Speco VL-12 Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Indoor Fully Adjustable Color CCD IR Camera
VL-12
• Fully adjustable for wall or ceiling use
• 420 lines of resolution
• 40 ft. IR range (depending on scene reflection)
• Cables are concealed within the housing

Specifications

Pick Up Device . . . . . . . . . . . . . . .
Resolution . . . . . . . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . .
Total Pixels . . . . . . . . . . . . . . . . .
Effective Pixels . . . . . . . . . . . . . . .
Sync Type . . . . . . . . . . . . . . . . . .
Scanning System . . . . . . . . . . . . .
Video Output . . . . . . . . . . . . . . .
Auto White Balance . . . . . . . . . . . .
Backlight / Flicker / Mirror
Min. Illumination . . . . . . . . . . . . .
IR Distance . . . . . . . . . . . . . . . . .
IR Trigger . . . . . . . . . . . . . . . . . .
X-Y-Z Postion . . . . . . . . . . . . . . .
S/N Ratio . . . . . . . . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . .
Gamma Correct . . . . . . . . . . . . . .
Horizontal Frequency
Vertical Frequency . . . . . . . . . . . .
Backlight Compensation
Power Supply . . . . . . . . . . . . . . . .
Consumption Current
Dimensions . . . . . . . . . . . . . . . . .
Operating Temperature
For more information contact us at:
Features
1/3" interline transfer CCD
420 lines
6.0mm board lens
NTSC 537 (H) x 505 (V)
NTSC 512 (H) x 492 (V)
2:1 Internal
NTSC 525 lines / 30 frames
Composite 1.0 Vp-p / 75 ohm
2400°K - 9400°K
. . . . . . . Built-in (option jumper ON/OFF)
0.5 lux color / 0 lux with IR on
40 feet (28pcs IR LED)
4 lux / 8 lux IR ON/OFF
Adjustable manual P-T-T (Pan-Tilt-Twist)
50dB (AGC off)
Auto 1/60 sec. to 1/100,000 sec.
0.45
. . . . . . . . . . 15.734 KHz
59.94 Hz
. . . . . . . . . Built-In Jumper ON/OFF
Regulated 12V DC power supply required - model PSW-5
. . . . . . . . . . Max. 300mA
92 mm x 122.5 mm
. . . . . . . . . -14˚F to 122˚F
