Page 1 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment: Model #: __________________________ Serial #: __________________________ Date Purchased: ___________________ OPERATOR’S MANUAL Medium Duty Counterline Griddle Models MDG-24, MDG-36 (shown), and MDG-48 Thermostatic Griddle Models MDGT-24, MDGT-36, and MDGT-48 Charbroiler Models MDC-24, MDC-36, and MDG-48...
Page 2: Safety Precautions
EDIUM OUNTERLINE SAFETY PRECAUTIONS Before installing and operating this equipment, be sure everyone involved in its operation is fully trained and aware of precautions. Accidents and problems can be caused by failure to follow fundamental rules and precautions. The following symbols, found throughout this manual, alert you to potentially dangerous conditions to the operator, service personnel, or to the equipment.
Page 3: Table Of Contents
Congratulations! You have purchased one of the finest pieces of commercial cooking equipment on the market. You will find that your new equipment, like all Southbend equipment, has been designed and manufactured to meet the toughest standards in the industry. Each piece of Southbend equipment is carefully engineered and designs are verified through laboratory tests and field installations.
Page 4: Specifications
The Serial Plate is located on the interior side of the valve panel (see Figure 1 on page 3). It indicates the type of gas the unit is equipped to burn. All Southbend equipment is adjusted at the factory. Check type of gas on serial plate.
Page 5 PECIFICATIONS EDIUM OUNTERLINE CLEARANCES WARNING There must be adequate clearance between units and adjacent construction. Clearance must also be provided for servicing and for operation. Minimum Clearances from COMBUSTABLE construction: Griddle Models Open Top Models Sides 4" 4" Back 4" 4"...
Page 6 PECIFICATIONS EDIUM OUNTERLINE Figure 2 DIMENSIONS OF GRIDDLE & THERMOSTATIC-GRIDDLE MODELS 1.7" 27.2" TOP VIEW Width (see table below) 3.9" 7.4" 13.7" 14.0" 9.8" 4" Adjustable Legs 2.8" 2.2" FRONT VIEW SIDE VIEW Model Width Number and Size of Burners Total BTU MDG-24 &...
Page 7 PECIFICATIONS EDIUM OUNTERLINE Figure 3 DIMENSIONS OF CHARBROILER MODELS 25.7" TOP VIEW Width (see table below) 7.8" 17.5" 9.7" 4" Adjustable Legs 2.2" 2.8" FRONT VIEW SIDE VIEW Model Width Number and Size of Burners Total BTU MDC-24 & MDCL-24 24"...
Page 8 PECIFICATIONS EDIUM OUNTERLINE Figure 4 DIMENSIONS OF OPEN TOP MODELS 27.3" TOP VIEW Width (see table below) 12.2" 10.1" 6.3" 2.2" 4" Adjustable Legs FRONT VIEW SIDE VIEW Model Width Number and Size of Burners Total BTU MDO-12 12" 2 @ 20,000 40,000 MDO-24 24"...
Page 9: Installation
NSTALLATION EDIUM OUNTERLINE NSTALLATION NOTICE Installation must comply with National Fuel Gas Code, ANSI Z223.1, Natural Gas Installation Code, CAN/CGA-B149.1, or the Propane Installation Code, CAN/CGA-B149.2, as applicable. These installation procedures must be followed by qualified personnel or warranty will be void. Local codes regarding installation vary greatly from one area to another.
Page 10 The serial plate is located interior side of the valve panel (see Figure 1 on page 3). It indicates the type of gas the unit is equipped to burn. All Southbend equipment is adjusted at the factory. Check type of gas on serial plate.
Page 11 NSTALLATION EDIUM OUNTERLINE Step 5: Spread Out Lava-Rock Briquettes (Lava-Rock Charbroilers Only) This step applies only to the installation of lava-rock charbroiler models. Such models are shipped with the lava-rock briquettes in bags located between the lava-rock grates and the top cooking grids. 1.
Page 12: Operation
PERATION EDIUM OUNTERLINE PERATION DANGER EXPLOSION HAZARD Purchaser of equipment must post in a prominent location, detailed instructions to be followed in the event the operator smells gas. Obtain the instructions from the local gas supplier. CAUTION To eliminate gas build up which could result in an explosion, in the event of main burner ignition failure a five minute purge period must be observed prior to re-establishing ignition source.
Page 13 PERATION EDIUM OUNTERLINE CHARBROILER MODELS Each 12"-wide charbroiler section has a knob on the front panel that directly controls the flow of gas, and so the heat. Turn the knob clockwise to increase the heat; turn it counterclockwise to reduce the heat. At the end of each day’s use, turn all knobs to the “OFF”...
Page 14: Cleaning
OUNTERLINE LEANING Southbend equipment is constructed with the best quality materials and is designed to provide durable service when properly maintained. To expect the best performance, your equipment must be maintained in good condition and cleaned daily. Naturally, the frequency and extent of cleaning depends on the amount and degree of usage.
Page 15 LEANING EDIUM OUNTERLINE CARE OF GRIDDLES New griddles should be carefully tempered and cared for in order to avoid possible damage. To break in a new griddle, first wipe it clean. Next, light all the griddle burners and turn them to low for one hour. Then gradually bring each griddle up to frying temperature.
Page 16: Adjustments
DJUSTMENTS EDIUM OUNTERLINE DJUSTMENTS WARNING ADJUSTMENTS AND SERVICE WORK MAY BE PERFORMED ONLY BY A QUALIFIED TECHNICIAN WHO IS EXPERIENCED IN, AND KNOWLEDGEABLE WITH, THE OPERATION OF COMMERCIAL COOKING EQUIPMENT. HOWEVER, TO ASSURE YOUR CONFIDENCE, CONTACT YOUR AUTHORIZED SERVICE AGENCY FOR RELIABLE SERVICE, DEPENDABLE ADVICE OR OTHER ASSISTANCE, AND FOR GENUINE FACTORY PARTS.
Page 17 DJUSTMENTS EDIUM OUNTERLINE All orifice sizes and burner rate are properly set at the factory and should not be altered. Over-rated burners cause poor burner and pilot performance, resulting in less heat, and wasted gas. Over-gassed burners DO NOT heat griddles as efficiently as those that are properly adjusted. Such conditions also create “hot spots”...
Page 18: Troubleshooting
ROUBLESHOOTING EDIUM OUNTERLINE ROUBLESHOOTING Consult the following table and the flowchart that begins on the following page. Problem Look for - All burners and pilots in unit will not turn on – Main gas supply to unit is “OFF.” All burners produce excessive carbon deposits –...
Page 19 ROUBLESHOOTING EDIUM OUNTERLINE OPEN TOP BURNER TROUBLESHOOTING. Common checks for all top configurations. NOTE: Griddle Tops NOTE: Griddles must be Check that the burners are set raised and secured or level in the support brackets. removed. Check that the burners are CAUTION! Before clean and all ports are clear.
Page 20 ROUBLESHOOTING EDIUM OUNTERLINE Continued from Previous Page With the gas supply shut off, install a pressure tap on the manifold in the plugged tap provided. Install a manometer on the pressure tap. Test each burner. Turn on the gas supply to the range. Each burner should have a steady blue flame on Re-light the pilots and...
Page 21: Figure
For parts not listed, consult a Southbend Authorized Parts Distributor or Southbend Authorized Service Agency. Consult the Southbend Authorized Parts/Service Distributor list for the Authorized Parts supplier in your area. If this list is not available, call Southbend at 1-800-348-2558 to obtain this list. Index of Parts Diagrams...
Page 22 ARTS EDIUM OUNTERLINE Medium Duty Counterline Griddle Parts See drawing on following page. Part Number Description 1177704 Knob 1178840 Front panel, 24" (for Model MDG-24) 1178842 Front panel, 36" (for Model MDG-36) 1178843 Front panel, 48" (for Model MDG-48) 1178826 Tailpipe 1172857 Legs (set of four)
Page 23 ARTS EDIUM OUNTERLINE Medium Duty Counterline Griddle Parts See parts list on previous page. Model MDG-36 is shown. ’ 1178822 PERATOR ANUAL...
Page 24 ARTS EDIUM OUNTERLINE Medium Duty Counterline Thermostatic-Griddle Parts See drawing on following page. Part Number Description 1182586 Knob 1178988 Front panel, 24" (for Model MDGT-24) 1181400 Front panel, 36" (for Model MDGT-36) 1181408 Front panel, 48" (for Model MDGT-48) 1163506 Tailpipe 1172857 Legs (set of four)
Page 25 ARTS EDIUM OUNTERLINE Medium Duty Counterline Thermostatic-Griddle Parts See parts list on previous page. Model MDGT-36 is shown. ’ 1178822 PERATOR ANUAL...
Page 26 ARTS EDIUM OUNTERLINE Medium Duty Counterline Charbroiler Parts See drawing on following page. Part Number Description 1177704 Knob 1178840 Front panel, 24" (for Models MDC-24 and MDCL-24) 1178842 Front panel, 36" (for Models MDC-36 and MDCL-36) 1178843 Front panel, 48" (for Models MDC-48 and MDCL-48) 1178826 Tailpipe 1172857...
Page 27 ARTS EDIUM OUNTERLINE Medium Duty Counterline Charbroiler Parts See parts list on previous page. Model MDCL-36 is shown. ’ 1178822 PERATOR ANUAL...
Page 28 ARTS EDIUM OUNTERLINE Medium Duty Counterline Open Top Parts See drawing on following page. Part Number Description 1177704 Knob 1178971 Front panel, 12" (for Model MDO-12) 1178969 Front panel, 24" (for Model MD0-24) 1178970 Front panel, 36" (for Model MD0-36) 1178944 Tailpipe 1172857...
Page 29 ARTS EDIUM OUNTERLINE Medium Duty Counterline Open Top Parts See parts list on previous page. Model MDO-36 is shown. ’ 1178822 PERATOR ANUAL...
Page 30 EDIUM OUNTERLINE ’ 1178822 PERATOR ANUAL...
Page 31 EDIUM OUNTERLINE ’ 1178822 PERATOR ANUAL...
Page 32 When service is needed, contact a Southbend Authorized Service Agency, or your dealer. To avoid confusion, always refer to the model number, serial number, and type of your unit.
