ACU-RITE Iris 06103M Setup

SETUP REQUIRES:
• Display
• Power Adapter (3 AAA backup batteries recommended)
• AcuRite Iris (5-in-1) Sensor (may be sold separately)
1
PLUG IN DISPLAY AND CONFIGURE SETTINGS
Plug in the power adapter. Once the display is powered on, configuration will begin automatically. Use the
Down buttons to select between options, and press the set button to confirm your selections.
and
• 12 or 24 Hour Clock Display • Calendar Year
• Clock Hour • Temperature Units (°F / °C)
• Clock Minute
• Wind Speed Units
• Calendar Month (mph, km/h, knots)
• Calendar Date
You can configure these settings at any time by pressing the set button.
2
INSTALL SENSOR BATTERIES
In the outdoor sensor battery compartment, install four AA alkaline or lithium batteries. The display should
automatically sync with the sensor and start showing readings within a minute.
NOTE: In the battery compartment of the sensor, there is a small A-B-C switch that should match the selection on
the Display, located in the battery compartment. By default, the selection is "A" and shouldn't need adjustment.
3
MOUNT SENSOR
Find a suitable place to mount the outdoor sensor:
• At least 5 feet (1.5 meters) off the ground
• Front solar cell facing south
• Away from heat and humidity sources
• Level for accurate rain reporting using bubble level
on top of sensor
Once the sensor is mounted, remove the rain gauge
stabilizer from sensor.
• Rainfall Units
(inches / mm)
• Pressure Units
(inHg / hPa)
A B C
A-B-C Switch
Set to match
1
display
Rain Gauge Stabilizer
Install Batteries
Remove and discard
4 AA Batteries
Set up your AcuRite Iris
Up
Use Wi-Fi to Connect to My AcuRite
SETUP REQUIRES:
• Display and AcuRite Iris Sensor
• 2.4 GHz Wireless Network
• Phone, Tablet, or Computer with Wi-Fi
1
CONNECT TO DISPLAY WI-FI
Connect to the Wi-Fi signal coming from your
Display using your phone or Wi-Fi compatible
device.
2
ACCESS WI-FI SETUP PAGE
Open a web browser on your device. Type
"192.168.4.1" in the address bar and hit enter to
access the AcuRite Wi-Fi display settings website.
ADDITIONAL NOTES
The Wi-Fi set up page is available for 30 minutes after the display is powered on. Press the set button to
reactivate the setup page at any time.
To retain Wi-Fi configuration details, backup batteries in the display are strongly recommended. The display can
be power cycled at any time to clear Wi-Fi credentials.
Display 06103M
®
Records Button
for Remote Monitoring
®
3
ADD YOUR WI-FI CREDENTIALS
Select your Wi-Fi network name and enter your
network password. Press "Save". Once your
credentials are successfully entered, reconnect to
your normal Wi-Fi.
4
SET UP YOUR MY ACURITE ACCOUNT
Download the My AcuRite mobile app or visit
www.myacurite.com to complete setup. You will
need the device ID located on the back of the
display or inside the battery compartment.
