Speco LEDome Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
LEDome Color Weatherproof Day/Night
Dome Camera with External IR LEDs
LEDome
• Fully adjustable external IR LEDs eliminate internal reflections
• ExView* technology yields 480 lines of resolution @ .03 Lux (0 Lux when IR LEDs are active)
• True Day/Night function using mechanical IR Cut Filter Technology
• User adjustable Lux settings determine at what light level the camera switches from color to B/W
• Has both normal coaxial video and UTP balun outputs. LEDome works with coaxial or CAT-5E type cables
• Wall & Ceiling mountable – Fully adjustable in all directions • Front and rear alarm tamper switches
• Dual Vo l t a ge – Line locked and V-Phase in the 24 volt AC mode • 3 to 9 mm auto iris varifocal lens with
mechanical IR filter • Built-in heaters extend the operating range and eliminate condensation
• Video test terminal for local adjustment of the camera without opening the case

Specifications

Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Image Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TV System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Scanning System . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sync System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Minimum Illumination . . . . . . . . . . . . . . . . . . . . . . .
CDS Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
S/N Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gamma Characteristic . . . . . . . . . . . . . . . . . . . . . . .
Video Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operational Temperature . . . . . . . . . . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
*ExView is a trademark of Sony Corporation
For more information contact us at:
No More Reflections
From The Inside
of the Dome
Features
480 Lines
1/3" Sony (ExView* CCD)
NTSC
2:1 Interlaced
Line locked, adjustable V-phase in
24-Volt AC mode
0.03 Lux (IR off) 0.00 Lux (IR on)
Photoconductive cells 10 lux resistance
5~10K
More than 50db
0.45
1.0 Volt p-p into 75 ohm Composite and
UTP (built-in balun)
1/60 – 1/100,000 sec
24-Volts AC, 12-Volts DC
1 Amp
DC auto iris varifocal lens (3mm-9mm)
mechanical IR Filter
-14˚F to 122˚F, RH 95% Max
6.75" diameter x 5" high
2 Lbs.
white housing
LEDome/W
