8. Remov e
Cut off Valve and
Remove the 2 bolts fixing the valve subassemblies.
Unsolder the welding joint connecting the gas valve
and the return air pipe. Remove the gas valve.
(Note: When unsoldering the soldering joint, wrap the
gas valve with wet cloth completely to avoid damage
to the valve caused by high temperature.)
Unsolder the welding joint connecting the liquid valve
and the connecting pipe.Remove the liquid valve.
Remove screws fixing valve support and then remove
the valve support.
9. Remov e compressor
Remove the 3 foot nuts fixing the compressor
and then remove the compressor.
10.Remove support
Remove the screws connecting the support
and condenser assy,and thenremove the support.
98
Valve Support
support
Service Manual
valve support
cut off Valve
