Service Manual
Steps
3. Take down the bad compressor
① Remove the bolts on the compressor by using a tool.
② Take down the bad compressor from the bottom plate.
4. Place the new compressor on the bottom plate and connect the
suction inlet and discharge outlet with the pipe system
① Place the compressor on the bottom plate.
② Tighen the nuts by using a tool.
Disassembly and Assembly of 4-way Valve
Steps
1. Remove the 4-way valve coil
① Remove the screws on the fixed coil by using a
screwdriver.
② Remove the 4-way valve coil.
Installation and Maintenance
Procedure
Procedure
103
