calibration Calibrate Temperature and Humidity The temperature and humidity readings can be calibrated on the display to improve accuracy. Calibration can improve accuracy when product placement or environmental factors impact your data accuracy. 1. Press AND HOLD both the “SET” button and color-coded button (found next to the location reading you wish to calibrate) simultaneously for 10 seconds. -
Page 18: Specifications
Specifications DISPLAY’S BUILT-IN TEMPERATURE SENSOR 32ºF to 122ºF; 0ºC to 50ºC RANGE DISPLAY’S BUILT-IN 1% to 99% RH HUMIDITY SENSOR RANGE 330 ft / 100 m depending on home construction materials WIRELESS RANGE 433 MHz OPERATING FREQUENCY Display: 5vdc power adapter POWER 3 x AAA alkaline batteries (optional) FCC Information... -
Page 19: Customer Support
Customer Support AcuRite customer support is committed to providing you with best-in- class service. For assistance, please have the model number of this product available and contact us in any of the following ways: (877) 221-1252 info@chaney-inst.com AcuRite 24/7 support at www. .com Installation Videos Register your Product... - Page 21 Weather Temperature Weather Kitchen Clocks Stations & Humidity Alert Radio Thermometers & Timers It’s more than accurate, it’s AcuRite offers an extensive assortment of precision instruments, designed to provide you with information you can depend on to Plan your day with confidence ™...
