Speco LPRB922 Specifications

LPRB922
9-22mm F1.4 DC auto iris varifocal lens

Features

• High-contrast imaging performance that delivers sharp, clear license-plate captures
• 36 Powerful 850nm IRs works perfectly even in total darkness to deliver clear license plate images
• 9-22mm varifocal IR-corrected lens optimizes day/night performance, even in very low light conditions and captures a wide 10-27 ft. field
• Weatherproof with Rain Guard/Extendable Sunshield minimize the effects of rain and sunlight on image quality
• Cable-management bracket enables easy installation in any location, including walls, surfaces, and ceilings
Note: Because of the special nature of this camera, it will only show pictures of license plates. All other items in the camera's field of view will be blacked out.

Specifications

Image Sensor
Resolution
Signal System
Min. Object Illumination
Effective Pixels
Built-In Lens
Viewing Angle
Video S/N Ratio
Gamma correction
BLC
Video Signal Output
IR LEDs
IR Wavelength
IR Distance
Capture Range
Capture Speed
Scanning System
Synchronization
Weatherproof Standard
Power Consumption
Power Requirement
Operating Temperature
Construction
Dimensions
Weight
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
For more information contact Speco Technologies
200 New Highway, Amityville, NY 11701
www.specotech.com
License Plate Capture Bullet Camera
simply unique.
™
1/3" Sony CCD
600 TV lines
NTSC
0 lux (with IR LEDs on)
768 (H) x 494 (V)
9-22mm F1.4 DC iris varifocal IR-corrected lens with external adjustments for zoom & focus
Horizontal: 32.1° (wide) ~ 13.1° (tele) / Vertical: 23.3° (wide) ~ 9.8° (tele)
Greater than 50db (AGC off)
0.45
Auto (center weighting)
1.0V(p-p) composite output, 75 Ohm
36 super power for more than 10,000 hours (122˚ F)
850nm
Up to 50ft.
10-27 ft.
Up to 55 MPH
2:1 interlaced V: 59.94Hz
Internal
IP66 rating
10W/600mA
Dual Voltage: 12V DC/24V AC
-14˚F to 122˚F
Compact die cast aluminum sunshield, cable management bracket
3.6" Dia. x 8.09" L
1.35 lbs.
• Toll Free: 1-800-645-5516
Weatherproof Close-Range
• Fax: 631-957-9142 or 631-957-3880
Rev. 5/23/11
