ASSEMBLY INSTRUCTIONS
4. Place the bumper on the door as shown
Hardware Used
Bumper 2MM
KK
5. Using a phillips head screwdriver, attach the
mounting plate as shown in the illustration.
Hardware Used
FF Hinge mounting plate
6. Insert the pcc hinge in the bore hole. Using a
phillips head screwdriver, turn the pre-installed
screws clockwise to lock into place.
Insert the hinge in the bore hole. Using
155 o
a phillips head screwdriver, fasten the hinge
screw with the hinges in the clockwise direction.
Place the bumper on the door as shown
Hardware Used
GG
155 o Hinge
HH
PCC Hinge
KK
Bumper 2MM
LL
Hinge screw
4
x 2
5
x 4
6
x 2
x 2
x 2
x 4
7
